Quick Details
-
CRI (Ra>):
-
90
-
Lamp Luminous Efficiency(lm/w):
-
80-90
-
Lamp Luminous Flux(lm):
-
1200-1350
-
Working Lifetime(Hour):
-
50000
-
Working Temperature(℃):
-
-20 - 50
-
Product Weight（kg）:
-
0.3
-
Feature:
-
Long Life
-
IP Grade:
-
IP67
-
Power:
-
15W/M
-
Voltage:
-
AC 110V/220V
-
Color:
-
2700K 3000K 4000K 5000K 6500K
-
LED QTY:
-
420leds/sheet
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
RAYMATES
-
Model Number:
-
RM-COBW420-12A110/120
-
CRI (Ra>):
-
90
-
Lamp Luminous Efficiency(lm/w):
-
80-90
-
Lamp Luminous Flux(lm):
-
1200-1350
-
Working Lifetime(Hour):
-
50000
-
Working Temperature(℃):
-
-20 - 50
-
Product Weight（kg）:
-
0.3
-
Feature:
-
Long Life
-
IP Grade:
-
IP67
-
Power:
-
15W/M
-
Voltage:
-
AC 110V/220V
-
Color:
-
2700K 3000K 4000K 5000K 6500K
-
LED QTY:
-
420leds/sheet
Product parameters
|
Model No.
|
RM-COBW420-12A110/120
|
|
LED Type
|
High voltage light strip
|
|
LEDs Qty
|
420 Chips/m
|
|
Voltage
|
110v/220v
|
|
Color Temperature
|
2700K/3000K/4000K/6000K
|
|
Wattage
|
15w/m
|
|
CRI
|
90
|
|
Beam Angle
|
180 degree
|
|
Waterproof Level
|
IP67
|
|
Dimension
|
12mm*50M/Roll
|
|
Certification
|
ETL,TUV,CE,RoHS
|
|
Warranty
|
5 YEARS
|
|
Place of Origin
|
Guangdong,China
|
COB light strip definition
The LED COB Strip's full name: Chip-On-Board, which is a production technology the low-power chips are directly encapsulated on the PCB board. Fastest heat dissipation.
The Traditional SMD LED Strip is made of chips on the frame and made into SMD. Then put the LEDs on the PCB board. COB tape light saves lots of costs and space on the PCB. For example, SMD 2110 strip light can hold a maximum of 700 LEDs per meter. However, the COB led strip can hold 1056 chips or more. And because the cost of mounting the Chip on the frame is saved, the price of the COB led strip is much Cheaper than the same number of led strips.
The Traditional SMD LED Strip is made of chips on the frame and made into SMD. Then put the LEDs on the PCB board. COB tape light saves lots of costs and space on the PCB. For example, SMD 2110 strip light can hold a maximum of 700 LEDs per meter. However, the COB led strip can hold 1056 chips or more. And because the cost of mounting the Chip on the frame is saved, the price of the COB led strip is much Cheaper than the same number of led strips.
Advantages
1, Flip-chip, new technology against traditional strip.
2, High density LEDs, no darkness.
3, Beam angle 180°, homogeneous illumination.
4, Extremely flexible, bending diameter >10mm.
5, Excellent heat dissipation.
2, High density LEDs, no darkness.
3, Beam angle 180°, homogeneous illumination.
4, Extremely flexible, bending diameter >10mm.
5, Excellent heat dissipation.
