Quick Details
-
Max Paper Size:
-
NA
-
Optical Resolution:
-
≥4mil(PCS90%,CODE 39)
-
Scan Speed:
-
200 times/sec
-
Brand Name:
-
OCOM/Neutral/OEM
-
Place of Origin:
-
Guangdong, China
-
Wireless:
-
100 meters 2.4G wireless
-
Battey:
-
1200mAh
-
Memory:
-
16MB
-
Aiming Light:
-
Green Dot
-
Working time/Charging time:
-
12 hours/4 hours
-
Shock resistance:
-
1.5m free fall on concrete surface
-
Light source:
-
Red LED(Aiming)+White LED(Lighting)
-
printing contrast:
-
≥25%
-
Power supply:
-
DC 5V ±5%
-
Trigger mode:
-
Manual,Continuous scanning,Auto-sensing
Quick Details
-
Type:
-
Barcode Scanner
-
Scan Element Type:
-
CMOS sensor
-
Colour Depth:
-
32-bit ARM MCU + DSP
-
Max Paper Size:
-
NA
-
Optical Resolution:
-
≥4mil(PCS90%,CODE 39)
-
Scan Speed:
-
200 times/sec
-
Brand Name:
-
OCOM/Neutral/OEM
-
Place of Origin:
-
Guangdong, China
-
Wireless:
-
100 meters 2.4G wireless
-
Battey:
-
1200mAh
-
Memory:
-
16MB
-
Aiming Light:
-
Green Dot
-
Working time/Charging time:
-
12 hours/4 hours
-
Shock resistance:
-
1.5m free fall on concrete surface
-
Light source:
-
Red LED(Aiming)+White LED(Lighting)
-
printing contrast:
-
≥25%
-
Power supply:
-
DC 5V ±5%
-
Trigger mode:
-
Manual,Continuous scanning,Auto-sensing
Product details
|
General
|
|
|
Model
|
OCBS-W220
|
|
Color
|
Black
|
|
Processor
|
32-bit ARM MCU + DSP
|
|
Wireless
|
100 meters 2.4G wireless
|
|
Power supply
|
DC 5V ±5%
|
|
Interface
|
USB
|
|
Battey
|
1200mAh
|
|
Power consumption
|
375mW(Working);226mW(standy);750mW(Max)
|
|
Prompt mode
|
Buzzer, indicator(LED)
|
|
Trigger mode
|
Manual,Continuous scanning,Auto-sensing
|
|
Memory
|
16MB
|
|
Working time
|
12 hours
|
|
Charging time
|
4 hours
|
|
ESD Protection
|
15KV air discharge
|
|
Shock resistance
|
1.5m free fall on concrete surface
|
|
System Supported
|
Linux,Android,Windows XP,7,8,10,MAC
|
|
Performance
|
|
|
Sensor
|
CMOS sensor
|
|
Light source
|
Red LED(Aiming)+White LED(Lighting)
|
|
Reading Mode
|
|
|
Print contrast
|
≥25%
|
|
Resolution
|
≥4mil（PCS90%,CODE 39）
|
|
Movement tolerance
|
25cm/s
|
|
Scanning Angel
|
Roll360°,Pitch30°,Yaw45°
|
|
Scanning Depth
|
Code39 4.17mil(15 bytes): 4cm-8cm
Code128 4.17mil(16 bytes):7cm- 15cm Data Matrix 10.83mil(8 bytes):3cm-9cm Code QR 20mil (8 bytes):1cm- 19cm |
|
Error rate
|
1/5 million
|
|
Decoding ability
|
1D:Code25-Interleaved,Code25-Standard ,Code25-Matrix,
Code39-Regular ,Code39-FullASCII ,Code32,Code128,EAN/GSL/UCC-128Auto,Codabar,MSI,EAN/JAN-13,UPC-A,JAN-8,UPCE 2D:QR,Data Matrix ,PDF417 |
|
Environment
|
|
|
Working temperature& humidity
|
0 to 45 degrees centigrade, 10%~80% No condensation
|
|
Storage temperature& humidity
|
-20 to 60 degrees centigrade , 10%~90% No condensation
|
Packing&Shipping&Payment
FAQ
1. MOQ policy
No MOQ limitation for the standard products, but the unit price is different, bigger quantity better price.
For customized production, you can discuss the MOQ with our sales representative directly.
2. Sample Availability & Policy
After customers confirmed the specification, we are very glad to provide samples for testing and qualification. All samples should be paid before shippment, the samples price is a higher than mass order. When the mass order placed, we can return you the samples cost, or send you more piece products with the shippments. You can buy the samples from us directly using t/t, western uion, or paypal.
3. Warranty
OCOM is dedicated to providing most cost-effective products and services with reliable quality that will meet customers 'satisfication; We was qualified by global fortune 500 company, and we have the top 1 level trade assurance which 100% protect your money and lead time. Our warranty of the products is about 12+1 months from the shipment normally, some designated models can have as long as 24 months warranty; Any product within 30 days of delivery failure occurs shall be deemed invalid delivery (DOA). DOA products will give priority to the replacement, and shipped by courier. For mass order, we would like to supply some spare parts with shipment for local quickly repair. And after that, you can returned failure parts for rework andanalysis.
4. Payment
Terms For mass order, you can pay us by using T/T, LC, Western Union, Escrow or others.
No MOQ limitation for the standard products, but the unit price is different, bigger quantity better price.
For customized production, you can discuss the MOQ with our sales representative directly.
2. Sample Availability & Policy
After customers confirmed the specification, we are very glad to provide samples for testing and qualification. All samples should be paid before shippment, the samples price is a higher than mass order. When the mass order placed, we can return you the samples cost, or send you more piece products with the shippments. You can buy the samples from us directly using t/t, western uion, or paypal.
3. Warranty
OCOM is dedicated to providing most cost-effective products and services with reliable quality that will meet customers 'satisfication; We was qualified by global fortune 500 company, and we have the top 1 level trade assurance which 100% protect your money and lead time. Our warranty of the products is about 12+1 months from the shipment normally, some designated models can have as long as 24 months warranty; Any product within 30 days of delivery failure occurs shall be deemed invalid delivery (DOA). DOA products will give priority to the replacement, and shipped by courier. For mass order, we would like to supply some spare parts with shipment for local quickly repair. And after that, you can returned failure parts for rework andanalysis.
4. Payment
Terms For mass order, you can pay us by using T/T, LC, Western Union, Escrow or others.
About samples order,T/T, Western Union, Escrow,Paypal are acceptable.Escrow Service is powered by Alipay.com.
5. Shipment
We accept all kinds of shipping ways including: express, air, sea, truck, or pick up by customers personally.
5. Shipment
We accept all kinds of shipping ways including: express, air, sea, truck, or pick up by customers personally.
