- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HONGDA
-
Model Number:
-
DD703
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1060*750*1700mm
-
Power (kW):
-
3kw
-
Weight (KG):
-
650 KG
-
Marketing Type:
-
Hot sales
-
Name:
-
Punch
-
Keyword:
-
dd703
-
Machine type:
-
Cnc Drilling Edm Machine
-
Provide after-sales service:
-
Available overseas third-party support
-
Post guarantee services:
-
Video technical support, online support
-
Core components:
-
motor
-
Video inspection:
-
Provided
-
colour:
-
Based on customer needs
-
Maximum drilling capacity:
-
3mm
-
advantage:
-
Good stability, low electrode consumption
Quick Details
-
type:
-
Edm Drilling Machine
-
Max. Drilling Dia. (mm):
-
3mm
-
Range of Spindle Speed(r.p.m):
-
30 - 3000 r.p.m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HONGDA
-
Model Number:
-
DD703
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1060*750*1700mm
-
Power (kW):
-
3kw
-
Weight (KG):
-
650 KG
-
Marketing Type:
-
Hot sales
-
Name:
-
Punch
-
Keyword:
-
dd703
-
Machine type:
-
Cnc Drilling Edm Machine
-
Provide after-sales service:
-
Available overseas third-party support
-
Post guarantee services:
-
Video technical support, online support
-
Core components:
-
motor
-
Video inspection:
-
Provided
-
colour:
-
Based on customer needs
-
Maximum drilling capacity:
-
3mm
-
advantage:
-
Good stability, low electrode consumption
Video Description
Product Description
Main technical parameters of the product:
|
model
|
DD703.30
|
DD703.50
|
|
X-Y travel (mm)
|
300*400
|
500*630
|
|
Workbench size (mm)
|
260*380
|
700*1000
|
|
Axis servo travel (mm)
|
300
|
600
|
|
Spiral head travel (mm)
|
200
|
500
|
|
Spiral head speed
|
20-120rpm
|
20-120rpm
|
|
Electrode wire diameter (mm)
|
0.3-3
|
0.3-3
|
|
The maximum distance between the director and the table (mm)
|
300
|
500
|
|
Input power (kW)
|
3
|
3
|
|
size (mm)
|
1260*1160*1900
|
2000*1500*1900
|
Details display
