Quick Details
-
Installation:
-
Internal
-
Brand Name:
-
SENONE / OEM / Neutral
-
Model Number:
-
SCR-300
-
Place of Origin:
-
Guangdong, China
-
Host Interface:
-
USB 2.0 CCID1 (also compliant with USB 1.1)
-
Transmission Speed:
-
12 Mbps (USB 2.0 full speed)
-
Standards:
-
ISO 7816 & EMV2 2000 Level 1
-
Protocols:
-
T=0, T=1, SLE 4432/42 (S=10), SLE 4418/28 (S=9), I2C (S=8)
-
Card Size:
-
ID-1 (full-size)
-
Smart Card Interface Speed:
-
420 Kbps (when supported by card)
-
Smart Card clock frequency:
-
Up to 5 MHZ
-
Supported card types:
-
5V, 3V and 1.8V Smart Cards ISO 7816 Class A, AB and C
-
Power to Smart Card:
-
60Ma
Quick Details
-
Type:
-
Other Type
-
Interface:
-
usb
-
Card Slots:
-
Single
-
Installation:
-
Internal
-
Brand Name:
-
SENONE / OEM / Neutral
-
Model Number:
-
SCR-300
-
Place of Origin:
-
Guangdong, China
-
Host Interface:
-
USB 2.0 CCID1 (also compliant with USB 1.1)
-
Transmission Speed:
-
12 Mbps (USB 2.0 full speed)
-
Standards:
-
ISO 7816 & EMV2 2000 Level 1
-
Protocols:
-
T=0, T=1, SLE 4432/42 (S=10), SLE 4418/28 (S=9), I2C (S=8)
-
Card Size:
-
ID-1 (full-size)
-
Smart Card Interface Speed:
-
420 Kbps (when supported by card)
-
Smart Card clock frequency:
-
Up to 5 MHZ
-
Supported card types:
-
5V, 3V and 1.8V Smart Cards ISO 7816 Class A, AB and C
-
Power to Smart Card:
-
60Ma
Specification
|
Support card type
|
5V, 3V and 1.8V smart cards, ISO 7816 Class A, AB and C.
|
|
|
|
|||
|
Interface Type
|
USB 2.0 CCID1 (also compliant with USB 1.1)
|
|
|
|
|||
|
Transfer speed
|
12Mbps
|
|
|
|
|||
|
Line length
|
47.24inch
|
|
|
|
|||
|
Certification standards
|
ISO-7816 and EMV2 2000 Level 1, CE, FCC, VCCI, CCID, Microsoft WHQL
|
|
|
|
|||
|
Durability
|
100,000 times
|
|
|
|
|||
|
Secondary development
|
Support multi-language development, provide routines
|
|
|
|
|||
|
operating system
|
Windows 10, 8, 7 (32/64 bit), Windows XP, Vista (32/64 bit), Windows Server 2003/2008 (32/64 bit).
|
|
|
|
|||
|
Operating temperature
|
0-55℃/32-131℉
|
|
|
|
|||
|
Product Size
|
3.36inch*2.56inch*1.02inch
|
|
|
|
|||
|
Package dimensions
|
96*103*25mm
|
|
|
|
|||
