ZCS07 Portable Payment ISO 14443 RS232 USB 13.56mhz Contactless Smart Card Reader Writer

ZCS07 Portable Payment ISO 14443 RS232 USB 13.56mhz Contactless Smart Card Reader Writer

FOB Reference Price: Get Latest Price

≥100 Pieces

US $30

≥1000 Pieces

US $15

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: ZCS

Model Number:: iMxiPay-BL

Place of Origin:: Guangdong, China

Product name:: ZCS07 Multi-functional Card Reader

Support cards:: IC/ID/RFID/PSAM

Application:: sdk

Windows system:: Win7, Win 8, Win2008, Win 2003, Win10, XP

Card contact usage times:: ≥5000 times

Dimensions:: 72mm (L) *72mm (W) *14.25mm (H)

Power supply:: USB interface powered

RFID Operating frequency:: 13.56 MHz

Quick Details

Type:: SD Card, XD Card, MMC CARD, Memory Stick Card, SM Card, CF Card

Interface:: usb

Installation:: External

Brand Name:: ZCS

Model Number:: iMxiPay-BL

Place of Origin:: Guangdong, China

Product name:: ZCS07 Multi-functional Card Reader

Support cards:: IC/ID/RFID/PSAM

Application:: sdk

Windows system:: Win7, Win 8, Win2008, Win 2003, Win10, XP

Card contact usage times:: ≥5000 times

Dimensions:: 72mm (L) *72mm (W) *14.25mm (H)

Power supply:: USB interface powered

RFID Operating frequency:: 13.56 MHz

Products Description

1. ZCS07 Multi-functional Card Reader – Unlocking the Power of Card Data!

ZCS07 card reader, capable of reading and writing 13.56MHz contactless cards, 125KHz ID cards, contact-based IC cards, and PSAM cards. Seamlessly connect to your PC and other compatible devices through the USB interface. Whether you're in the industrial, commercial, telecommunications, taxation, banking, insurance, medical, or various payment and storage value management systems, the ZCS07 is the ultimate choice. It supports reading and writing various card types to cater to your wide-ranging application needs. The ZCS07 comes equipped with programmable functionality, allowing you to effortlessly handle different data formats and intelligent interface outputs. It can be programmed and configured to match application requirements and communication needs. Choosing the ZCS07 means opting for an efficient, flexible, and reliable card reading solution. Let the ZCS07 bring convenience and innovation to your workflow, enabling you to work smarter and more efficiently.

2.Feature

* USB communication with PC.
* Support for CCID and keyboard emulation output.
* Compact, aesthetically pleasing, and practical design.
* Self-check during startup, USB-powered, plug-and-play without the need for additional driver installation.
* Reading and writing capabilities for IC cards and proximity cards.
* Ability to read and write various memory cards and support CPU cards with T=0, T=1 communication protocols.
* Support for multifunctional operations with SAM cards.
* Programmable buzzer.

ZCS07 Multi-functional Card Reader
Material	ABS
Dimensions	72mm (L) × 72mm (W) × 14.25mm (H)
Interface	USB 2.0, USB-OTG
Power supply	USB interface powered
Operating System	Win7, Win 8, Win2008, Win 2003, Win10, XP
ID Card		-0℃ to 45℃
Operating frequency	125KHz
Card type	EM4100 and others
Reading distance	0-5cm
RFID Card		2GB RAM+16GB Flash
Operating frequency	13.56 MHz
Smart card interface	ISO14443-A/B, Mifare series, etc
Detection distance	0-5cm
Card reading/writing speed	106kbps, 212kbps, 424kbps, 848kbps
Card compatibility	ISO14443A,MifareOneS50,MifareOneS70,MF3 DESFIRE, Ultralight、ISO14443B 、SONY felica
IC Card
Card standard	ISO7816 1/2/3, Class A, B, C (5V, 3V, 1.8V), T=0 and T=1
Card reading/writing speed	9.6-115.2kbps
Card compatibility	AT24C01A/24C02/24C04/24C08/24C16/AT24C64, SLE4432/4442, SLE4418/4428
PSAM Card
Card contact usage times	≥5000 times
PC communication type	USB
Communication protocol	Supports T=0, T=1 protocol
Standards followed	ISO 7816
