Quick Details
-
Interface Type:
-
SATA3
-
Brand Name:
-
Golden memory
-
Model Number:
-
SATA3 SM2246EN SSD
-
Place of Origin:
-
Guangdong, China
-
Certification:
-
FCC CE RoHS TUV
-
Advanced Functions:
-
NCQ, Trim, SMART,Dynamic power management
-
Control chip:
-
SM2258XT
-
Sequential Read:
-
550MB/s
-
Sequential Write:
-
480MB/s
-
ECC:
-
Supports BCH ECC 12/14/40 bits in 1024 bytes
-
Testing line:
-
50 working lines
-
Warranty:
-
3 Years warranty
Quick Details
-
Application:
-
Desktop
-
Type:
-
Internal
-
Style:
-
SSD
-
Interface Type:
-
SATA3
-
Brand Name:
-
Golden memory
-
Model Number:
-
SATA3 SM2246EN SSD
-
Place of Origin:
-
Guangdong, China
-
Certification:
-
FCC CE RoHS TUV
-
Advanced Functions:
-
NCQ, Trim, SMART,Dynamic power management
-
Control chip:
-
SM2258XT
-
Sequential Read:
-
550MB/s
-
Sequential Write:
-
480MB/s
-
ECC:
-
Supports BCH ECC 12/14/40 bits in 1024 bytes
-
Testing line:
-
50 working lines
-
Warranty:
-
3 Years warranty
Product video
product marketing
product picture
Product Parameter
|
Based Specification
|
|
|
||
|
Control chip
|
|
SM2258XT
|
||
|
Interface
|
|
SATAIII
|
||
|
Capacity
|
|
120GB 240GB 480GB 512GB 1Tb
|
||
|
Cache
|
|
128MB
|
||
|
Read/Write Performance
|
|
|
||
|
Sequential Read
|
|
550MB/s
|
||
|
Sequential Write
|
|
480MB/s
|
||
|
4KB Random Read IOPS
|
|
70000
|
||
|
4KB Random Write IOPS
|
|
3000
|
||
|
Response Time
|
|
0.2ms
|
||
|
Power Consumption
|
|
|
||
|
Power Supply
|
|
5V+5%
|
||
|
Standby
|
|
0.3W
|
||
|
Maximum Ripple
|
|
70 mV(peak to peak)
|
||
|
4KB Random Write
|
|
2.5W
|
||
|
Reliability
|
|
|
||
|
Write endurance:
|
|
8 years @ 100G write/day(32G)
|
||
|
Read endurance:
|
|
unlimited
|
||
|
MTBF:
|
|
>2,000,000 hours
|
||
|
Data retention:
|
|
>20years @ 25°C
|
||
|
Data destroy support
|
|
no
|
||
|
Sudden power-off recovery support
|
|
yes
|
||
|
NCQ support
|
|
yes
|
||
|
Trim support
|
|
yes
|
||
|
Dynamic power management support
|
|
yes
|
||
|
SMART support
|
|
yes
|
||
|
ECC:
|
|
Supports BCH ECC 12/14/40 bits in 1024 bytes
|
||
|
Static and dynamic wear-leveling
|
|
|
||
|
Bad block management algorithm
|
|
|
||
|
Environment
|
|
|
||
|
Storage temperature:
|
|
-55~95 °C
|
||
|
Operation temperature:
|
|
-0~55°C
|
||
|
Humidity:
|
|
5%~95%
|
||
|
Vibration
|
|
15G (10 to 2000Hz)
|
||
|
Shock
|
|
350G at 0.5ms
|
||
|
Testing platform
|
|
|
||
|
CPU:
|
|
i5-2400 CPU @ 3.10GHz
|
||
|
Chipset:
|
|
Z68 Express Chipset
|
||
|
Memory:
|
|
KHX1600C9D3C1K2/4GX
|
||
|
|
|
|
||
|
AHCI Driver:
|
|
Server Express Chipset SATA AHCI Controller
|
||
|
BIOS Settings:
|
|
AHCI Mode
|
||
|
Testing software
|
|
Crystal Disk Mark 3.0;HD Tune Pro 3.5;ATTO Disk Benchmark;Iometer2008 AS_SSD Benchmark
|
||
|
Physical Size
|
|
100*70*7 mm
|
||
|
Weight
|
|
80g
|
||
|
Warranty
|
|
3 years
|
||
|
Certification
|
|
CE,ROHS,FCC,TUV
|
||
