Quick Details
-
Model Number:
-
R6
-
Specification:
-
20-1100mm
-
Length:
-
6m or as required
-
Thickness:
-
2-60mm
-
Standard:
-
GBT13663-2000,ISO4427-1:2007, GBT13663-2000,ISO4427-1:2007
-
product name:
-
Sdr 17 Pe 100 Dn300 High Density Polypropylene Pipes Hdpe Pipe 560 Mm
-
Certification:
-
CE ISO
-
Warranty:
-
50 years
-
Pressure:
-
0.6MPa-1.6Mpa
-
Product name:
-
HDPE Polyethylene Black Pipe
-
Application field:
-
water supply and drainage
-
Feature:
-
Corrosion Resistant
-
Temperature:
-
-60℃-60℃
-
Usage:
-
Water Supply
Quick Details
-
Processing Service:
-
Moulding, Cutting
-
Place of Origin:
-
China (Mainland)
-
Brand Name:
-
Hesu
-
Model Number:
-
R6
-
Specification:
-
20-1100mm
-
Length:
-
6m or as required
-
Thickness:
-
2-60mm
-
Standard:
-
GBT13663-2000,ISO4427-1:2007, GBT13663-2000,ISO4427-1:2007
-
product name:
-
Sdr 17 Pe 100 Dn300 High Density Polypropylene Pipes Hdpe Pipe 560 Mm
-
Certification:
-
CE ISO
-
Warranty:
-
50 years
-
Pressure:
-
0.6MPa-1.6Mpa
-
Product name:
-
HDPE Polyethylene Black Pipe
-
Application field:
-
water supply and drainage
-
Feature:
-
Corrosion Resistant
-
Temperature:
-
-60℃-60℃
-
Usage:
-
Water Supply
|
item
|
value
|
|
Place of Origin
|
China (Mainland)
|
|
Brand Name
|
Hesu
|
|
Model Number
|
R6
|
|
Material
|
PE
|
|
Specification
|
20-1100mm
|
|
Length
|
6m or as required
|
|
Thickness
|
2-60mm
|
|
Standard
|
GBT13663-2000,ISO4427-1:2007
|
|
Processing Service
|
Moulding, Cutting
|
|
product name
|
Sdr 17 Pe 100 Dn300 High Density Polypropylene Pipes Hdpe Pipe 560 Mm
|
|
Certification
|
CE ISO
|
|
Warranty
|
50 years
|
|
Pressure
|
0.6MPa-1.6Mpa
|
|
Product name
|
HDPE Polyethylene Black Pipe
|
|
Application field
|
water supply and drainage
|
|
Feature
|
Corrosion Resistant
|
|
Temperature
|
-60℃-60℃
|
|
Standard
|
GBT13663-2000,ISO4427-1:2007
|
|
Usage
|
Water Supply
|
|
Product Name
|
PE100 Water Supply HDPE Pipe
|
|
Color
|
Black with bule line
|
|
Standard
|
GB/T13663-2000,ISO 4427-1:2007
|
|
Specification
|
20-1200mm
|
|
Pressure
|
0.6MPa SDR26,0.8MPa SDR21,1MPa SDR17,1.25MPa SDR 13.6,1.6MPa SDR 11
|
|
Main application
|
Water Supplying and Draining
|
|
Guarantee
|
More than 50 years
|
|
Pressure
OD
(mm)
|
PN0.6MPa SDR 26
Thickness
(mm)
|
PN0.8MPa SDR 21
Thickness
(mm) |
PN1.0MPa SDR 17
Thickness
(mm) |
PN1.25MPa SDR 13.6
Thickness
(mm) |
PN1.6MPa SDR 11
Thickness
(mm) |
|
63
|
|
|
3.7
|
4.7
|
5.8
|
|
75
|
|
|
4.5
|
5.6
|
6.8
|
|
90
|
|
4.3
|
5.4
|
6.7
|
8.2
|
|
110
|
4.2
|
5.3
|
6.6
|
8.1
|
10.0
|
|
125
|
4.8
|
6.0
|
7.4
|
9.2
|
11.4
|
|
140
|
5.4
|
6.7
|
8.3
|
10.3
|
12.7
|
|
160
|
6.2
|
7.7
|
9.5
|
11.8
|
14.6
|
|
180
|
6.9
|
8.6
|
10.7
|
13.3
|
16.4
|
|
200
|
7.7
|
9.6
|
11.9
|
14.7
|
18.2
|
|
225
|
8.6
|
10.8
|
13.4
|
16.6
|
20.5
|
|
250
|
9.6
|
11.9
|
14.8
|
18.4
|
22.7
|
|
280
|
10.7
|
13.4
|
16.6
|
20.6
|
25.4
|
|
315
|
12.1
|
15.0
|
18.7
|
23.2
|
28.6
|
|
355
|
13.6
|
16.9
|
21.1
|
26.1
|
32.2
|
|
400
|
15.3
|
19.1
|
23.7
|
29.4
|
36.3
|
|
450
|
17.2
|
21.5
|
26.7
|
33.1
|
40.9
|
|
500
|
19.1
|
23.9
|
29.7
|
36.8
|
45.4
|
|
560
|
21.4
|
26.7
|
33.2
|
41.2
|
50.8
|
|
630
|
24.1
|
30.0
|
37.4
|
46.3
|
57.2
|
|
710
|
27.2
|
33.9
|
42.1
|
52.2
|
|
|
800
|
30.6
|
38.1
|
47.4
|
58.8
|
|
|
900
|
34.4
|
42.9
|
53.3
|
|
|
|
1000
|
38.2
|
47.7
|
59.3
|
|
|
|
1200
|
45.9
|
57.2
|
|
|
|
Packing Details : container or as customer required
Delivery Details : within 15 days after payment
Q: What is your MOQ?
A: As customer's request.
Q: Why choose us?
A: We are a professional and leader of HDPE pipe factory, we offer pipeline system one stop services with competitive price and fast delivery time, and we insure our quality is the second to none.
Q: How to buy the product?
A: Contact with us by email or by Trade Manager, and inform us which product and quantity that you need, we will contact
you immediately. More specify the information that you provided more faster and easier you will get the quotation.
Q: Can I make my own design and logo on the product?
A: Yes, we do OEM. Welcome partner from globally, we can make your product in China.
Q: What's the payment term?
A: Order amount <=1,000USD, 100% in advance.
Order amount>=1,000USD, 30% T/T in advance, balance before shipment.
Order amount>20,000USD, 30% T/T in advance, balance L/C at sight acceptable.
Order amount>100,000USD, 100% L/C at sight acceptable.
Q: Still have more questions?
A: Please use the table below and send your questions to us. Thank you.
