Gluing
Traditional way of gluing is stable,
Teflon coated glue pot for EVA
hot-melt glue has a high
capacity.(about 5L)
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
4500*900*1500
-
Power (kW):
-
8
-
Weight (KG):
-
2200 kg
-
Panel Feed Speed(m/min):
-
13m/min
-
Product name:
-
Wood Edge Banding Machine
-
Color:
-
Customized Making
-
After Warranty Service:
-
Video Technical Support Online Support
-
Total Power:
-
3.8kw
-
Panel thickness:
-
10-60mm
-
Edge Band Width:
-
10-65mm
-
Control system:
-
CNC Control System
-
Overall Size:
-
3600*750*1500mm
-
Application:
-
Furniture Industry
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Grandio
-
Voltage:
-
380/220v, 380V-50Hz 3phase
-
Dimension(L*W*H):
-
4500*900*1500
-
Power (kW):
-
8
-
Weight (KG):
-
2200 kg
-
Panel Feed Speed(m/min):
-
13m/min
-
Product name:
-
Wood Edge Banding Machine
-
Color:
-
Customized Making
-
After Warranty Service:
-
Video Technical Support Online Support
-
Total Power:
-
3.8kw
-
Panel thickness:
-
10-60mm
-
Edge Band Width:
-
10-65mm
-
Control system:
-
CNC Control System
-
Overall Size:
-
3600*750*1500mm
-
Application:
-
Furniture Industry
Product Description
Machine Specification:
|
Model
|
GD-2400
|
|
Panel Feed Speed(m/min)
|
15m/min
|
|
Edge Thickness
|
0.4-3mm
|
|
Edge Width
|
10-50mm
|
|
Edge banding height
|
12-60mm
|
|
Panel thickness
|
8-30mm
|
|
Mini work Panel Width
|
> 80mm
|
|
Mini work Panel Length
|
>120 Mm
|
|
Heating power of plastic box
|
1.5kw
|
|
Plate preheating power
|
0.37KW
|
|
End cutting motor power
|
0.55kw * 2 1200r / min200HZ
|
|
Transmission motor power
|
2.2KW
|
|
Polishing motor power
|
0.18kw*2 1400r / min 300Hz
|
|
Fine trimming motor power
|
0.75kw*2 1800r / min 300Hz
|
|
Total power
|
10kw
|
|
Air pressure
|
0.9MPA
|
|
Machine weight
|
2200KG
|
|
Machine size
|
4500*900*1500mm
|
Detailed Images
6 basic functions
Front and end cutting
Linear guide way structure at an
angle of 45 degrees with 2 motors
(0.35kw 200hz 12000rmp/min) to
remove the extra edge tape on
front and back.
Double trimming
Rough trimming unit with 2
powerful motors(power 0.75kw;
frequency 200hz; rotating speed
1,2000
rpm/min )and
2 milling
cutters;
Fine trimming, 2 motors (power:
0.55kw; frequency:200hz, rotating
speed:12000rpm/min).
Scrapping
Scraping the edge by R2
cutters(Standard), making edge
banding more beautiful. Air blowing
device blowing toward the scraping.
cutters on upside and underside for
cleaning the scraps on cutter surface
and cooling.
BUFFING
Buffing by dual screen cloth structure
is the last step to make perfect edge
banding to make the edge shining, more stable.
2 optional functions
Corner rounding
Cut the four corners of the edging
into arcs.
Pre-milling
Cut the burrs off the planks
before edge banding.
