- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
SunriseTek
-
Model Number:
-
FT2024
-
Work Time (h):
-
24
-
Max PV Power:
-
Support Customization
-
Certificate:
-
CE, RoHS, ISO
-
Warranty:
-
5 years
-
Product name:
-
PWM Solar Charger Controller
-
SIZE:
-
153*101*37mm
-
WEIGHT:
-
390g
-
Display:
-
LCD Screen
-
Working Temperature( C):
-
-20℃-50℃
-
System voltage:
-
12v/24v Automatic Recognition
-
Battery type:
-
Sealed Gel AGM Flooded Lithium
-
USB output:
-
5V/2A MAX
-
Communication:
-
RS485
-
Protection:
-
Multi Protection
Quick Details
-
Type:
-
PWM
-
Application:
-
Charger Controller, Wind Controller, Collector Controller, Water Heater Controller, Solar Working Station, Lighting Controller, Thermal Controller, Voltage Controller, Solar System Controller
-
Place of Origin:
-
China
-
Brand Name:
-
SunriseTek
-
Model Number:
-
FT2024
-
Work Time (h):
-
24
-
Max PV Power:
-
Support Customization
-
Certificate:
-
CE, RoHS, ISO
-
Warranty:
-
5 years
-
Product name:
-
PWM Solar Charger Controller
-
SIZE:
-
153*101*37mm
-
WEIGHT:
-
390g
-
Display:
-
LCD Screen
-
Working Temperature( C):
-
-20℃-50℃
-
System voltage:
-
12v/24v Automatic Recognition
-
Battery type:
-
Sealed Gel AGM Flooded Lithium
-
USB output:
-
5V/2A MAX
-
Communication:
-
RS485
-
Protection:
-
Multi Protection
Products Description
Customized 12v 24v intelligent auto energy regulator led lamp solar street light charge controller
Why Choose Us?
1.Original solar controller factory with 20 years history
2.Excellent cost performance
3.Product customization supported
4.High-quality raw materials for production
5.100% inspection for all functions before delivery
6.Responsible after-sales service
CLICK HERE TO GET MORE DETAILS OF PRODUCTS>>>
Why Choose Us?
1.Original solar controller factory with 20 years history
2.Excellent cost performance
3.Product customization supported
4.High-quality raw materials for production
5.100% inspection for all functions before delivery
6.Responsible after-sales service
CLICK HERE TO GET MORE DETAILS OF PRODUCTS>>>
Major Functions
:
* Automatic identification system voltage, 12V 24V 48V auto recognition
* Humanized LCD displaying and double button operation of man-machine interface.
* Completed technical data for setup and modify.
* High efficiency intelligent PWM 3 stage charging.
* The load control mode can be selected, the timer function can be reset for street light at night.
* Reliable over voltage protection, short circuit protection, over load protection, overcharge protection, overdischarge
protection.
* Accurate temperature compensation by external battery temperature sensor, correcting the charging and discharging voltage
automatically, improving the battery lifetime.
* Roundly reverse connected protection.
* Solar panels, battery, solar charge controller positive poles are all connected together, adopting negative MOSFET in series
control circuit.
* Automatic identification system voltage, 12V 24V 48V auto recognition
* Humanized LCD displaying and double button operation of man-machine interface.
* Completed technical data for setup and modify.
* High efficiency intelligent PWM 3 stage charging.
* The load control mode can be selected, the timer function can be reset for street light at night.
* Reliable over voltage protection, short circuit protection, over load protection, overcharge protection, overdischarge
protection.
* Accurate temperature compensation by external battery temperature sensor, correcting the charging and discharging voltage
automatically, improving the battery lifetime.
* Roundly reverse connected protection.
* Solar panels, battery, solar charge controller positive poles are all connected together, adopting negative MOSFET in series
control circuit.
Model
|
Specification
|
Max PV Input Power
|
Set/
|
Weight/
|
Measurement
|
Volume/
|
|
|
|
Carton
|
Carton
|
|
Cartome
|
FT2024
|
10A 12/24V
AUTO Work |
Input voltage: ≤55V
12V battery: 130W 24V battery: 260W |
50PCS
|
13.0KG
|
540*320*200mm
|
0.035CBM
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
20A 12/24V
AUTO Work |
Input voltage: ≤55V
12V battery: 260W 24V battery: 520W |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FT4024
|
30A 12/24V
AUTO Work |
Input voltage: ≤55V
12V battery: 390W 24V battery: 780W |
40PCS
|
17.7KG
|
510*370*240mm
|
0.045CBM
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
40A 12/24V
AUTO Work |
Input voltage: ≤55V
12V battery: 520W 24V battery: 1040W |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FT6024
|
50A 12/24V
AUTO Work |
Input voltage: ≤55V
12V battery: 650W 24V battery: 1300W |
30PCS
|
18.2KG
|
400*270*405mm
|
0.044CBM
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
60A 12/24V
AUTO Work |
Input voltage: ≤55V
12V battery: 780W 24V battery: 1560W |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FT6048
|
50A AUTO Work12/24/48V
|
Input voltage: ≤100V
12V battery: 650W 24V battery: 1300W 48V battery: 2600W |
30PCS
|
18.2KG
|
400*270*405mm
|
0.044CBM
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
60A AUTO Work12/24/48V
|
Input voltage: ≤100V
12V battery: 780W 24V battery: 1560W 48V battery: 3120W |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FT8024
|
80A Auto Work 12V/24V/48V
|
Input voltage: ≤100V
12V battery: 1040W 24V battery: 2080W 48V battery: 4160W |
20PCS
|
21.5KG
|
535*475*425mm
|
0.108CBM
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
100A Auto Work 12V/24V/48V
|
Input voltage: ≤100V
12V battery: 1300W 24V battery: 2600W 48V battery: 5200W |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
