Quick Details
-
Model Number:
-
MGNG500
-
Rated Voltage:
-
400/230V
-
Rated Current:
-
1800A
-
Speed:
-
1500/1800rpm
-
Frequency:
-
50/60HZ
-
Engine brand:
-
WEICHAI
-
Engine model:
-
12M26D605E300NG
-
Alternator Brand:
-
Stanford
-
Gas type:
-
Natural Gas Biogas Lpg
-
Cooling method:
-
Water Cooled Method
-
Start method:
-
Electric Start
-
Product name:
-
Natural Gas Generator
-
Engine Type:
-
Gas Engine
-
Gas Fuel:
-
Natuaral Gas
Quick Details
-
Warranty:
-
1year, 1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MG
-
Model Number:
-
MGNG500
-
Rated Voltage:
-
400/230V
-
Rated Current:
-
1800A
-
Speed:
-
1500/1800rpm
-
Frequency:
-
50/60HZ
-
Engine brand:
-
WEICHAI
-
Engine model:
-
12M26D605E300NG
-
Alternator Brand:
-
Stanford
-
Gas type:
-
Natural Gas Biogas Lpg
-
Cooling method:
-
Water Cooled Method
-
Start method:
-
Electric Start
-
Product name:
-
Natural Gas Generator
-
Engine Type:
-
Gas Engine
-
Gas Fuel:
-
Natuaral Gas
Product Description
China 100kw 500kw biomass gasifier stove system charcoal coal biomass gasification power generation plant equipment
Natural Gas Generators
A widely used and efficient way to generate electricity is by using natural gas generators. Natural gas can be used in both
emergency and portable generators and is considered one of the most economical and efficient fuels among non-renewable power generation resources. Coal may be the only fuel that is less expensive in terms of affordability. However, one of the biggest disadvantages of coal is that it is a high pollutant.
Natural gas is usually obtained in a similar manner to drilling oil. The liquid form is then transported to various areas where it is converted to a gaseous form. Afterwards, one can obtain it through pipes and cylinders.
GAS ENGINE BRAND
Specification
|
Generator Set
|
Rated Power
|
20kw-1000kw
|
|
|
|
Rated Voltage
|
400V/380/230V/220V (customizable)
|
|
|
|
Rated Frequency
|
50Hz/60Hz
|
|
|
|
Rated Current
|
36~1800A
|
|
|
|
Type
|
Open/Silent/Soundproof/Container
|
|
|
Gas Engine
|
Engine Brand
|
Cummins, YuChai, WEICHAI, Ricardo, Jichai
|
|
|
Alternator
|
Type
|
Brushless
|
|
|
|
Brand
|
Stamford,Leory Somer,LongYuan, etc.
|
|
|
|
Connection
|
3-pahse, 4-wire
|
|
|
Controller
|
Type
|
Auto PLC Controller
|
|
|
|
Brand
|
Deepsea, SmartGen,etc.
|
|
|
Fuel
|
|
Natural gas/CNG/LNG/LPG/Biogas/Biomass gas
|
|
|
Application
|
|
Mines, Building, Oil Fields, Hospitals, Schools, Ports, Hotels, etc.
|
|
|
Delivery Time
|
|
7-10days
|
|
|
Warranty
|
|
12 months or 1500 running hours (subject to the earlier)
|
|
|
Requirments for gas
|
|
1.Impurities content≤30mg/Nm³, size≤5μm, no free water.
|
|
|
|
|
2.Acceptable fuel gas pressure: 2kPa ~10 kPa, C3H8≥80%.
|
|
|
|
|
3.Impurities content≤30mg/Nm³
|
|
|
|
|
Excessive sulfur content can cause serious damage to engine components
|
|
|
Approximate Natural Gas Consumption Chart
|
|
|
|
|
||||
|
This chart approximates the fuel consumption* of a natural gas generator based on the size of the generator and the load at which the generator is operating at. Please note that this table is intended to be used as an estimate of how much fuel a generator uses during operation and is not an exact representation due to various factors that can increase or decrease the amount of fuel consumed. Just for reference only
|
|
|
|
|
||||
|
Generator Size (kW)
|
1/4 Load (ft3/hr)
|
1/2 Load (ft3/hr)
|
3/4 Load (ft3/hr)
|
Full Load (ft3/hr)
|
||||
|
20
|
157
|
188
|
247
|
289
|
||||
|
30
|
202
|
260
|
348
|
416
|
||||
|
40
|
246
|
333
|
449
|
543
|
||||
|
60
|
334
|
479
|
652
|
798
|
||||
|
75
|
400
|
588
|
803
|
990
|
||||
|
100
|
510
|
771
|
1056
|
1308
|
||||
|
125
|
621
|
953
|
1308
|
1627
|
||||
|
135
|
665
|
1026
|
1409
|
1754
|
||||
|
150
|
731
|
1135
|
1561
|
1946
|
||||
|
175
|
841
|
1317
|
1813
|
2264
|
||||
|
200
|
952
|
1500
|
2066
|
2583
|
||||
|
230
|
1084
|
1718
|
2369
|
2965
|
||||
|
250
|
1172
|
1864
|
2571
|
3220
|
||||
|
300
|
1393
|
2229
|
3076
|
3857
|
||||
|
350
|
1614
|
2593
|
3581
|
4495
|
||||
|
400
|
1834
|
2958
|
4086
|
5132
|
||||
|
500
|
2276
|
3687
|
5096
|
6407
|
||||
|
600
|
2717
|
4416
|
6107
|
7681
|
||||
|
750
|
3379
|
5509
|
7622
|
9593
|
||||
|
1000
|
4482
|
7332
|
10147
|
12780
|
||||
Packing & Delivery
plywood or according the customer requirement for 40kw Natural gas/biogas/gas generator with stamford alternator
