Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Hengwang
-
Model Number:
-
HWSD13, HWSD13S
-
Dimension(Long * Breadth * High):
-
4492*3185*2950mm
-
Parameter name:
-
HWSD13
-
Operating weight (Kg):
-
13700
-
Ground pressure (kPa):
-
53.8
-
Engine model:
-
SC8D143G2B1 (China-II) /SC8DK (China-III)
-
Rated power/rated speed (kW/rpm):
-
105/1900
-
Overall dimensions of machine (mm):
-
4492*3185*2950
-
Forward speed (km/h):
-
F1: 0-3.2 F2:0-5.9 F3:0-9.8
-
Reversing speed (km/h):
-
R1:0-3.9 R2:0-7.1 R3:0-11.9
-
Center distance of track (mm):
-
1880
-
Width of track shoes (mm):
-
700
Quick Details
-
Machine Weight:
-
13700 KG
-
Dozing Capacity:
-
Other
-
Marketing Type:
-
Hot Product 2023
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Hengwang
-
Model Number:
-
HWSD13, HWSD13S
-
Dimension(Long * Breadth * High):
-
4492*3185*2950mm
-
Parameter name:
-
HWSD13
-
Operating weight (Kg):
-
13700
-
Ground pressure (kPa):
-
53.8
-
Engine model:
-
SC8D143G2B1 (China-II) /SC8DK (China-III)
-
Rated power/rated speed (kW/rpm):
-
105/1900
-
Overall dimensions of machine (mm):
-
4492*3185*2950
-
Forward speed (km/h):
-
F1: 0-3.2 F2:0-5.9 F3:0-9.8
-
Reversing speed (km/h):
-
R1:0-3.9 R2:0-7.1 R3:0-11.9
-
Center distance of track (mm):
-
1880
-
Width of track shoes (mm):
-
700
Factory introduction
Shandong Hengwang Group Co., Ltd. is located in Shiqiao Industrial Park, Jining City, Shandong Province, China. Our Group occupies an area of about 40,000 square meters.It is a comprehensive enterprise integrating construction equipment design, manufacture and installation.Our group has over 300 workers, 35 senior engineers and 260 salesmen. The main processing equipment quantity reaches 100 sets,including of CNC lathe machines, advanced guide way grinder, and TK611-1A CNC milling & boring machine.Hengwang construction machinery products mainly include bulldozers, cranes, self-loading concrete mixer trucks and backhoe loaders, etc., which are widely used in various engineering construction sites.
We have the well-equipped machine, advanced technology, and strict quality management system. Excellent quality and good service win trust and reward in domestic and overseas. We sincerely welcome friends from all over the world to come for a visit and cooperation!
Product Manual
Product Details
Product Paramenters
|
Parameter name
|
HWSD13 (Standard version)
|
HWSD13S (Wetland version)
|
|
Operating weight (Kg)
|
13700
|
14900
|
|
Ground pressure (kPa)
|
53.8
|
38.4
|
|
Engine model
|
SC8D143G2B1 (China-II) /SC8DK (China-III)
|
SC8D143G2B1 (China-II) /SC8DK (China-III)
|
|
Rated power/rated speed (kW/rpm)
|
105/1900
|
105/1900
|
|
Overall dimensions of machine (mm)
|
4492*3185*2950
|
4492*3510*3000
|
|
Forward speed (km/h)
|
F1: 0-3.2 F2:0-5.9 F3:0-9.8
|
F1: 0-3.2 F2:0-5.9 F3:0-9.8
|
|
Reversing speed (km/h)
|
R1:0-3.9 R2:0-7.1 R3:0-11.9
|
R1:0-3.9 R2:0-7.1 R3:0-11.9
|
|
Center distance of track (mm)
|
1880
|
1880
|
|
Width of track shoes (mm)
|
460
|
700
|
|
Ground length (mm)
|
2365
|
2365
|
