13mm thickness all weather fully cast in site spray coating polyurethane synthetic running track system equivalent to synthetic consist of 10mm thick resilient cushion layer of polyurethane (PU) bonded with SBR granules by paving machine and red ethylene propylene diene monomer( EPDM) granules size 1-2mm sprayed to permanently embedded on top of SBR cushion layer.
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
IS01
-
Product Name:
-
IAAF Tartan Track
-
System:
-
Spray Coat System
-
Material:
-
sbr granules , epdm granules , pu binder , pu top coating
-
Height:
-
13mm as international standard
-
Application:
-
Running Track , Rubber Playground
-
MOQ:
-
500 sqm
-
Feature:
-
Permeable , waterproof
-
Warranty:
-
1 year
-
Service Life:
-
8-10 Years
Quick Details
-
Color:
-
Red, Red, Green, Blue, etc.
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ISun
-
Model Number:
-
IS01
-
Product Name:
-
IAAF Tartan Track
-
System:
-
Spray Coat System
-
Material:
-
sbr granules , epdm granules , pu binder , pu top coating
-
Height:
-
13mm as international standard
-
Application:
-
Running Track , Rubber Playground
-
MOQ:
-
500 sqm
-
Feature:
-
Permeable , waterproof
-
Warranty:
-
1 year
-
Service Life:
-
8-10 Years
Products Description
Spray Coat System Running Track
|
Test Item
|
|
Standard
|
Test Data
|
Judge
|
|||
|
Thickness mm
|
|
≥13
|
15
|
Standards
|
|||
|
Force
Reduction
|
0℃
|
35-50
|
38.5
|
Standards
|
|||
|
|
20℃
|
|
41.3
|
Standards
|
|||
|
Vertical
Deformation
|
0℃
|
0.6-2.5
|
1.85
|
Standards
|
|||
|
|
20℃
|
|
2.08
|
Standards
|
|||
|
Tensile Strength Mpa
|
|
≥0.4
|
0.85
|
Standards
|
|||
|
Elongation at Break %
|
|
≥40
|
102.1
|
Standards
|
|||
|
Skid Resistance BPN20℃
|
|
≥47
|
57
|
Standards
|
|||
|
Conclusion
|
|
All test item cater to IAAF certification
requirement |
|
|
|||
Materials Composition
EPDM Granules
1. High Elongation
2. Fresh Color
3. Anti-aging
4. UV-Resistance
5. Non Color Fading
6. Eco Friendly
PU Binder
1. Adhesive for sbr or epdm granules
2. Free solvent
3. Non yellowing
4. 100% polymer
5. moisture curing
6. Curing at room temperature
PU Pigment Adhesive
1. use as sealer , self-leveling , top coating of running track flooring
2. Color can be customized
3. UV-Resistance
4. Anti-aging
5. Non Color Fading
Package & Loading
EPDM Rubber Granules Package
Rubber granules packed in 25kg/ bag , 1000kg/ bag
20 tons/ 20GP Container
PU Liquid Materials Package
Liquid PU materials packed in barrel ，like 200kg/drum, 250kg/ drum ,20kg/ barrel, 30kg/ barrel, etc.
16 tons-21Tons / 20GP Container
More Application
Sports Court Surface Coating Apply
1. Basketball court flooring coating
2. Tennis court flooring coating
3. Badminton court surface coating
4. Futsal Court flooring
5. Multi-purposed sports court coating
6. Leisure Area soft flooring coating
Running Track Surface Coating Apply
1. School playground rubber surface
2. Military exercise playground flooring
3. Public park jogging track
4. Community walk path
5. Stadium track and field
6. Sports center athletic running track
EPDM Rubber Flooring
1. Children safety playing rubber flooring
2. Community walk path
3. public jogging track
4. non-standard running track flooring
5. swim pool deck flooring
