Quick Details
-
Model Number:
-
130A10C20C
-
Frequency:
-
50/60HZ
-
Rated Power:
-
1kW
-
Rated Torque:
-
4.8Nm
-
Rated Speed:
-
2000rpm
-
Rated Voltage:
-
3 Phase 220V
-
Poles:
-
8
-
Rated Current:
-
4.0A
-
Kt:
-
1.4Nm/A
-
Ke:
-
83V/Krpm
-
Rotor Intertia:
-
12Kg.cm2
-
Certificated:
-
CE /ISO 9001/2008
Quick Details
-
AC Voltage:
-
380/ 480 V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
synmot
-
Model Number:
-
130A10C20C
-
Frequency:
-
50/60HZ
-
Rated Power:
-
1kW
-
Rated Torque:
-
4.8Nm
-
Rated Speed:
-
2000rpm
-
Rated Voltage:
-
3 Phase 220V
-
Poles:
-
8
-
Rated Current:
-
4.0A
-
Kt:
-
1.4Nm/A
-
Ke:
-
83V/Krpm
-
Rotor Intertia:
-
12Kg.cm2
-
Certificated:
-
CE /ISO 9001/2008
Details
|
Power range
|
0.75kW~3kW
|
|
Rated torque
|
4.8N. m~19.1N. m
|
|
Rated speed
|
1000rpm~3000rpm
|
|
Feature
|
The product specifications are complete and meet the needs of different sub industries. It has been widely used in industries such as injection molding machines, textile machinery, and CNC machine tools.
|
