Quick Details
-
Dimension(L*W*H):
-
3520*1670*2050mm
-
Weight:
-
3500kg, 3,560 kg
-
Working Pressure:
-
23bar
-
Air capacity:
-
19m³/min
-
Rated FAD:
-
24 m3/min
-
Rated Pressure:
-
22 bar
-
Engine:
-
228 kW
-
Air End:
-
Single Stage Compression
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ZEGA
-
Model Number:
-
S85T
-
Dimension(L*W*H):
-
3520*1670*2050mm
-
Weight:
-
3500kg, 3,560 kg
-
Working Pressure:
-
23bar
-
Air capacity:
-
19m³/min
-
Rated FAD:
-
24 m3/min
-
Rated Pressure:
-
22 bar
-
Engine:
-
228 kW
-
Air End:
-
Single Stage Compression
| Model |
Working pressure
(Bar) |
Capacity
(m3/min) |
Diesel engine brand |
Power
(kw) |
Air end |
| S60 | 18 | 18 | YUCHAI | 162 | Single stage |
| S85T | 22 | 24 | YUCHAI | 228 | Two stage |
| S95CD | 24 | 29 | YUCHAI | 295 | Two stage |
| S98D | 24 | 30 | YUCHAI | 295 | Two stage |
| S100D | 25 | 30 | YUCHAI | 310 | Two stage |
| S120D | 27 | 37 | XICHAI | 412 | Two stage |
Product Upgrade Features
1. Full series product optimized for stronger frame and better towing protection and safety; stronger roof loading capabilities to meet customer load carry needs with rubber protection strips.
2. All pressure pipes are connected with steel tubes,it has excellent sealing and protect rubber from prevent aging,never wear and has attractive appearance.
3. With Patent designed safety air filter unit and stainless steel air inlet pipes for guaranteed dust filter ability and better protection against dirty air due to rubber hose damage.
4. All new designed cooler with independent modular unit and secured by structural component with cushion pad without any pressure points, effectively eliminating cooler damage by shroud deformation;independent damaged unit replacement made easy without removing the cooler assembly.
5. Diesel portable compressors all with international brand name controller with optimized interface for only 3 switches to operate, power, on and off. Automatic preheating, loading and unloading process, pressure control and engine fuel injection,eliminating high pressure stop and oil outburst. Controller with water and moisture proof.
6. Easy access to all maintenance parts with document and tool box for better management of tools, records and safer for machine operation.
7. Electrical portable machine with breaker and power switch easy to access and protected for convenience and safety.
8. New designed protected cooler for higher efficiency and better safety protection. Full body sound absorbent cotton and rear car silencer designed to make operate noise reduce 40% less than normal products.
Q1 : Wonder if you accept small orders?
A1: Do not worry. Feel free to contact us .in order to get more orders and give our clients more convener ,we accept small order.
Q2 : Can you send products to my country?
A2: Sure, we can. If you do not have your own ship forwarder, we can help you.
Q3 : Can you do OEM for me?
A3: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
Q4 : What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q5 : How can I place the order?
A5: First sign the PI,pay deposit,then we will arrange the production.After finished production need you pay balance. Finally we will ship the Goods.
Q6 : When can I get the quotation ?
A6: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
