Quick Details
-
Rolling thinckness:
-
0.3-1mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Hokang
-
Voltage:
-
380V / 220V or as required
-
Dimension(L*W*H):
-
5800x900X1500
-
Weight:
-
2500 kg
-
Feeding width:
-
750
-
Marketing Type:
-
New Product
-
Product name:
-
Gusset plate roll forming machine
-
Raw material:
-
Galvanized Coil
-
Application:
-
Building Construction
-
Main frame:
-
350mm/400mm H-Beam
-
Cutting blade material:
-
Cr 12 Mov
-
Roller material:
-
45#steel Chrome Plated
-
Roller stations:
-
18 Stations
-
Control system:
-
PLC
-
Shaft material:
-
High Grade No.45 Forged
-
Decoiler:
-
Manual Decoiler
Quick Details
-
Type:
-
Gusset plate roll forming machine
-
Tile Type:
-
Colored Steel
-
Production Capacity:
-
20M/MIN
-
Rolling thinckness:
-
0.3-1mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Hokang
-
Voltage:
-
380V / 220V or as required
-
Dimension(L*W*H):
-
5800x900X1500
-
Weight:
-
2500 kg
-
Feeding width:
-
750
-
Marketing Type:
-
New Product
-
Product name:
-
Gusset plate roll forming machine
-
Raw material:
-
Galvanized Coil
-
Application:
-
Building Construction
-
Main frame:
-
350mm/400mm H-Beam
-
Cutting blade material:
-
Cr 12 Mov
-
Roller material:
-
45#steel Chrome Plated
-
Roller stations:
-
18 Stations
-
Control system:
-
PLC
-
Shaft material:
-
High Grade No.45 Forged
-
Decoiler:
-
Manual Decoiler
Products Overview
Metal Gusset Plate Billboard Making Machinery Advertising Steel Gusset Plate Cold Roll Forming Machine
Gusset Plate Machine is a very popular type of board in the market in recent years. Mainly exported to markets in Europe, America, Southeast Asia, such as the United States, Germany, Brazil, Malaysia, Chile, Indonesia, the Philippines, Russia, Thailand etc，It features a buckle style splicing design, seamless splicing, convenient installation, and high-end atmosphere. It is mainly used in various occasions such as commercial space background walls, outdoor door heads, indoor and outdoor suspended ceilings, and can be designed with different appearances according to customer requirements.
Feature:
1. The whole machine is controlled by PLC, and multiple safety protections can be set to effectively avoid accidents;
2. The bed is made of steel plate welded parts and tempered to effectively eliminate internal stress and the body is not easy to deform;
3. The forming frame is welded by channel steel;
4. The roll shaft is made of 45# steel, which has been quenched and tempered;
5. The material of forming punching and shearing die is Gr12;
Specification
|
No
|
item
|
value
|
|
1
|
Type
|
Baffle Ceiling Forming Machine
|
|
2
|
Use
|
Metal Fence
|
|
3
|
Production Capacity
|
20M/MIN
|
|
4
|
Voltage
|
380v/220V/415V
|
|
5
|
Rolling thinckness
|
0.3-0.8mm
|
|
6
|
Feeding width
|
750
|
|
7
|
Raw material
|
Steel Coil GI PPGI
|
|
8
|
Cutting
|
Hydraulic Guide Pillar
|
|
9
|
Roller material
|
Cr12Mov
|
|
10
|
Shaft material
|
45# steel
|
|
11
|
Shaft diameter
|
80MM
|
|
12
|
Motor
|
7.5KW
|
|
13
|
Machine frame
|
300H beam
|
|
14
|
Frame thickness
|
16mm, middle plate frame
|
|
15
|
Forming Speed
|
8-15m/min
|
|
16
|
Dimension(L*W*H)
|
5800x900X1500
|
|
17
|
Weight
|
2500kg
|
Noted: There are two types of roll forming machines: standard type and customized type. If you need to customize, please send us the design drawing,feeding width, thickness and raw materials, so that we can customize according to your requirements, which is very important for us!!!
Our Advantages
Gusset plate roll forming machine
1 More efficient and accurate execution of production orders;
2. High equipment reliability;
3. Little waste of materials and energy;
4. High productivity;
5. High quality materials, get a longer service life;
6. All parts of the machine are processed with precision, and the surface of the roll is chromeplated to ensure that customers can get qualified products at the same time, it can avoid the scratch of the color steel surface paint, and increase the service life of the roll;
7. Customized coil processing solutions to solve all aspects of technical problems.
All the control system of our machines we make by ourselves. we have a professional engineer to design and make the control system. This can make sure the after-sale service, when customer have problem with control, we can solve it timely.
Our Technical Personnel Provide On-Site Services Overseas:
Our technical personnel arrive at the customer's site in Malaysia for technical guidance and training,If a customer encounters technical problems that are difficult to solve during use, we usually send professional and technical personnel to foreign customer sites for guidance and training. Therefore, if you want to do business in cold bending forming equipment, please feel free to contact our customer service personnel at any time.
Our technical personnel arrive at the customer's site in Malaysia for technical guidance and training,If a customer encounters technical problems that are difficult to solve during use, we usually send professional and technical personnel to foreign customer sites for guidance and training. Therefore, if you want to do business in cold bending forming equipment, please feel free to contact our customer service personnel at any time.
Details Images
Machine frame of
Gusset plate roll forming machine
Roll Forming Making Machine
adopts welded steel frame structure, it make sure roof sheet machine can operation more stable
Cutting Blade of
Gusset plate roll forming machine
Roll Forming Making Machine
blade using more high precious machine making, which can make sure the tile keep good shape, more better for using.
The forming cutter of cold roll forming machine can cut raw materials of different materials.Our scissors can usually cut 0.3-0.6 mm steel plates.
Forming Roller of
Gusset plate roll forming machine
Roof sheet make machine forming roll quality will decide roof sheet shapes, we can according to your local roof shape customized different type rollers
Roller chrome coated thickness: 0.05 mm
Roller material: Forging Steel 45# heat treatment.
Roller chrome coated thickness: 0.05 mm
Roller material: Forging Steel 45# heat treatment.
PLC control part of
Gusset plate roll forming machine
Roll Forming Making Machine
control parts have different types, standard type are button control, through press buttons to
realize different function.
realize different function.
PLC touch screen type can setting data on the screen, its price is little higher, but is more intelligent and automatic.
Different electric control cabinets for selection：
