Quick Details
-
Brand Name:
-
DAIPU
-
Model Number:
-
PSC-12SK
-
Product Name:
-
PSC-12SK
Quick Details
-
Type:
-
Video Conference System, PTZ Camera
-
Function:
-
Video conference PTZ camera
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DAIPU
-
Model Number:
-
PSC-12SK
-
Product Name:
-
PSC-12SK
Specification
|
Camera Parameter
|
|
|
|
|||
|
Model
|
PSC-12SK
|
|
|
|||
|
FOV
|
5.2° (N)~62°(W)
|
|
|
|||
|
Optial Zoom
|
12X
|
|
|
|||
|
Effective Pixels
|
8million, 1/2.8-inch CMOS sensor
|
|
|
|||
|
Video Format
|
HDMI/USB: 4KP30、1080P60
|
|
|
|||
|
Interface
|
|
|
|
|||
|
Product Interface
|
HDMI,3G-SDI,LAN(POE),USB3.0,RS232-IN,RS232-OUT
|
|
|
|||
|
Network Protocol
|
RTSP, RTMP, ONVIF, GB/T28181, VISCA OVER IP, IP VISCA, RTMPS, SRT
|
|
|
|||
|
Control Interface
|
RS232-IN,RS232-OUT,RS422 compatible with RS485
|
|
|
|||
Product Description
3G-SDI
Connect to an SDI device up to 330ft such as a video production switcher or a video display at resolutions up to 3G(1080P@60Hz) over SDI cabling.
HDMI
Connect to an HDMI device such as a video production switcher or a video display up to 1080@60Hz.
USB 3.0
Connect USB 3.0 type B cable to a PC for plug &play connectivity for any conferencing service like Skype or Zoom,supporting resolution up to 1080p@60Hz.
LINE IN
Connect external audio sources such as a microphone or small audio mixer to embed the sound into all video output interfaces.
RS232,RS422/485
Connect cascading RS-232 or RS-422/485 to control the camera(s) with a joystick controller.
LAN-NDI|HX 2
Connect to a network switch via CAT6 cable to supply power (PoE), control (TCP/IP or webGUI) and stream (NDI|HX 2).
DC12V
Connect supplied 12V power adapter.
HDMI
Connect to an HDMI device such as a video production switcher or a video display up to 1080@60Hz.
USB 3.0
Connect USB 3.0 type B cable to a PC for plug &play connectivity for any conferencing service like Skype or Zoom,supporting resolution up to 1080p@60Hz.
LINE IN
Connect external audio sources such as a microphone or small audio mixer to embed the sound into all video output interfaces.
RS232,RS422/485
Connect cascading RS-232 or RS-422/485 to control the camera(s) with a joystick controller.
LAN-NDI|HX 2
Connect to a network switch via CAT6 cable to supply power (PoE), control (TCP/IP or webGUI) and stream (NDI|HX 2).
DC12V
Connect supplied 12V power adapter.
