Quick Details
-
Product Name:
-
Electric Golf Cart
-
Controller:
-
Curtis
-
Battery:
-
6 x 8V Deep Cycle Batteries
-
Tire:
-
18x8.5-8(4 Ply )
-
Ground Clearance:
-
120 mm
-
Speed Range:
-
up to 25 km/h
-
Turning Radius:
-
2900mm
-
Seating Capacity::
-
2 and 4 passengers
Quick Details
-
Certification:
-
ISO
-
Place of Origin:
-
China
-
Brand Name:
-
Leroad
-
Product Name:
-
Electric Golf Cart
-
Controller:
-
Curtis
-
Battery:
-
6 x 8V Deep Cycle Batteries
-
Tire:
-
18x8.5-8(4 Ply )
-
Ground Clearance:
-
120 mm
-
Speed Range:
-
up to 25 km/h
-
Turning Radius:
-
2900mm
-
Seating Capacity::
-
2 and 4 passengers
Product Description
|
Model
|
L2 Standard
|
|
L2+CSA
|
|
L2+2
|
|
|||||
|
Voltage
|
AC 48 V
|
DC 48V
|
AC 48 V
|
DC 48V
|
AC 48 V
|
DC 48V
|
|||||
|
Motor
|
5 KW
|
3.8 KW
|
5 KW
|
3.8 KW
|
5 KW
|
3.8 KW
|
|||||
|
Controller
|
Curtis
|
|
|
|
|
|
|||||
|
Rear Axle Ratio
|
16.2:1
|
12.375:1
|
16.2:1
|
12.375:1
|
16.2:1
|
12.375:1
|
|||||
|
Battery
|
6 x 8V Deep Cycle Batteries
|
|
|
|
|
|
|||||
|
Charger
|
Learoad Charger
|
|
|
|
|
|
|||||
|
Accelerator
|
Hall Accelerator 0-4.7V
|
|
|
|
|
|
|||||
|
Load Capacity
|
200 kg
|
|
370 kg
|
|
|
|
|||||
|
Curb Weight
(Lead Acid Batteries)
|
480 kg
|
|
500 kg
|
|
540 kg
|
|
|||||
|
Curb Weight
(Lithium Battery)
|
340 kg
|
|
360 kg
|
|
400 kg
|
|
|||||
|
Length
|
2425 mm
|
|
2655 mm
|
|
2715 mm
|
|
|||||
|
Width
|
1180 mm
|
|
|
|
1190 mm
|
|
|||||
|
Height
|
1780 mm
|
|
|
|
1905 mm
|
|
|||||
|
Seating Capacity
|
2
|
|
|
|
4
|
|
|||||
|
Ground Clearance
|
120 mm
|
|
|
|
|
|
|||||
|
Wheelbase
|
1673 mm
|
|
|
|
|
|
|||||
|
Wheel Track Front/Rear
|
885 mm/970 mm
|
|
|
|
|
|
|||||
|
Speed Range
|
up to 25 km/h
|
|
|
|
|
|
|||||
|
Turning Radius
|
2900 mm
|
|
|
|
|
|
|||||
|
Steering System
|
Bi-directional Push Rack and Pinion Steering Box
|
|
|
|
|
|
|||||
|
Front Suspension
|
Macpherson Independent Suspension
|
|
|
|
|
|
|||||
|
Rear Suspension
|
Spring Plate and Hydraulic Shock
|
|
|
|
|
|
|||||
|
Braking System
|
Parking Brake and Rear Mechancial Brake
|
|
|
|
|
|
|||||
|
Tire
|
18x8.5-8(4 Ply )
|
|
|
|
|
|
|||||
|
Standard Body Color
|
Gold, Forest Green, White, Ivory, Electric Blue
|
|
|
|
|
|
|||||
|
Standard Seat Color
|
Beige
|
|
|
|
|
|
|||||
|
Options and Accessories
|
10” Aluminum Alloy Wheel Rims/Tyres, Color: Black, red or customized color, Rear-view Mirror and Side Mirrors, Front and Rear Wheel Eyebrows, Hand Held Diagnostic Unit, Hot Galvanized Frame, Convertible Rear Seat, Extended Sun Canopy, Battery Fill System, Cargo Box-Plastic, Message Holder, Rain Enclosure, Lithium Battery, Speed Meter, Ball Washer, Sand Bottle, Sand Rake, Bag Cover, Sunshade, Light Kits, Ashtray, Cooler, LCD, Electromagnetic Brake
|
|
|
|
|
|
|||||
