The
GZ-H61J
is firmer and more durable than ever.
The three-dimensional dot texture on the outside of the
GZ-H61J
is ergonomic and effective for shock absorption and skid resistance, making it more stable.
- Product Details
- {{item.text}}
Quick Details
-
Screen Size:
-
6.5 inch, 6.5 " (20:9, 720*1600 IPS) 500Nits
-
Weight:
-
470
-
Brand Name:
-
GENZO
-
Model Number:
-
GZ-H61J
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
Windows PDA
-
CPU:
-
Intel JASPER LAKE N5100
-
RAM/ROM:
-
RAM 8GB LPDDR4 , ROM 128GB EMMC
-
Camera:
-
Front 5.0MP /Rear 8.0MP autofocus with flash
-
4G LTE:
-
MeiGlink 750VE
-
GPS:
-
GPS+GLONASS
-
Wifi:
-
Wi-Fi 802.11(a/b/g/n/ac) Dual frequency 2.4G+5.8G WIFI
-
Battery:
-
7.4V/4000mAh Removeable Battery
-
Barcode:
-
2D Barcode Scanner
Quick Details
-
Operating System:
-
windows 11 IOT
-
Style:
-
Handheld Computer
-
Memory Capacity:
-
8gb ddr4
-
Screen Size:
-
6.5 inch, 6.5 " (20:9, 720*1600 IPS) 500Nits
-
Weight:
-
470
-
Brand Name:
-
GENZO
-
Model Number:
-
GZ-H61J
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
Windows PDA
-
CPU:
-
Intel JASPER LAKE N5100
-
RAM/ROM:
-
RAM 8GB LPDDR4 , ROM 128GB EMMC
-
Camera:
-
Front 5.0MP /Rear 8.0MP autofocus with flash
-
4G LTE:
-
MeiGlink 750VE
-
GPS:
-
GPS+GLONASS
-
Wifi:
-
Wi-Fi 802.11(a/b/g/n/ac) Dual frequency 2.4G+5.8G WIFI
-
Battery:
-
7.4V/4000mAh Removeable Battery
-
Barcode:
-
2D Barcode Scanner
10 Years Old Store Upgraded & Reopened
Product Description
|
Hardware
|
|
|
|
CPU
|
Intel JASPER LAKE N5100,2.80 GHz
|
|
|
GPU
|
Intel® UHD Graphics 620
|
|
|
RAM/ROM
|
8GB
LPDDR4+
128GB
Emmc
|
|
|
External Memory
|
Support TF*1,MAX 512GB
|
|
|
LCD Display
|
6.5 inch full laminated TFT color full IPS screen,Dropnotch 20:9,
Resolution: 720*1600P, Brightness: 500cd/cm²
|
|
|
Touch Panel
|
5 points Capacitive, G+FF, Corning Gorilla Glass, Hardness 6H or higher, scratch-resistant.
|
|
|
Camera
|
Front:5.0MP,Rear 8.0MP automatic focusing
|
|
|
Battery
|
7.4V/4000mAh.
Removeable polymer lithium ion battery,
About 6 hours(50% volume sounds, 50% screen brightness, 1080P HD video display by default )
Support
45W
PD3.0 - Fast Charging
|
|
|
Speaker
|
Embedded 1Ω/1W speaker x 1 95dB@0.1m
|
|
|
Microphone
|
Single microphone
|
|
|
Senssors
|
G_sensor *1
|
|
|
Data Collection & Networking
|
|
|
|
Barcode Scanner
|
2D Optional Honeywell N4680/N3680
|
|
|
NFC
|
13.56MHz, Support ISO/IEC 14443A/14443B/15693/18092/mifare protocol, reading distance: 3-5cm
|
|
|
BT
|
BT5.0 (BLE) class1 transmission distance：10m
|
|
|
WIFI
|
Wi-Fi 802.11(a/b/g/n/ac) Dual frequency 2.4G+5.8G WIFI
|
|
|
4G
|
MeiGlink 750VE,
LTE FDD:
B1/B3/B7/B8/B20,
LTE TDD
: B40,
WCDMA:
B1/B5/B8
GSM:
900/1800 China (Unicom, Telecom, Mobile) Europe, Middle East,Africa, Taiwan, Japan
Optional:
750-VA
，LTE-FDD: B2/4/5/12/13/17/18/25/26, LTE-TOD:B41, WCDMA: B2/4/5, CDMA&EVDO: BC0/BC1 GSM: 850/1900
750-VSA,
LTE-FDD:B2/4/5/7/8/28, LTE-TOD:B40, WCDMA: B2/5/8, GSM:850/900/1900
|
|
|
GPS
|
GPS+GLONASS
|
|
|
OS
|
Windows 10 IOT/Windows 11 IOT inactivated os(Free)
|
|
|
I/O Port & Appearance & Packag
e
|
|
|
|
I/O Port
|
TYPE-C 2.0*1 OTG (Data transmission),
Standard USB-A port/Data Transfer (3.0 ), TF card *1, Max: 512GB
Nano-SIM * 1
Pogo Pin (Suitable docking charger) |
|
|
Dimension
|
183.1*88.6*24.1mm
|
|
|
Buttons
|
Power *1
Volume Adjustment Key (+) *1 Volume Adjustment Key (-) *1
Bar code scanning (left and right)*2
|
|
|
Weight
|
Device unit: 470g
|
|
|
Package
|
USB C to C cable/PD3.0 45W Adapter/Packing box（Can be customized logo)
Handstrap is Optional
|
|
|
Certificate System & Reliability Design
|
|
|
|
IP67
|
IP67 Report：waterproof test：IP-X7，dustproof test：IP-6X
a.nozzle inner diameter：6.3mm；
b.water-carrying capacity：12.5±0.625L/min；
c.water pressure：adjust according to specified water-carrying capacity；
d.central part of main water flow Away from the nozzle 2.5 m diameter about 40mm circle；
e.water spray time for outter shell per a square meter：about 1min；
f. test time：at least 3min;
g.distance from nozzle to outter shell surface：2.5～3m.
after tested,check sample and no water inside situation
|
|
|
CE NB
|
YES
|
|
|
MIL-STD-810G
|
YES
|
|
|
Battery
|
UN38.3，MSDS,IEC62133
|
|
|
Drop Height
|
MIL-STD-810G 1.22m drop
|
|
|
Operate Temperature
|
‘-10 °C to 50 °C
|
|
|
Store Temperature
|
’-20 °C to 60 °C
|
|
|
Humidity
|
Humidity: 95% Non-Condensing
|
|
Details Images
Born To Be Tough
PC+TPU material
and
two-color
injection molding process featuring its high precision, strength, and small gap, to create a high-quality body.With the cutting-edge industrial design and embedded hardware bracket for unsurpassed support performance.
Display Whatever You Want
6.5-inch TFT
screen with
20:9
overlength ratio and arc border for arounded and refined appearance.
lt supports 720x 1600 resolution and
500 nits
brightness, giving you asmooth HD display.
The 5-point capacitive touch panel with Corning Gorilla Glass provides,you with a smooth operation experience, and the tough cover plate is resistant to drops and scratches.
The 5-point capacitive touch panel with Corning Gorilla Glass provides,you with a smooth operation experience, and the tough cover plate is resistant to drops and scratches.
Camera:
Front 5.0MP/Rear 8.0MP
Peformance Beyond Yourlmagination
Powered by the lntel Celeron
N5100
Processor with a
4-core
CPU, upping to
2.80 GHz
, the
GZ-H61J
provides a better balance between performance and power consumption.
Equipped with the
Windows 10
operating system, and optional
Windows 11
, the GZ-H61J ensures
security and improves efficiency and productivity.
security and improves efficiency and productivity.
8GB
LPDDR4 +
128GB
eMMC is the mainstream configuration, providing a faster speed to bring smooth operation.
24/7 Outdoor Productivity
lts
7.4V/4000mAh
high-voltage high-capacity battery supports
45W
Type-C
PD3.0 Fast Charging
to provide longer endurance.
The battery is
detachable
, so equipping it with a spare battery is a great choice to eliminate your concern about long-time oroutdoormobile use.
With active turbofan for powerful heat dissipation and
PWM
intelligent temperature control, the
GZ-H61J
is ready for high-intensity tasking.
Professional Supportfor Multi-Scenario
With the
optional barcode scanning engine
, white light for illumination, and red light for aiming, the
GZ-H61J
greatly assists in professional information collection.
Large-area
NFC
supports ISO/IEC international standards and various protocols,so the
GZ-H61J
provides faster identification and more convenient card reading.Thanks to the integration of
dual-band Wi-Fi
, Bluetooth
5.0
, and
4G
, the
GZ-H61J
achieves a more stable network connection indoors and in remote scenes.
Ready for Harsh Environments
GZ-H61J's
sealed and precision structure is up to
IP67
grade dustproof and waterproof, so there is no need to worry about rainy and other harsh weather. Its
1.5m
fall-resistance performance keeps it intact even if falling from a height of up to 1.5m to the surface of the composite wood floor.
GZ-H61J
is impressive in fast cooling and temperature control. In the laboratory test environment, it can maintain about 30℃ for a long time.
Optional Accessories
Docking Charger, Scanner Trigger,
Vehicle Mount, Battery
Vehicle Mount
Car Charger
Removeable Battery
Payment & Packing &Shipping
Company Introduction
FAQ
Q :Are you manufacturer?
A: Yes, we are manufacturers.We can provide OEM / ODM customized service according to our customers’ various application and demands.All of our products are fully patented, ID/MD design, hardware and software,mold,assembly are done by our own team.
Q: Would you provide SDK for me?
A: Yes, we offer free SDK if you order sample.In addition, we also have support engineers to assist you with software development.
Q: What is the minimum order(MOQ)?
A: We accept one unit for standard products.we can even customized with your logo if needed. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.
Q: Can we get the free sample?
A: Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.
Q: Can i choose multiple function into 1 device?
A: Yes, you can choose multiple fuction into onedevice, Different functions depending on the product model,optional functions:RFID(LF/HF/UHF)1 Fingerprint/ Bar code scanner.
Q: How to order and pay?
A: We accept T/T (bank transfer), Alipay online for 1 Trade Assurance
Q: What's Your Products Warranty?
A: We Offer 18 Months Warranty after shipment sent.
Q: Can I extend the warranty?
A: We offer a deferred warranty for up to 36 Months, and the price for the warranty extension is 10% up.
Q: How long it will take for delivery?
A: For production lead time around 3-10 days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would around 3-5 working days. For some remote place, delivery time maybe a little bit longer.
Q:How to repair the device if any problem ?
A: We will provide technical support online to solve problem; If for the hardware problem , we could send the parts or components and teach customer to fit if they have technician or can also send backto us to fix it.
Q: Can you do customized and preload our software?
A:We are professional rugged device manufacture with 11 years experiences
A: Yes, we are manufacturers.We can provide OEM / ODM customized service according to our customers’ various application and demands.All of our products are fully patented, ID/MD design, hardware and software,mold,assembly are done by our own team.
Q: Would you provide SDK for me?
A: Yes, we offer free SDK if you order sample.In addition, we also have support engineers to assist you with software development.
Q: What is the minimum order(MOQ)?
A: We accept one unit for standard products.we can even customized with your logo if needed. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.
Q: Can we get the free sample?
A: Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.
Q: Can i choose multiple function into 1 device?
A: Yes, you can choose multiple fuction into onedevice, Different functions depending on the product model,optional functions:RFID(LF/HF/UHF)1 Fingerprint/ Bar code scanner.
Q: How to order and pay?
A: We accept T/T (bank transfer), Alipay online for 1 Trade Assurance
Q: What's Your Products Warranty?
A: We Offer 18 Months Warranty after shipment sent.
Q: Can I extend the warranty?
A: We offer a deferred warranty for up to 36 Months, and the price for the warranty extension is 10% up.
Q: How long it will take for delivery?
A: For production lead time around 3-10 days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would around 3-5 working days. For some remote place, delivery time maybe a little bit longer.
Q:How to repair the device if any problem ?
A: We will provide technical support online to solve problem; If for the hardware problem , we could send the parts or components and teach customer to fit if they have technician or can also send backto us to fix it.
Q: Can you do customized and preload our software?
A:We are professional rugged device manufacture with 11 years experiences
