Quick Details
-
Nature:
-
hd mi dvb-t modulator
-
Channel No.:
-
Universal 1 channel
-
inputs:
-
1xH DMI
-
RF out optional:
-
DVB-T
-
Audio Compression standard:
-
MPEG1 Layer II(default),MPEG-2-AAC, MPEG-4 AAC optional
-
Video compression standard:
-
H.264 HD
-
Resolution:
-
Up to 1080P Full HD
-
Configurable 1:
-
Program name & number,service ID
-
Configurable 2:
-
Video & Audio PID, PMT PID, PCR PID
-
Capability:
-
Encoding, Multiplexing, Encapsulation and Modulator
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DIGICAST/DTVANE
-
Model Number:
-
DMB-9591
-
Nature:
-
hd mi dvb-t modulator
-
Channel No.:
-
Universal 1 channel
-
inputs:
-
1xH DMI
-
RF out optional:
-
DVB-T
-
Audio Compression standard:
-
MPEG1 Layer II(default),MPEG-2-AAC, MPEG-4 AAC optional
-
Video compression standard:
-
H.264 HD
-
Resolution:
-
Up to 1080P Full HD
-
Configurable 1:
-
Program name & number,service ID
-
Configurable 2:
-
Video & Audio PID, PMT PID, PCR PID
-
Capability:
-
Encoding, Multiplexing, Encapsulation and Modulator
Main Feature
- Smart structure with powerful functions
- Advanced compression for H.264 HD
- DVB-T/DVB-C/ATSC/ISDB-T/DTMB modulation mode
- Insertable LCN (Logic Channel Number)
- Insertable NIT table.
- Configurable program name&number, service ID, Audio&Video PID, PMT&PCR PID etc.
- Mounted flexible-anywhere you need.
- Keyboard on front panel and LCD display, convenient and easy for operation
- Network upgrading via JTAG interface, convenient for maintenance
- USB 3.0 for Save,play,record
- Support both web management and front panel control
Specifications
|
ENCODING MODULES |
|
|
H.264 H D Encoding M odule |
Video input: 1*HD MI, Video compression standard: H.264 HD Video resolution: HD MI: 1920*1080_60P, 1920*1080_50P; 1920*1080_60i, 1920*1080_50i, 1280*720_60p, 1280*720_50P. CVBS&S-video: 720x576_50i (PAL); 720x480_60i (NTSC) YPbPr: 1920*1080_60i, 1920*1080_50i; 1280*720_60p, 1280*720_50P Audio input: analog audio (stereo/mono) Audio compression standard: MPEG-1, Layer II (default) , ( MPEG-2 AAC, MPEG-4 AAC optional) Audio sample rate: 48KHz Audio bit rate: 64~384 Kbps |
|
MODULATION MODULES (optional) |
|
|
DVB-T Modulation |
Modulation standard: EN300 744, EN304 744 Bandwidth: 6M, 7M, 8M Constellation: QPSK, 16QAM, 64QAM FET mode: 2K, 8K Guard interval: 1/4, 1/8, 1/16, 1/32 FEC: 1/2, 2/3, 3/4, 5/6, 7/8 MER: ≥42dB RF output frequency range: 30~960MHz, in 1KHz steps RF output level: -30~10dBm (81~97dbµV), in 0.1dB steps Out-of-band rejection: 55dB |
|
ATSC -T Modulation |
Modulation standard: ATSC A/53 Constellation: 8VSB RF output level: -30~-10dbm (81~97dbµV), in 0.1dB steps MER: ≥40dB RF output frequency range: 30~960MHz, in 1KHz steps |
|
DVB-C Modulation |
Modulation standard: J.83A, J.83B, J.83C Constellation: J.83A-6/32/64/128/256QAM; J.83A-64/256QAM; J.83C-64/256QAM RF output level: -30~-10dbm (81~97dbµV), in 0.1dB steps MER: ≥40dB RF output frequency range: 30 ~ 960MHz, in 1KHz steps Symbol rate: J.83A-5 ~ 7MSymbol/s, J.83B - fixed; J.83C - fixed Out-of-band rejection: 55dB Bandwidth: J.83A - 8M, J.83B - 6M, J.83C - 6M |
|
ISDB-T Modulation Specifications |
Modulation standard: ARIB STD-B31 Modulation mode: mode 1(2k), mode 2(4k), mode 3(8k) Constellation: DQPSK, QPSK, 16QAM, 64QAM ISN: convolutional coding (1/2, 2/3, 3/4, 5/6, 7/8) Outer code: RS (204, 188) Guard interval: 1/4, 1/8, 1/16, 1/32 Bandwidth: 6MHz RF output frequency range: 30 ~ 960MHz, in 1KHz steps MER: ≥42dB RF output level: -26dbm ~ -10dbm, in 0.1dB steps |
|
GENERAL OPTIONS |
|
|
Management
|
Local operation: keyboard and LCD display Operation language: English Software upgrading: JTAG
|
|
Physical and Power
|
Voltage: DC 12V Dimensions: 140mm(W)*110mm(D)*43mm(H) Operating temperature: 0~50°C Storage temperature: -10~60°C Humidity: 10%~90% (non-condensing)
|
Encoder modulator with following Option
| DMB-90E Series 4/8/12/16/20/24 Tuners to IP Receiver/Gateway | DMB-24E 4/8/12/16/20/24 Tuners to RF out | IP to RF Modulator Series | |
| Tuner Input |
FTA up to 24 Tuners to 256*IP Receiver
|
FTA 4/8/12/16/20/24 Tuners to RF out
|
IP TO QAM/ATSC/ISDB-T/DVB-T modulator
|
| HDMI input |
DMB-9581E 24*HDMI to RF modulator
|
DMB-8820E 24 HDMI to RF Encoder
|
DMB-9582 Mpeg2/H.264 1/2/4 HDMI/HD-SDI to RF out |
| Transmodulator |
DMB-2400 INPUT:4 tuners with 4 Cl slots OUTPUT:4*DVB-C/2*ATSC/2*DVB-T out |
DMB-2408 INPUT:4*Tuners FTA+4*Tuners with CAM OUTPUT: 4*DVB-T/ DVB-C |
DMB-2412 Input: FTA 12*Tuners(DVB-S/S2) output: 4*DVB-T/C |
