Autel MaxiCOM MK808TS TPMS Diagnostic Tool Update Online Tyre Pressure Monitor Sensor Tyre Sensor Function MK 808TS

Autel MaxiCOM MK808TS TPMS Diagnostic Tool Update Online Tyre Pressure Monitor Sensor Tyre Sensor Function MK 808TS

FOB Reference Price: Get Latest Price

≥1 Sets

US $650

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: AUTEL

Model Number:: Autel MaxiCOM MK808TS

Warranty:: 12 Months

Certification:: CE

Product Name:: Autel MaxiCOM MK808TS Autel Scanner

Keywords:: Autel MaxiCOM MK808TS

MK808TS:: TPMS Diagnostic Tool With Wifi

MK 808TS Tablet:: 8" capacitive HD touch screen

Autel MaxiCOM MK808TS:: Support Online Update

Function:: Basic Dianostic + TPM + Tyre Sensor

Autel MK808TS:: Tyre Pressure Monitor Sensor Professional Diagnostic Tool

Autel MaxiCOM 808TS TPMS Diagnostic Tool:: Android operating system

MK808TS Car Scanner:: With TPMS Function, can replace TS501

New Arrival from Autel:: Better than TS401 TS501 TS601

Quick Details

Voltage:: V

Power:: W

Applicable Models:: Cover all Asian,Euro and American cars

Place of Origin:: Guangdong, China

Brand Name:: AUTEL

Model Number:: Autel MaxiCOM MK808TS

Warranty:: 12 Months

Certification:: CE

Product Name:: Autel MaxiCOM MK808TS Autel Scanner

Keywords:: Autel MaxiCOM MK808TS

MK808TS:: TPMS Diagnostic Tool With Wifi

MK 808TS Tablet:: 8" capacitive HD touch screen

Autel MaxiCOM MK808TS:: Support Online Update

Function:: Basic Dianostic + TPM + Tyre Sensor

Autel MK808TS:: Tyre Pressure Monitor Sensor Professional Diagnostic Tool

Autel MaxiCOM 808TS TPMS Diagnostic Tool:: Android operating system

MK808TS Car Scanner:: With TPMS Function, can replace TS501

New Arrival from Autel:: Better than TS401 TS501 TS601

Autel MaxiCOM MK808TS TPMS Diagnostic Tool Update Online Tyre Pressure Monitor Sensor Tyre Sensor Function MK 808TS

Quick Detail of Autel MaxiCOM MK808TS:

Autel MaxiCOM MK 808TS Tyre Pressure Monitor Sensor Function: Basic Dianostic + TPM + Tyre Sensor

100% Original, Autel Authorized Distributor

Update Online with Wifi, Support Multi Languages

Exclusive(Sole) Agent

Product Description

New Arrival Original Autel MaxiCOM MK808TS Professional TPMS Diagnostic Tool

Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MaxiCOM MK808TS provides superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), BMS (Battery Management System) and DPF (Diesel Particulate Filter). In addition to OBD II diagnostics and special functions, MK808TS can perform comprehensive TPMS services with ease.

There are two main components of the MK808TS system:
l MK808TS Display Tablet – the central processor and monitor for the system.
l MaxiVCI Mini (Vehicle Communication Interface) – the device for accessing vehicle data.

Autel MaxiCOM MK 808TS Display Tablet

MK808TS Tablet Main Unit Functional Description

1. 7.0” LCD Capacitive Touch screen
2. Ambient Light Sensor – detects ambient brightness.
3. Power LED – indicates battery level & charging or system status.
4. TPMS Service Symbol – indicates the position of the embedded TPMS antenna.

5. Collapsible Stand – extends from the back to allow hands-free viewing of the Display Tablet.
6. Heat Sink
7. MaxiVCI Mini Holder
8. Built-in Battery

9. Mini USB OTG Port
10. Micro SD Card Slot – holds the micro SD card.
11. HDMI (High-Definition Multimedia Interface) Port
12. USB Port
13. Lock/Power Button – turns the device on & off with long press, or locks the screen with short press.

MK 808TS Main Unit Technical Specifications

Recommended Use	Indoor
Operating System	AndroidTM 4.4.2, KitKat
Processor	Cortex-A9 processor (1.5 GHz)
Memory	32GB
Display	7-inch LCD capacitive touchscreen with 1024 x 600 resolution
Connectivity	l Mini USB 2.0 l USB 2.0 l Wi-Fi l HDMI Type A l Micro SD card (supports up to 32GB)
Sensors	Light sensor for brightness auto changing
Audio input/output	l Input: N/A l Output: buzzer
Power and Battery	l 3.7 V/5000 mAh lithium-polymer battery l Charges via 5 VDC power supply
Audio input/output	l Input: N/A l Output: buzzer
Power and Battery	l 3.7 V/5000 mAh lithium-polymer battery l Charges via 5 VDC power supply
Tested Battery Life	Around 7 hours of continuous use
Battery Charging Input	5 V/1.5 A
Power Consumption	600 mA (LCD on with default brightness, Wi-Fi on) @3.7 V
Operating Temprature	-10 to 60°C(14 to 140°F)
Storage Temprature	-20 to 70°C (-4 to 158°F)
Operating Humidity	5% - 95% non-condensing
Dimensions (W x H x D)	270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”)
Net Weight	885 g (2.31 lb.)
Protocols	ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610,GM UART,UART Echo Byte Protocol, H - onda Diag-H Protocol, TP2.0, TP1.6

Autel MaxiCOM MK808TS VCI – Vehicle Communication Interface

The wireless diagnostic interface MaxiVCI Mini is a small vehicle communication interface (VCI) used to connect to a vehicle’s data link connector (DLC) and connect wirelessly with the tablet for vehicle data
transmission.

MK808TS VCI Module Functional Description

1. Vehicle Data Connector (16-Pin) – connects the MaxiVCI Mini to the vehicle’s 16-pin DLC directly.
2. Power LED
3. Connection LED
4. USB Port – provides the easiest connection between the device and the tablet via a USB cable.

VCI Technical Specifications:

Communications	· BT V.2.1 + EDR · USB 2.0
Wireless Frequency	2.4 GHz
Input Voltage Range	12 VDC to 24 VDC
Supply Current	150 mA @ 12 VDC
Operating Temperature	0°C to 50°C (ambient)
Storage Temperature	-20°C to 70°C (ambient)
Dimensions (L x W x H)	47 mm (1.7”) x 23 mm (0.9”) x 51 mm (2.0”)
Weight	33.1g (0.07 lb.)
