Quick Details
-
Model Number:
-
T522B
-
Max. Current:
-
15A/20A
-
Mechanical Life:
-
50000 cycles, 50000 Cycles
-
Rating Current:
-
15A 250V 20A 125V
-
Position:
-
2 Position
-
Motor Load:
-
400W 125V (singlephase)
-
Terminal type:
-
Screw Terminal
-
Switch Type:
-
SPST
-
Material:
-
Metal, Plastic
-
Mounting Hole:
-
M12
-
Operating Temp:
-
-25°C to +85°C
-
Product type:
-
Toggle switches
-
Certification:
-
CE CCC
Quick Details
-
Max. Voltage:
-
250V/125VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OENGOL
-
Model Number:
-
T522B
-
Max. Current:
-
15A/20A
-
Mechanical Life:
-
50000 cycles, 50000 Cycles
-
Rating Current:
-
15A 250V 20A 125V
-
Position:
-
2 Position
-
Motor Load:
-
400W 125V (singlephase)
-
Terminal type:
-
Screw Terminal
-
Switch Type:
-
SPST
-
Material:
-
Metal, Plastic
-
Mounting Hole:
-
M12
-
Operating Temp:
-
-25°C to +85°C
-
Product type:
-
Toggle switches
-
Certification:
-
CE CCC
Product Description
Feature:
- Movement way has fi xed type and auto-return type (both single-throw and double-thr ow can r eturn).
- The terminal block has screw terminal, solder terminal and tab terminal.
- Rainproof cap, water- proof and oil-proof, it is suitable for full series pr-oducts
- Mounting hole: φ12mm.
Characteristics:
| Rating | 15A 250VAC/20A 125VAC |
| Contact resistance | 15MΩ max. (initial) |
| Insulation resistance | 100MΩ Under 500VDC |
| Dielectric strength | 2000VAC,50/60Hz For 1minute |
| Vibration | 10 to 55Hz,1.5mmDouble amplitude |
| Ambien temperture | -10°C~+70°C(With no icing) |
| Electrical life | Above 25000 |
| Humidity | 85% RH max |
