Quick Details
-
RAL Code:
-
RAL 9006
-
Gloss:
-
55%
-
Color:
-
White Aluminium
-
Hardness:
-
>=F
-
Flexibility:
-
3mm
-
Film thickness:
-
80 mm
-
Impact resistance:
-
>=50 cm
-
Cupping test:
-
>=6 mm
-
Color difference:
-
<=0.5
Quick Details
-
CAS No.:
-
n/a
-
Place of Origin:
-
China
-
Name:
-
powder coating
-
RAL Code:
-
RAL 9006
-
Gloss:
-
55%
-
Color:
-
White Aluminium
-
Hardness:
-
>=F
-
Flexibility:
-
3mm
-
Film thickness:
-
80 mm
-
Impact resistance:
-
>=50 cm
-
Cupping test:
-
>=6 mm
-
Color difference:
-
<=0.5
1.High quality products, superior customer service
WANAN Powder Coating believes that what sets it apart from its competitors is a unique manufacturing process and a commitment to impeccable client service.
All products are treated in a quality controlled environment, in which every element is scrupulously monitored to create a superior end-product. This ensures that WANAN’s powder coating is among the toughest on the market, providing many years of rust-resistant, durable and attractive coating that can be applied to almost any metal product. All products and services are tailored to clients’ individual needs, from the specific colour required to the high-quality finishes and fast turn-around times. This personalised and highly efficient customer service has cemented WANAN’s reputation as one of the foremost power coaters in China.
2.Competitive prices & wide choice of colours
Thanks to WANAN’s competitive prices, fantastic sales support and wide range of colours, the company remains one of the top powder coaters in China – and continues to grow every year. Contact us now to discuss your specific powder coating requirements, or learn more about our powder coating services and colours.
Skype: lydia.yip1 Tel/ Wechat/ Whatsapp: + 86 13434797980
3.Professional powder coating services
WANAN provides professional powder coating services to private and corporate clients across all over the world. We offer competitive rates on all our powder coating services, and pride ourselves on our fast turn-around times, friendly service and exceptional attention to detail. Choose WANAN for:
-
Powder coating for the widest range of products: Household, automotive, commercial and industrial goods
-
Superior quality: Our high quality powder coating outlasts most other types of paint on the market
-
Personalised attention: Customised colour matching and friendly, efficient service. ntact Us Now!
| Description | Powder coating | |
| Another Name |
Powder paint,Electrostatic powder coating, Thermosetting powder coating |
|
| Type | polyester, epoxy polyester | |
| Main Material | Saturated polyester resin and hardner | |
| Surface Type | Gloss,satin,matte,dull,wrinkle,checkered,sand grain,transparent | |
| semitransparent,metallic,and special pattern. | ||
| Advantage | Good adhesion,good mechanical property,strong coating film, | |
| smooth film,high gloss,UV resistance,weather resistance. | ||
| Application Field | Outdoor or indoor use | |
| Household appliance:air conditioner outdoor unit, | ||
| electric appliance,lighting sets. | ||
| Construction:curtain wall,door and window profile,ceiling. | ||
| Traffic facility:road barrier,highway barrier,fence. | ||
| Other field:auto parts,sport facility,fitness equipment, | ||
| gas station equipment,yard facility. | ||
| Application Condition | Electrostatic spray/Triboelectric gun spray. | |
| Recommended curing condition:200 degree centigrade for 12 minutes | ||
| (object surface temperature),range from 190 degree centigrade | ||
| for 20 minutes to 210 degree centigrade for 8minutes. | ||
| Recommended film thickness:50~80um, range from 40~150um | ||
| Physical Property | Specific gravity | 1.4~1.8g/cm3 as per formula and color |
| Particle size | average 35~40um | |
| Test Condition | Substrate | 0.5mm thickness cold rolled steel sheet |
| Pretreatment | Remove rust and grease | |
| Film thickness | 50~80um | |
| Curing temperature | 200 degree centigrade for 12 minutes | |
| Mechanical Property | Pencil hardness | ISO 15184:1998,2H |
| Adhesion (by griding) | GB/T 9286-1998,0grade | |
| Impact test | GB/T 1732-1993,≥50 kg.cm | |
| Bending test | GB/T 6742 ,≤2mm | |
| Cupping test | GB/T 9753,≥7mm | |
| Chemical and Durability Test | Salt spray test | GB/T 1771,≥500 hours,no obvious change , |
| crossion width at cross≤2mm | ||
| Heat and moisture test | GB/T 1740,≥1000 hours,no change | |
| Weather resistance test | GB/T 1865-1997,≥800 hours,discolor ≤2 grade | |
| loss of gloss ≤2 grade,no pulverization, | ||
| no blister,no crack,no spalling | ||
| no other abnormal appearance | ||
| Package | Inside by two-ply PVC bag,outside by carton,net weight 25kg | |
| Storage Condition | Store in dry ventilated room,temperature under 35 degree centigrade, | |
| avoid direct sunlight. | ||
| Shelf Life | Six months | |
| Health and Safty | Raw material of powder coating don't contain toxic substance, | |
| no toxic gas produced during curing.Please wear dust mask in operation | ||
| to avoid inhelation of powder.Please avoide prolonged skin contact | ||
| with powder,wash out powder with soap and water. | ||
