Elang 400cfm Environmental Skid Mounted Air Compressor
Elang 400cfm Environmental Skid Mounted Air Compressor
Elang 400cfm Environmental Skid Mounted Air Compressor
Elang 400cfm Environmental Skid Mounted Air Compressor
Elang 400cfm Environmental Skid Mounted Air Compressor
Elang 400cfm Environmental Skid Mounted Air Compressor
Elang 400cfm Environmental Skid Mounted Air Compressor
Elang 400cfm Environmental Skid Mounted Air Compressor

Elang 400cfm Environmental Skid Mounted Air Compressor

FOB Reference Price: Get Latest Price
≥1 Sets
US $12800
≥3 Sets
US $12300
≥10 Sets
US $11800
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Product Name:
Diesel Portable Air Compressor
Engine Model:
EL400
OEM / ODM:
Provide
Protection Grade:
IP54 /IP55
Insulation Grade:
F
Color:
Red & White
Cooling Method:
Air Cooling
Delivery Ways:
Oceanshipping
Exhaust Oil Content:
< 3ppm

Quick Details

Place of Origin:
Jiangsu, China
Brand Name:
ELANG
Model Number:
EL400
Product Name:
Diesel Portable Air Compressor
Engine Model:
EL400
OEM / ODM:
Provide
Protection Grade:
IP54 /IP55
Insulation Grade:
F
Color:
Red & White
Cooling Method:
Air Cooling
Delivery Ways:
Oceanshipping
Exhaust Oil Content:
< 3ppm
Elang 400cfm Environmental Skid Mounted Air Compressor
Product Name:
Elang 400cfm Environmental Skid Mounted Air Compressor
Working Pressure: 8/10 bar
Air Delivery: 11 m 3 /min
Engine Model: EL400
Dimension: 3800*1900*1900 mm
Weight: 1820kg

There are more parameters below.

Description

The machine can meet the demands of overloading use and stands up to the most severe filed environment. Meanwhile, it also can reduce fuel consumption,which greatly cut down the operation cost. Subsided  structure to install the oil tank, placed around each one, Increase oil reserves, make the add oil time interval longer, the weight on both sides are  balanced. Tank not in the case, make the space more and not only bring convenience to maintenance service, noise is reduced accordingly, but also giving the customer a good value feeling.

Advantages

  1. High Reliability:

    Less compressor parts, without wearing parts, so it is reliable, long life, overhaul interval is up to 40 to 80 thousand hours.

  2. Easy Operation and Maintenance:

    A high degree of automation, the operator does not have to go through a long period of professional training, can achieve unattended operation.

  3. The Power Balance is Good:

    There is no unbalanced inertia force, can smoothly high-speed operation, can achieve no basic operation, especially suitable for portable compressors, small size, light weight, small footprint.

  4. Strong Adaptability:

    With a mandatory gas transmission characteristics, the volume flow is almost free from the impact of exhaust pressure, in a wide range of speed to maintain high efficiency.

Model Working Pressure Air Flow Air Outlets Engine Brand Engine Model Power Dimension Weight
Psig Bar cfm m 3 /min rpm L*W*H (mm) Kg
EL185 100 7 185 5 G1, G3/4 Yanmar 4TNV94L 36.2 2460*1400*1430 1200
Kubota V1505T 33
Weichai WP3.2G50E347 36.8
EL250 116 8 250 7 G1-1/4, G1 Yanmar 4TNV98C 51.7 3300*1570*1570 1500
Cummins QSB-C80 60
EL350 116 8 350 10 G1-1/4, G1 Cummins QSB3.9-C125 93 3800*1900*1900 1820
145 10 350 10
EL400 116 8 400 11 G1-1/4, G1 Cummins QSB3.9-C125 93 3800*1900*1900 1820
145 10 400 11
EL460 188 13 460 13 G1-1/2, G1-1/4 Cummins QSB3.9-C150 110 4000*1900*1900 1860
EL550 203 14 550 16 G1-1/2, G1-1/4 Cummins QSB5.9-C210 154 4350*1960*1950 2200
EL660 246 17 660 18 G1-1/2, 3*G1-1/4 Cummins QSB8.3-C2610 194 4580*1950*2500 2920
EL1050 348 24 1050 29 2*G1-1/2
2*G1-1/41-G1
Cummins QSZ13-C550 410 5400*2100*2550 36800
EL1200 362 25 1200 34 2*G1-1/2
2*G1-1/41-G1
Cummins QSZ13-C550 410 5400*2100*2550 4000
507 35 1200 34 Cummins QSK19-700 522 5400*2100*2550 4800
Specifications are subject to change without notice.
Cummins, Yanmar, Kubota, Perkins, Cat, Volvo, Weichai, Yuchai..etc. Level 2, Level 3, Level 4...etc for choose.

Q1: Why customer choose us?

A: ELANG Group was established in 1999, we are specialized in Rotary Screw Air Compressor. Germany Standard and 10 years exporting experience help us won more than 50 loyal foreign agents. We warmly welcome your small trial order for quality or market test.

Q2: Are you a manufacturer or trading company?

A: We are professional manufacturer with big modern factory in Nantong, Jiangsu Province, China. Both OEM & ODM service can be accepted.

Q3: What's your delivery time?

A: Generally 3 to 7 days, if urgently order, pls contact our sales in advance.

Q4: How long is your air compressor warranty?

A: One year for the whole machine and two years for screw air end, except consumble spare parts.

Q5: How long could your air compressor be used?

A: Generally, more than 10 years.

Q6: What's payment term?

A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc.
Also we could accept USD, RMB, Euro and other currency.

Q7: How about your customer service?

A: 24 hours on-line service available. 48hours problem sovled promise.

Q8: How about your after-sales service?

A: 1. Provide customers with intallation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3. Worldwide agents and after service avaiable.
