Product name:
-
SMD LED Aluminium PCB Printed Circuit Board
-
Keyword:
-
aluminium printed circuit board
Quick Details
-
Base Material:
-
FR-4,Hi-TG FR4,CEM-1,CEM-3
-
Board Thickness:
-
1.6mm
-
Model Number:
-
pcb
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FS
-
Copper Thickness:
-
0.3oz-3oz
-
Min. Hole Size:
-
0.1mm
-
Min. Line Width:
-
0.15mm
-
Min. Line Spacing:
-
0.15mm
-
Surface Finishing:
-
HASL Lead Free,ENIG,OSP
-
Board Size:
-
custom
-
Layer:
-
1-12 Layers
-
Certification:
-
ISO/UL/RoHS/TS16949
-
Board Thickness Tolerance:
-
5-10%
-
Copper Weight Tolerance:
-
±0.15 oz
-
Flame resistance:
-
94v0
-
Silk Screen Min Line Width:
-
0.15mm
-
Application:
-
Consumer Electronics
-
Service:
-
One stop service
-
Product name:
-
SMD LED Aluminium PCB Printed Circuit Board
-
Keyword:
-
aluminium printed circuit board
SMD LED Aluminium PCB Printed Circuit Board
Product Description:
|
Product Type |
Al Clad PCB 1 layer~2 layer |
|
Maximum Panel size |
20"*24" (1170mm*600mm) |
|
Copper thickness |
0.5oz, 1oz, 2oz, 3oz and 4 oz |
|
Dielectric Thickness
|
0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm |
|
Substrate Core Thickness |
0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm,2.0mm, 3.0mm and 3.2mm |
|
Finished Board Thickness |
0.4mm To 4.0mm |
|
Thickness Tolerance |
+/-10% |
|
Aluminum Machining |
Drilling,Tapping,Milling,Routing, Die-Punching,break-off tab available |
|
Min. Finish hole size |
0.25mm |
|
Max.working voltage |
2.5kVDC(0.075mm Dielectric), 3.75kVDC (0.15mm Dielectric) |
|
Min.Track Width |
0.2mm (8mils) |
|
Min.Track gap |
0.2mm (8mils) |
|
Min. SMD pad pitch |
0.2mm (8mils) |
|
Surface Finishing |
HASL, HASL Leadfree, Immersion gold, Flash gold, OSP |
|
Soldermask color |
White, Black, others Available |
|
Legend color |
Black, White, others Available |
|
Etest |
YES |
|
Rohs |
YES |
|
Reference Standard |
IPC-A-600G Class 2 |
|
Special holes |
Spot facing, Cup holes |
|
Data Input |
Gerbers, AutoCad, Cam350, PROTEL 99SE,PROTEL DXP,
|
Aluminum PCB
is one of metal-based pcb,including copper foil,thermal insulating layer and metal substrate,its structure divide into three layers:
1. Circuit layer: the equivalent of an ordinary PCB,copper thickness from 1oz to 10oz.
2. Insulation layer: Insulation is a layer of thermal insulating material with low thermal resistance.Thickness: 0.003 "to 0.006" inch is the aluminum pcb core technology.
3. Based Layer: a metal substrate,usually aluminum or copper may be chosen.
Peculiarity of Aluminum PCB:
High Heat dissipation, Electromagnetic Shielding, High Mechanical Strength, Excellent processing performance.
PCB or PCB Assembly files requests
1.
Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly
To short the lead time, please kindly advise us if there is any acceptable components substitution.
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary
