Factory multifunctional walking tractor two wheels mini tractor with disc plough
Factory multifunctional walking tractor two wheels mini tractor with disc plough
Factory multifunctional walking tractor two wheels mini tractor with disc plough
Factory multifunctional walking tractor two wheels mini tractor with disc plough
Factory multifunctional walking tractor two wheels mini tractor with disc plough
Factory multifunctional walking tractor two wheels mini tractor with disc plough
Factory multifunctional walking tractor two wheels mini tractor with disc plough
Factory multifunctional walking tractor two wheels mini tractor with disc plough

Factory multifunctional walking tractor two wheels mini tractor with disc plough

FOB Reference Price: Get Latest Price
≥2 Pieces
US $500
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Make:
walking tractor two wheels
Place of Origin:
Germany
Weight:
25 KG

Quick Details

Rated Power (HP):
20-60HP
Brand Name:
walking tractor two wheels
Year:
2023
Make:
walking tractor two wheels
Place of Origin:
Germany
Weight:
25 KG

The walking tractor can drive by the power of the internal combustion engine through the transmission system, and the driving wheels that obtain driving torque then give the ground a small, backward horizontal force (tangential force) through the tire pattern and tire surface. This reaction force is to push the tractor forward Driving force for driving (also called position propulsion). The structure is simple, the power is small, and it is suitable for small arable land. The driver supports the handrail frame to control the operating mechanism, towing or driving the supporting agricultural tools to perform the operation.

Engine
Model
QD-WT10E
Chassis
Dimension
2180×905×1070MM
Rated Power
7.35KW/10HP
Tires Model
6.00-12
Rated Speed
2200RPM
Transmission
Vee-Belt Trans
Type
1 Cylinder 4 Stroke
Gears Style
6 Forward, 2 Reverse
Cylinder Bore
90MM
Steering Type
Single Side Steering
Piston Stroke
90MM
Wheel Tread
680--740MM
Displacement
0.573L
Min. G. Clearance
210MM
Weight
125KG
Structure Weight
325KG
