- Product Details
- {{item.text}}
Quick Details
-
Condition::
-
New Original
-
Warranty:
-
3 Years
-
Device Type:
-
Graphics card
-
Delivery time:
-
1-2 Working Days
-
Payment Terms:
-
T/T
-
Base Clock:
-
1329 MHz
-
Boost Clock:
-
1557 MHz
-
Memory Bus:
-
128 bit
-
Memory Type:
-
GDDR5
-
Memory Size:
-
2 GB
Quick Details
-
Chipset Manufacturer:
-
nVIDIA
-
Video Memory Type:
-
GDDR5
-
Place of Origin:
-
Beijing, China
-
Condition::
-
New Original
-
Warranty:
-
3 Years
-
Device Type:
-
Graphics card
-
Delivery time:
-
1-2 Working Days
-
Payment Terms:
-
T/T
-
Base Clock:
-
1329 MHz
-
Boost Clock:
-
1557 MHz
-
Memory Bus:
-
128 bit
-
Memory Type:
-
GDDR5
-
Memory Size:
-
2 GB
Clock Speeds
- Base Clock
- 1329 MHz
- Boost Clock
- 1557 MHz
- Memory Clock
-
1002 MHz
4 Gbps effective
Memory
- Memory Size
- 2 GB
- Memory Type
- GDDR5
- Memory Bus
- 128 bit
- Bandwidth
- 64.13 GB/s
Render Config
- Shading Units
- 384
- TMUs
- 24
- ROPs
- 16
- SM Count
- 3
- L1 Cache
- 48 KB (per SM)
- L2 Cache
- 1024 KB
Theoretical Performance
- Pixel Rate
- 24.91 GPixel/s
- Texture Rate
- 37.37 GTexel/s
- FP16 (half) performance
- 18.68 GFLOPS (1:64)
- FP32 (float) performance
- 1,196 GFLOPS
- FP64 (double) performance
- 37.37 GFLOPS (1:32)
Board Design
- Slot Width
- Single-slot
- Length
-
150 mm
5.9 inches
- Width
-
69 mm
2.7 inches
- TDP
- 40 W
- Suggested PSU
- 200 W
- Outputs
- 4x mini-DisplayPort
- Power Connectors
- None
- Board Number
- PG212 SKU 501
Graphics Features
- DirectX
- 12 (12_1)
- OpenGL
- 4.6
- OpenCL
- 1.2
- Vulkan
- 1.2
- CUDA
- 6.1
- Shader Model
- 6.4
HISCO INTERNATIONAL LIMITED mainly work on Intel, Dell, IBM, EMC, Brocade, Cisco, Seagate, Qlogic, Samsung and so on, servers and parts, our advantage is honesty and trustworthiness, skilled in technology, backed by strong IT resources, good after sales. Win-win cooperation is our company's philosophy, is our core values. Welcome IT partners from all over the world to negotiate business!
1. We provide 1-5 years replacement warranty. Warranty period begin after sales.
2. If our goods have any quality problem, within warranty period, we will replace it for you freely (Artificial damage will not accept a return).
3. We will be responsible for shipping charges.
