Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Nice Power
-
Model Number:
-
PS-605
-
Output Frequency:
-
50HZ/60HZ
-
Output Current:
-
0-5A
-
Product Name:
-
DC power supply
-
Model:
-
PS-605
-
Application:
-
mobile repairing
-
working temperature:
-
0℃~40℃
-
Product:
-
switching power supply
-
Color:
-
Black
-
Warranty:
-
1 year
-
Packing:
-
carton
-
Product Dimension:
-
223x93x145mm
Quick Details
-
Output Power:
-
300W
-
Input Voltage:
-
220V/110V, 230V±10% 50Hz (115V±10% 60Hz)
-
Output Voltage:
-
0-60V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Nice Power
-
Model Number:
-
PS-605
-
Output Frequency:
-
50HZ/60HZ
-
Output Current:
-
0-5A
-
Product Name:
-
DC power supply
-
Model:
-
PS-605
-
Application:
-
mobile repairing
-
working temperature:
-
0℃~40℃
-
Product:
-
switching power supply
-
Color:
-
Black
-
Warranty:
-
1 year
-
Packing:
-
carton
-
Product Dimension:
-
223x93x145mm
Product Description
PS-605 60V 5A Regulated Power Supply PC Circuit Adjustable DC Power Supplies Variable Mobile Switching Supply Led Power 300W
The PS series of adjustable regulated DC power supplies are designed for use in laboratories, schools and production lines. Both output voltage and output current are continuously adjustable between 0 and nominal.
The stability and ripple factor of the power supply are very good and have a perfect protection circuit. Can work at full load for a long time. This power supply can be used as both a regulated power supply and a regulated current supply.
Packing List
1. 1 x power supply
2. 1 x power cord
3. 1 x output load cord
4. 1 x user's manual
5. 1 x warranty card
Specification
|
Model Number
|
PS-305
|
PS-3010
|
PS-605
|
PS-1203
|
|||
|
Output Voltage
|
0~30V
|
0~30V
|
0~60V
|
0~120V
|
|||
|
Output Current
|
0~5A
|
0~10A
|
0~5A
|
0~3A
|
|||
|
Input Voltage
|
230V±10% 50Hz (115V±10% 60Hz)
|
|
|
|
|||
|
Working Temperature
|
0℃~40℃; Relative Humidity: <80%RH
|
|
|
|
|||
|
Storage Temperature
|
-10℃~70℃; Relative Humidity: <70%RH
|
|
|
|
|||
|
Constant Voltage State
|
Voltage stability ≤ 0.1%+3mV Low Voltage: 0.2~0.3%+3mV
|
|
|
|
|||
|
|
Load stability ≤ 0.5%+3mV
|
|
|
|
|||
|
|
Ripple noise ≤ 30mVrms
|
|
|
|
|||
|
Constant Voltage State
|
Current stability ≤ 0.2%+3mA
|
|
|
|
|||
|
|
Load stability ≤ 0.2%+3mA
|
|
|
|
|||
|
|
Ripple noise ≤ 20mArms (valid value)
|
|
|
|
|||
|
Display Accuracy
|
0.5%±2digits
|
|
|
|
|||
|
Display Resolution
|
Voltage: 00.01V Current: 0.001A
|
|
|
|
|||
|
Product Dimension
|
223mm(L) x 93mm(W) x 145mm(H)
|
|
|
|
|||
|
Product Weight
|
1.9kg
|
1.9kg
|
1.9kg
|
1.9kg
|
|||
|
Fuse Standard
|
3A (AC220V Input) / 5A (AC110V Input)
|
|
|
|
|||
