Quick Details
-
Housing Color:
-
Silver
-
Warranty:
-
2 Years
-
Material:
-
304 Stainless Steel
-
Certificate:
-
CE Approved
-
MTBF:
-
10,000,000 times
-
Feature:
-
Anti-push
-
Working environment:
-
-25℃~+70℃
-
Motor Power:
-
50W
-
Application:
-
Security Access Control Management
-
Keyword:
-
Speed gate
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WEJOIN
-
Model Number:
-
ST301
-
Housing Color:
-
Silver
-
Warranty:
-
2 Years
-
Material:
-
304 Stainless Steel
-
Certificate:
-
CE Approved
-
MTBF:
-
10,000,000 times
-
Feature:
-
Anti-push
-
Working environment:
-
-25℃~+70℃
-
Motor Power:
-
50W
-
Application:
-
Security Access Control Management
-
Keyword:
-
Speed gate
Product Description
|
No.
|
Item
|
Functions & Features
|
|
1
|
Motor
|
Self-developed tubular two-stage planetary gear reducer structure, driven by DC permanent magnet motor, compact structure, large
torque, low noise and wear resistance.
|
|
2
|
Control System
|
Self-developed servo control system, precise control, more flexible running, less mechanical impact and longer service life.
|
|
3
|
Technology
|
Frequency conversion technology, running speed adjustable, automatic opening when power off, meet different access requirements
and have a better experience.
|
|
4
|
Anti-push
|
Self-adaptive anti-push function, high transformation ratio gear box, increasing torque for strengthen resistance and the
stability, reducing the failure rate and cost pressure.
|
|
5
|
Wing
|
Acrylic or tempered glass optional, shape, size or color can be customized.
|
|
6
|
RS232 Communication Module
|
Support
|
|
7
|
Modbus Protocol
|
Support
|
|
8
|
Voice Function
|
Support
|
|
9
|
Trumpet
|
Optional
|
|
10
|
DC12V Backup Battery
|
Optional
|
Technical Data：
1. Working Temperature: -25℃～+70℃
2. Power Supply: AC110/220V±10%
3. Input Voltage of Controller: DC24V ±10%
4. Working Voltage of Motor: DC24V
5. Motor Power: 50W
6. Relative Humidity: 90% (no condensation)
7. Material of Cabinet: 304 stainless steel, sheet metal spraying process
8. Width of Passage: 600~1100mm (a pair)
9. Opening & Closing Speed: 0.2~1 seconds adjustable
10. MTBF:
10,000,000 times
ST301
ST302
ST303
