Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
XINQUAN
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
15m*1.2m*2.3m
-
Power (kW):
-
45
-
Weight:
-
1000 KG
-
After-sales Service Provided:
-
Field maintenance and repair service
-
After Warranty Service:
-
Online support
-
After Warranty Service2:
-
Spare parts
-
After Warranty Service3:
-
Field maintenance and repair service
-
Certification:
-
CE
-
Marketing Type:
-
Hot Product 2023
-
Motor:
-
SIEMENS Brand
-
Inverter:
-
ABB Brand
-
Function:
-
Automatic Profile Making Machine Line
-
Feature:
-
High Production Efficiency
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
30:1
-
Screw Speed (rpm):
-
90 rpm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
XINQUAN
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
15m*1.2m*2.3m
-
Power (kW):
-
45
-
Weight:
-
1000 KG
-
After-sales Service Provided:
-
Field maintenance and repair service
-
After Warranty Service:
-
Online support
-
After Warranty Service2:
-
Spare parts
-
After Warranty Service3:
-
Field maintenance and repair service
-
Certification:
-
CE
-
Marketing Type:
-
Hot Product 2023
-
Motor:
-
SIEMENS Brand
-
Inverter:
-
ABB Brand
-
Function:
-
Automatic Profile Making Machine Line
-
Feature:
-
High Production Efficiency
Product description
|
Model
|
Pipe diameter(mm)
|
Extruder
|
Output (kg/h)
|
|
PE-32
|
Φ4-15
|
SJ-45/30
|
30-120
|
|
PE-63
|
Φ10-35
|
SJ-60/33
|
120-220
|
|
PE-110
|
Φ20-60
|
SJ-65/33
|
150-250
|
|
PE-160
|
Φ50-100
|
SJ-65/33
|
120-270
|
|
PE-250
|
Φ60-150
|
SJ-75/33
|
280-400
|
|
PE-450
|
Φ100-200
|
SJ-90/33
|
450-600
|
|
PE-630
|
Φ150-300
|
SJ-120/33
|
700-950
|
|
PE-800
|
Φ200-500
|
SJ-150/33
|
800-1200
|
Single screw extruder
High efficiency with new design screw
Die and mould
For water supplying pipe production
Forming device
Air cooling,vacuum forming system
Mould
Alloy steel material by high temperature forging
Winder
Double winder for pipe coiling
Corrugated pipe
Best quality final plastic pipe
Product Application
Characteristic & Application
PE/HDPE/PVC corrugated pipe making machine adopts extruding and forming process, the features is reliable-quality and high-efficiency.Compared with other plastic pipe wall structure, corrugated pipe has excellent wall structure design,its low weight reach the lower production cost and improve the market competitiveness.The pipe is widely used in various field instead of concrete pipe and iron pipes,because it has excellent features such as:easy connected and accessories installed,and quality reliable.
The corrugated pipe is mature product which has the advantage of low weight, low cost, anti-corrosion,good ring stiffness and flexibility. Our factory has developed corrugated pipe extrusion line more than 25 years. Have the whole series of double wall corrugated pipe machine: horizontal type, vertical type and shuttle type. The machine can process wide range of material, including HDPE, PP, PVC, etc.
The corrugated pipe is mature product which has the advantage of low weight, low cost, anti-corrosion,good ring stiffness and flexibility. Our factory has developed corrugated pipe extrusion line more than 25 years. Have the whole series of double wall corrugated pipe machine: horizontal type, vertical type and shuttle type. The machine can process wide range of material, including HDPE, PP, PVC, etc.
Production Flow Chart
