Quick Details
-
Brand Name:
-
CB
-
Model Number:
-
LDS-5
-
Max load:
-
5Kn
-
Tensile space:
-
0-650mm
-
Test speed range:
-
0~300 mm/min
-
Resolution:
-
1/50000
-
Displacement resolution:
-
0.01mm
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
Electronic
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CB
-
Model Number:
-
LDS-5
-
Max load:
-
5Kn
-
Tensile space:
-
0-650mm
-
Test speed range:
-
0~300 mm/min
-
Resolution:
-
1/50000
-
Displacement resolution:
-
0.01mm
Applications
Table single arm testing machine is suitable for metal, adhesive, pipe, profile, aerospace, petrochemical, waterproof coil, wire and cable, textile, fiber, rubber, ceramics, food, pharmaceutical packaging, geotextile, film, wood, paper and other manufacturing industries. Product quality supervision departments at all levels are also applicable to teaching demonstration work in colleges and universities.
|
Product Name |
Universal strength testing machine |
|
WDS-2Model |
LDS-5 |
|
Angle accuracy |
0.1° |
|
Load weight |
5Kn |
|
Displacement resolution |
0.01mm |
|
Resolution |
1/50000 |
|
Test speed |
0~300 mm/min |
|
Data sampling frequency |
200times/sec |
|
Board travel |
750mm |
|
Effective stretching space distance |
0-650mm |
|
Size |
420×275×1480(mm) |
|
Machine Weight |
150Kg |
|
MOQ |
1 set |
1. The speed control system adopts stepping motor and speed reducer, and the performance is stable and reliable. It has protection devices such as over-current, over-voltage, overload and so on.
2. The transmission part adopts circular-arc synchronous toothed belt, precision screw auxiliary transmission, smooth transmission, low noise and high transmission efficiency.
3. Touch health mode of operation, real-time LCD display, overcoming the old-fashioned digital display easy to malfunction problems, and elegant, convenient and quick.
1. Appearance adopts surface cold plate electrostatic spray pattern, simple and generous, inherently multifunctional and economical and practical;
2. Force value digital liquid crystal display, LCD interface is clear and easy to read;
3. Two units of measurement: N-KN optional;
4.LCD liquid crystal display with backlight, can be used in low light environment;
5. A single measurement, you can read the peak of the pull, and can be automatically and manually cleared;
6. With travel limit and overload stop function.
7. The floor-standing single-column tension machine is beautiful and exquisite, economical and practical;
1.Response within 24 hours for any problem.
2.Lifelong after sales service & maintenance.
3.Our products are equipped with more than 100 different sample holders for users to choose, which can meet the testing requirements of more than 1000 kinds of materials.
4.Installation and training service is available.
5.According to different user materials, Chuanbai also provides customized services to meet different users' needs
