GRADE 1, GRADE 2, GRADE 3 SUPPLY STUDLESS LINK MARINE STEEL ANCHOR CHAIN

FOB Reference Price: Get Latest Price

≥500 Meters

US $10

Free Inquiry

Customized Request

Quick Details

Packing:: Nude packed, or packed in drums, or wooden case, then on iron pallet

Packing:: Nude packed, or packed in drums, or wooden case, then on iron pallet

Product Description

GRADE 1, GRADE 2, GRADE 3 SUPPLY STUDLESS LINK MARINE STEEL ANCHOR CHAIN

1.Commodity description	GRADE 1, GRADE 2, GRADE 3 SUPPLY STUDLESS LINK MARINE STEEL ANCHOR CHAIN
2.Category	Chain
3.Standard	anchor chain, Grade 1, Grade 2, Grade 3
4.Material of body	high carbon steel
5.Accessories	kenter shackle,swivel,joining shackle or anchor shackle
6.Surface treatment	self colored, black bitumen painted, electric galvanized, hot dip galvanized
7.Technology	welded
8.Size	16mm-50mm
9.MOQ	100meter
10.Supply ability	100Ton per month
11.Packing	1.nude packed :packed in bundles 2.packed in iron drums then on pallets 3.packed in woodencase 4.requied by the cllent
12.Delivery time	as the quantity in order, 15-30days
13.Payment term	30% deposit prepaid after confirmed PI, the balance against copy of BL before cargo arrival. Or negotiated with clients
14.Main products	anchor chains, NACM standard chains, DIN5685 /DIN766/DIN763 chains decoretive chains shackles , turnbuckles, wire rope clips, pulley blocks, load binders, bolts and nuts, quick links , snap hooks, swivels, wire rope thimbles, ferrules and sleeves
15.Company name	QINGDAO POWERFUL MACHINERY CO.,LTD
16.Experience	17years experience in the area of chains and rigging hardware
17.Main market	the United States, Europe, Mid East, Southeast Asia
18.our advantage	1)more than 15 years experience in the area of chains and rigging hardware
	2)quick react to your email at the first time
	3)provide best price, good quality and my team will supply best seivice

GRADE 1, GRADE 2, GRADE 3 SUPPLY STUDLESS LINK MARINE STEEL ANCHOR CHAIN
Dia.	U1(KN)		U2(KN)		U3(KN)		Weight
MM	Breaking load	Proof load	Breaking load	Proof load	Breaking load	Proof load	kg/m
16	94.72	47.1	132.3	66.2	184.83	92.42	5.56
17.5	113.31	56.35	157.78	78.89	221.1	110.55	6.65
19	133.57	66.42	187.2	93.6	260.64	130.32	7.83
20.5	155.49	77.33	217.27	108.64	303.42	151.7	9.12
22	179.08	89.06	250.9	125.4	349.4	174.7	10.5
24	213.25	105.98	298.9	149.9	415.8	207.9	12.5
26	250.12	124.38	350.8	175.4	488	244	14.67
28	290.08	144.26	406.7	203.8	566	283	17
30	333	165.6	467.5	234.2	649.8	324.9	19.5
32	378.88	188.42	531.2	265.6	739.3	369.6	22.22
34	427.72	212.7	599.8	299.9	834.6	417.3	25.08
36	479.52	238.46	672.3	336.1	935.7	467.8	28.12
38	534.28	265.7	748.7	374.4	1042.5	521.3	31.33
40	592	294.4	829.1	414.5	1155.2	577.6	34.72
42	652.68	324.58	915.3	457.7	1273.6	636.8	38.28
44	706.32	356.22	999.6	502.7	1397.8	698.9	42.01
46	782.92	389.34	1097.6	548.8	1527.8	763.9	45.92
48	852.48	423.94	1195.6	597.8	1663.5	831.7	50
50	926.09	460	1293.6	648.8	1805	902.5	54.25
