Quick Details
-
Brand Name:
-
OEM
-
Name:
-
CGA320 cylinder valve
-
Working medium:
-
Gas co2
-
Body material:
-
brass
-
Operation:
-
Manual Control
-
Seal Material:
-
brass
-
Usage:
-
Gas cylinder
-
Connection:
-
Thread
-
Working pressure:
-
150-250bar
-
Function:
-
Pressure Regulators
-
Type:
-
Air Valves & Vents
Quick Details
-
Port Size:
-
CGA300
-
Place of Origin:
-
Hubei, China
-
Model Number:
-
CGA300
-
Brand Name:
-
OEM
-
Name:
-
CGA320 cylinder valve
-
Working medium:
-
Gas co2
-
Body material:
-
brass
-
Operation:
-
Manual Control
-
Seal Material:
-
brass
-
Usage:
-
Gas cylinder
-
Connection:
-
Thread
-
Working pressure:
-
150-250bar
-
Function:
-
Pressure Regulators
-
Type:
-
Air Valves & Vents
CGA320 valve mainly used for CO2 carbon dioxide gas.
Brief introduction of CGA320 flap type carbon dioxide cylinder valve
CGA320 valve type carbon dioxide gas cylinder valve model CGA320 product name valve type carbon dioxide gas cylinder valve suitable medium carbon dioxide nominal working pressure MPa15 nominal diameter mm4 outlet thread mmCGA320 and gas cylinder connection thread mm3/4-14-NGT safety device temperature or pressure MPa21±1.5
Detailed information of CGA320 flap carbon dioxide cylinder valve
CGA320 Disc Type Carbon Dioxide Gas Cylinder Valve
Model CGA320
Product Name Valve Type Carbon Dioxide Gas Cylinder Valve
Applicable medium carbon dioxide
Nominal working pressure MPa 15
Nominal diameter mm 4
Outlet thread mm CGA320
Connection thread with cylinder mm 3/4-14-NGT
Safety device temperature or pressure MPa 21±1.5
Application
We supply gas cylinder valve : oxygen cylinder valve, acetylene cylinder valve, nitrogen cylinder valve, argon cylinder valve, carbon dioxide cylinder valve and propane cylinder valve, both flammable gas, non-flammable gas and toxic gases.
FAQ
Q1. Can I have a sample order for the gas valve?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.
Q2. Do you have any MOQ limit for valve orders? and how about the sample time?
A: Low MOQ is from 1pc for each. How about the sample time? Sample time: 3-10 days after e-proof is confirmed and your payment is received.
Q3. How do you ship the goods and how long does it take to arrive?
A: The valves are usually shipped by sea. It usually takes 30 days to arrive. Airline shipping is also optional.
Q4. How to proceed with an order for valves?
A: Firstly let us know your requirements or application. Secondly, We quote according to your requirements in the PI
Thirdly. the customer confirms the informations and price.
After we recevie the payment, We will arrange the production.
Q5. Do you provide customized products?
A: We are good to offer customized services in terms of logo labeling, manufacturing based on samples or blueprints, etc
Q6. What about your payment method?
A: T/T, Alibaba, or RMB Bank
Q7: Do you offer guarantee for the products?
A: Yes, we offer life-time years warranty to our products.
