ATS 100A 160A 250A 400A 630A 220V AC PC Class Automatic Transfer Switch

FOB Reference Price: Get Latest Price
≥10 Pieces
US $25.5
≥100 Pieces
US $25
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Brand Name:
GANDIAN
Model Number:
GDG-100A/4P
Max. Current:
100
Standard:
IEC947-6-1GB14048.11-2008
Rated working voltage:
AC440V
Rated connecting capacity:
10le
Rated breaking capacity:
8le
Control supply voltage:
DC24V 48V 110V/AC220V
Certification:
CE

Quick Details

Whether the smart:
NO
Max. Voltage:
other
Place of Origin:
Zhejiang, China
Brand Name:
GANDIAN
Model Number:
GDG-100A/4P
Max. Current:
100
Standard:
IEC947-6-1GB14048.11-2008
Rated working voltage:
AC440V
Rated connecting capacity:
10le
Rated breaking capacity:
8le
Control supply voltage:
DC24V 48V 110V/AC220V
Certification:
CE
Products Description

Product Introduction

Dual power transfer switch electrical appliances (transfer switch ATS, also known as ATSE, is the English abbreviation of Automatic transfer Switching equipment.) An electrical appliance that converts one or several load circuits from one power supply to another. It consists of one (or several) transfer switch appliances and other necessary appliances for monitoring the power circuit and automatically switching one or several load circuits from one power source to another. When the common power suddenly fails or fails, it will be automatically switched to the backup power supply through the dual power switch (the backup power supply can also be powered by a generator under small loads), so that the equipment can still operate normally. The most common ones are elevators, fire protection, monitoring, lighting, etc.

Product Features

1. Complete protective fun ctions, including short circuit, overload, open phase and loss-of-voltage protection. 2. Reliable remote double-break with EPS fire protectin power supply interface DC12-24V 3. Noiseless, energy saving, simple installation, easy operation, raliable and stable performance
4. Mechanical life of transfer switch(transfer of normal and reserve power): 3000 times, electric life: 1500 times
此处添加文字标题
Rated heating current(A
100
160
250
Rated insulation voltage Ui (V)
750V
750V
750V
Rated impact withstandvoltage Uimp (kV)
8kV


Rated limit short-circuit current(kA)
100kA


Control supply voltage(V
DC24V,48V,110V,AC220V


If you want to know more, please contact us, we will do our best to meet your needs
