Quick Details
-
Brick size:
-
400*200*200 mm
-
Place of Origin:
-
China
-
Brand Name:
-
HF
-
Voltage:
-
220-440
-
Dimension(L*W*H):
-
9350x2320x2950mm
-
Marketing Type:
-
Hot Product 2021
-
Weight (KG):
-
11000 kg
-
After-sales Service Provided:
-
Field maintenance and repair service
-
Block Type:
-
Hollow Concrete Brick Machine
-
Model:
-
QT10-15
-
Vibrating Force:
-
100KN
-
Pallet size:
-
1150x900
-
Molding cycle:
-
15-20s
-
Advantage:
-
Easy Operation
-
Machine Type:
-
Fully Automatic Brick Block Making Machine
-
Motor:
-
Siemens Brand
-
Certification:
-
CE,ISO,TUV,BV
Quick Details
-
Type:
-
Hollow Block Making Machine
-
Brick Raw Material:
-
Cement
-
Production Capacity (Pieces/8 hours):
-
50 sets per month
-
Brick size:
-
400*200*200 mm
-
Place of Origin:
-
China
-
Brand Name:
-
HF
-
Voltage:
-
220-440
-
Dimension(L*W*H):
-
9350x2320x2950mm
-
Marketing Type:
-
Hot Product 2021
-
Weight (KG):
-
11000 kg
-
After-sales Service Provided:
-
Field maintenance and repair service
-
Block Type:
-
Hollow Concrete Brick Machine
-
Model:
-
QT10-15
-
Vibrating Force:
-
100KN
-
Pallet size:
-
1150x900
-
Molding cycle:
-
15-20s
-
Advantage:
-
Easy Operation
-
Machine Type:
-
Fully Automatic Brick Block Making Machine
-
Motor:
-
Siemens Brand
-
Certification:
-
CE,ISO,TUV,BV
Products Description
1. Particular storage and description material system insure the feeding accuracy and avoiding the effect of exterior material. So the products have high density.
2. Adopting synchronization vibration insures the products making average. The frequency can change according to different technics. Low frequency in feeding material, high frequency vibration makes the different material to have a optimal vibration way.
3. The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault. Combine with long-distance controlling system, it can achieve scrutiny, controlling, diagnosis
4. PLC intelligent control: Man-machine interface, control system equipped with complete logic control, production program, malfunction diagnosis system and remote control function. So it doesn't need a professional person but only need a simple training to the operator.
5. It produces various bricks/blocks including color-face bricks (layered material feeding),through-body tiles,lock linkage blocks, road curb bricks, hydraulic blocks,hollow blocks, perforated bricks, and standard bricks etc.
2. Adopting synchronization vibration insures the products making average. The frequency can change according to different technics. Low frequency in feeding material, high frequency vibration makes the different material to have a optimal vibration way.
3. The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault. Combine with long-distance controlling system, it can achieve scrutiny, controlling, diagnosis
4. PLC intelligent control: Man-machine interface, control system equipped with complete logic control, production program, malfunction diagnosis system and remote control function. So it doesn't need a professional person but only need a simple training to the operator.
5. It produces various bricks/blocks including color-face bricks (layered material feeding),through-body tiles,lock linkage blocks, road curb bricks, hydraulic blocks,hollow blocks, perforated bricks, and standard bricks etc.
|
Main technical parameter
|
|
|
|
|
||||
|
Qty/mould
|
|
10pcs/mould (hollow block 400*200*200mm)
|
|
|
||||
|
Pallet size
|
|
1150x900mm
|
|
|
||||
|
Molding cycle
|
|
15-25s
|
|
|
||||
|
Vibration frequency
|
|
2800-4200 rolls/minute
|
|
|
||||
|
Host Machine Power
|
|
63.5Kw
|
|
|
||||
|
Overall Dimension
|
|
9350x2520x2950mm
|
|
|
||||
|
Host machine weight
|
|
11000Kg
|
|
|
||||
|
Factory Area
|
|
2000m²
|
|
|
||||
|
Applied Products
|
|
concrete blocks, solid/hollow/cellular masonry products, paving stones with color or without color etc.
|
|
|
||||
