- Product Details
- {{item.text}}
Quick Details
-
Input:
-
8 CVBS/4 HDMI/3.5mm audio
-
Output:
-
4 IP signal
-
Network protocol:
-
SRT,HTTP, RTSP, RTMP, RTMPS, UDP, multicast, unicast,HLS
-
Encoded size:
-
640*360~1920*1080,customized
-
power consumption:
-
<28W
-
Power supply:
-
200~240V/100~120V
-
Support:
-
OSD Insertion
-
Code Rate Control:
-
16kbps- 12Mbps
-
Weight:
-
4KG
-
Warranty:
-
2 Years
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Haiwei
-
Model Number:
-
H5448B
-
Input:
-
8 CVBS/4 HDMI/3.5mm audio
-
Output:
-
4 IP signal
-
Network protocol:
-
SRT,HTTP, RTSP, RTMP, RTMPS, UDP, multicast, unicast,HLS
-
Encoded size:
-
640*360~1920*1080,customized
-
power consumption:
-
<28W
-
Power supply:
-
200~240V/100~120V
-
Support:
-
OSD Insertion
-
Code Rate Control:
-
16kbps- 12Mbps
-
Weight:
-
4KG
-
Warranty:
-
2 Years
|
Input
|
4 channel HDMI/ Line-in Audio, 8 channel CVBS/AV
|
|
|
||
|
Output
|
4 channel IP signal output. 1 RJ 100M / 1000M,Main TS stream and Sub TS stream, dual-stream.
|
|
|
||
|
Input resolution
|
Up to 1080p 50fps
|
|
|
||
|
Coding standard
|
H.265 HEVC H.264 AVC
|
|
|
||
|
Video Bit Rate
|
CBR/ VBR, 16kb-12Mbit/s
|
|
|
||
|
Audio Bit Rate
|
64kb/s-384kb/s
|
|
|
||
|
Video packaging
|
FFMPEG/ VLC
|
|
|
||
|
On Screen Display
|
Text ,images
|
|
|
||
|
Network protocol
|
SRT/HLS/HTTP/ RTSP/ RTMP/ RTMPS/ ON VIF/ RTP/ TCP/ UDP( Unicast/ multicast)
|
|
|
||
|
Available image settings
|
Contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering
|
|
|
||
Recommend Products
Support Most Live Streaming Platforms
Multi-protocol, multi-platform, all-round live marketing
Support SRT/ HLS / RTSP/ RTP / RTMP / RTMPS / P2P / DHCP / ON VIF / HTTP / UDP / Unicast / Multicast and other protocols, as long as the live broadcast platform, support the above protocol
Connection Schematic Diagram
OSD（On-Screen Display）
Application
Digital TV Broadcasting System/IPTV&OTT system/Internet TV
Digital Signage /Video Conference/Live streaming/Hotel IPTV System
Digital Signage /Video Conference/Live streaming/Hotel IPTV System
About Haiwei
Haiwei is leading video streaming solutions provider in China, mainly for broadcast, webcaster, Multimedia platform, sports, IPTV operator, IPTV project for Hotel/ enterprises, military project, and city's construction. Haiwei provide SDK for integration project, can be tailored to each customer's unique market needs, and developed "IP finder", "Multi devices manager", "APP for smartphone" for different use.
