- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Lei Na
-
Running Speed:
-
0-25m/min (Optional)
-
Electric drive:
-
motor drive
-
Function:
-
Heavy material transportation
-
Site:
-
Customized
-
Application:
-
Material handling/steel coil/industrial
-
Load capacity:
-
1-300T(Customized)
-
After Warranty Service:
-
Lifetime technical support
-
Advantage:
-
Easy Operation
-
MOQ:
-
1 SET
-
Brand:
-
Lei Na
Quick Details
-
Warranty:
-
2 years
-
Weight (KG):
-
6500
-
Marketing Type:
-
Hot Product 2023
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Lei Na
-
Running Speed:
-
0-25m/min (Optional)
-
Electric drive:
-
motor drive
-
Function:
-
Heavy material transportation
-
Site:
-
Customized
-
Application:
-
Material handling/steel coil/industrial
-
Load capacity:
-
1-300T(Customized)
-
After Warranty Service:
-
Lifetime technical support
-
Advantage:
-
Easy Operation
-
MOQ:
-
1 SET
-
Brand:
-
Lei Na
Product Description
|
Rated load capacity(t)
|
10
|
|
|
Platform size(m)
|
4.5*2.2
|
|
|
Height(m)
|
0.6
|
|
|
Running speed
|
0-20m/min (Optional)
|
|
|
Power supply method
|
Rail/Cable Drum/Cable Reel/Battery
|
|
|
Running distance(m)
|
Handle OR Remote Control
|
|
|
Climbing angle
|
Customized
|
|
|
The above parameters and dimensions can be customized according to your specific usage on site.
|
|
|
Specification
|
model
|
KPX-2t
|
KPX-16t
|
KPX-25t
|
KPX-30t
|
KPX-50t
|
KPX-80t
|
KPX-100t
|
KPX-150t
|
||||||||
|
Rated load capacity (t)
|
2
|
16
|
25
|
30
|
50
|
80
|
100
|
150
|
||||||||
|
Platform size(m)
|
2*1.5*0.15
|
4*2*0.55
|
4.5*2.2*0.6
|
4.5*2.2*0.6
|
5.5*2.4*0.65
|
6*2.6*0.8
|
6.5*2.8*0.9
|
10*3*1.2
|
||||||||
|
Track width(m)
|
1.2
|
2.8
|
3.2
|
3.2
|
4.2
|
4.7
|
4.9
|
7
|
||||||||
|
Rail inner distance(m)
|
1.2
|
1.4
|
1.4
|
1.4
|
1.4
|
1.8
|
2
|
2
|
||||||||
|
Wheel Dia.(m)
|
Φ0.27
|
Φ0.35
|
Φ0.4
|
Φ0.4
|
Φ0.5
|
Φ0.6
|
Φ0.6
|
Φ0.6
|
||||||||
|
Number of wheels(pieces)
|
4
|
4
|
4
|
4
|
4
|
4
|
4
|
8
|
||||||||
|
Ground clearance(mm)
|
50
|
50
|
50
|
50
|
50
|
75
|
75
|
75
|
||||||||
|
Running speed(m/min)
|
0-25
|
0-20
|
0-20
|
0-20
|
0-20
|
0-20
|
0-20
|
0-18
|
||||||||
|
Motor power(kW)
|
1
|
2
|
3
|
3.5
|
5
|
8
|
10
|
15
|
||||||||
|
Battery Capacity(Ah)
|
180
|
180
|
250
|
250
|
330
|
400
|
440
|
600
|
||||||||
|
Battery voltage(V)
|
24
|
48
|
48
|
48
|
48
|
72
|
72
|
72
|
||||||||
|
continuous running time(h)
|
4.32
|
4.3
|
4
|
3.5
|
3.3
|
3.6
|
3.2
|
2.9
|
||||||||
|
Range(km)
|
6.5
|
5.1
|
4.8
|
4.2
|
4
|
4.3
|
3.8
|
3.2
|
||||||||
|
Maximum wheel pressure(KN)
|
14.4
|
64.5
|
94.5
|
110.4
|
174
|
278.4
|
343.8
|
265.2
|
||||||||
|
Reference weight(t)
|
2.8
|
5.5
|
6.5
|
6.8
|
8
|
12.8
|
14.6
|
26.8
|
||||||||
|
Recommended track model
|
P15
|
P24
|
P38
|
P38
|
P43
|
P50
|
QU100
|
QU100
|
||||||||
|
Explanation:
1.Load capacity, table size, and rail inner distance can be designed and manufactured according to customer needs; 2.Optional wireless remote control device (domestic or imported); 3.Optional automatic stop and limit device when encountering people; 4.Optional maintenance free batteries, lithium batteries, explosion-proof batteries, high-temperature batteries, etc; 5.Optional DC brushed motor and DC brushless motor; 6.It can be optionally equipped with domestic and imported appliances. |
|
|
|
|
|
|
|
|
||||||||
