Quick Details
-
Brand Name:
-
Yuanda Boiler
-
Dimension(L*W*H):
-
depends on boiler model
-
Weight:
-
3~50ton
-
product name:
-
Thermal oil boiler capacity 1000000 kcal/h with oil burner
-
Application field:
-
food factory, dyeing,wood processing,etc
-
color:
-
blue,red,sliver
-
capacity:
-
300,000kcal to 12,000,000kcal
-
boiler output:
-
high temperature
-
quality control:
-
X-ray inspection, etc
-
fuel consumption:
-
low ,energy-saving
-
fuel burning style:
-
chamber combustion
-
Efficiency:
-
92-98%
-
company type:
-
manufacturer founded in 1956
Quick Details
-
Core Components:
-
boiler main part
-
Steam Production:
-
350kw to 14000kw
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yuanda Boiler
-
Dimension(L*W*H):
-
depends on boiler model
-
Weight:
-
3~50ton
-
product name:
-
Thermal oil boiler capacity 1000000 kcal/h with oil burner
-
Application field:
-
food factory, dyeing,wood processing,etc
-
color:
-
blue,red,sliver
-
capacity:
-
300,000kcal to 12,000,000kcal
-
boiler output:
-
high temperature
-
quality control:
-
X-ray inspection, etc
-
fuel consumption:
-
low ,energy-saving
-
fuel burning style:
-
chamber combustion
-
Efficiency:
-
92-98%
-
company type:
-
manufacturer founded in 1956
Thermal oil boiler capacity 1000000 kcal/h with oil burner
| Model |
YY(Q)W- 350Y(Q) |
YY(Q)W- 700Y(Q) |
YY(Q)W- 1400Y(Q) |
YY(Q)W- 2100Y(Q) |
YY(Q)W-3000Y(Q) |
YY(Q)W- 3500Y(Q) |
YY(Q)W- 4200Y(Q) |
YY(Q)W-5600Y(Q) | YY(Q)W-7000Y(Q) | ||
| Capacity | KW | 350 | 700 | 1400 | 2100 | 3000 | 3500 | 4200 | 5600 | 7000 | |
| Rated working pressure | Mpa | 0.8 | |||||||||
| Heat carrier output/inlet temperature | ℃ | 280/250; 320/290 | |||||||||
|
Design thermal effiency |
% | >96 | |||||||||
|
Fuel con sump. |
Natural gas | Nm3/h | 42.13 | 84.26 | 169.11 | 259.6 | 369.57 | 431.92 | 516.38 | 676.5 | 830.73 |
| Diesel | kg/h | 34.5 | 69.1 | 138.78 | 212.52 | 302.39 | 353.31 | 422.57 | 560.24 | 673.82 | |
| Size | Meter |
3000 *1000 *2000 |
3200 *1300 *2050 |
3710 *1524 *2150 |
5600 *2400 *3170 |
5600 *2400 *3170 |
5900 *2382 *3560 |
6630 *3200 *3050 |
7200 *3550 *3920 |
8090 *3675 *4000 |
|
| Weight | Ton | 2.0 | 3.0 | 4.0 | 6 | 10 | 10.2 | 16.5 | 23.6 | 28 | |
For buying a boiler, customers cares most is boiler's quality,energy consumption and boiler maintanance, our boiler sloves these easily.
For our thermal oil boiler's good quality and our company's good after sales service, we have hundreds of projects all around the world. They are mainly used in plywood factory,bitumen(asphalt) factory, textile factory, refinery factory,food factory,etc.
1. Way of delivery: by Sea or Railway or truck based on needs
2. Shipping model: by normal container and flat rack or bulk cargo based on differnent capacity. We have stable and experienced cooperate shipping company, and we will suggest suitable container.
3. Customers specifying freight forwarders or we send bottom shipping price from our forwarder partner for your reference, negotiable shipping methods.
4. Packing: nude for boiler main part in nude, accessories in export-use wooden box.
5. Payment Terms: T/T, LC; 30% deposits; 70% balance before delivery.
