Quick Details
-
OS:
-
-
-
Screen Type:
-
-
-
Warranty:
-
12 Months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VJOYCAR
-
Model Number:
-
TK05
-
Product name:
-
car parts gps tracker
-
Product type:
-
Powerful magnet easy install
-
Frequency:
-
850/900/1800/1900MHZ
-
Waterproof:
-
Yes
-
Voice surveillance:
-
No
-
Internal battery:
-
5000mAh
-
Standby time:
-
300days
-
Drop sensor alert:
-
Yes
-
GPS Tracking Software:
-
FREE forever
-
Application:
-
Universal for car, vehicle, truck, container,assets...
Quick Details
-
Car Fitment:
-
Universal
-
Resolution:
-
-
-
Function:
-
GPS Tracking
-
OS:
-
-
-
Screen Type:
-
-
-
Warranty:
-
12 Months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VJOYCAR
-
Model Number:
-
TK05
-
Product name:
-
car parts gps tracker
-
Product type:
-
Powerful magnet easy install
-
Frequency:
-
850/900/1800/1900MHZ
-
Waterproof:
-
Yes
-
Voice surveillance:
-
No
-
Internal battery:
-
5000mAh
-
Standby time:
-
300days
-
Drop sensor alert:
-
Yes
-
GPS Tracking Software:
-
FREE forever
-
Application:
-
Universal for car, vehicle, truck, container,assets...
GPS Tracking Sticker 2G GSM LBS Locations Free Platform Cheap Price Best Quality Tracking Device for Asset Tracking
• Big rechargeable removable battery 5000mAh;
• Powerful magnet,no need professional install,cost effective;
• Low consumption and kinds of sleeping mode, power saved, long battery life;
• Anti theft: built in motion sensor,it will send sms or call alert once detect motion;
• Geo fence, it will send alert also once move out the pre-setted fence;
• Easy gsm sms tracking with street name in sms text;
• Free web based tracking platform supporting: no monthly or yearly subciption, FREE forever;
• Support the third party free software,eg, gpsgate,traccer,gurtam,gps-server,gpswox,gps-trace;
• Dismount sensor alert,to avoid it dropping from vehicles without notice;
Tech Specification:
| Size | 120*59*30mm |
| Weight | 240g |
| GPRS | MTK 6260D,Quad band; GSM 850/900/1800/1900 MHz |
| Antennae | Internal, GPRS Class 12 |
| Battery | Rechargeable, 5000mAh, Lithium-Polymer Battery |
| GPS | G7020-ST, 50 channel |
| A-GPS | AssistNow Online and AssistNow Offline services |
| Sensor | Built-in Vibration/motion sensor |
| Position Accuracy | <=5m |
| Sensitivity |
(R)C161 dB, Cold starts:(R)C148 dB, Hot starts: (R)C156 dB
Cold start:<27s, Warm Start: <5s, Hot Start:1s |
Preparation: A. Device Charged first
B. SIM card with SMS, Call & GPRS
C. Check your APN’s name
D. Place the device outdoors
Set up your device before using server or APP
Step 1-- Insert the SIM card
After inserting the SIM, dial the SIM’s number.
If get through with no answer, the device works.
Best GPS Device Wifi Positioning 2G SIM Card Could Receive Locations Even Indoor Wifi Tracking GPS System
Step 2-- Set APN
Send the following command by you phone:
*apn*APN’s name*
E.g. Your APN’s name is cmnet, then send *apn*cmnet*
Step 3-- Set Mater Phone
Send the following command by your phone:
*master*123456*+(country code)phone number*
Best GPS Device Wifi Positioning 2G SIM Card Could Receive Locations Even Indoor Wifi Tracking GPS System
E.g. your country code: +86
Phone number: 1456894255
Then send *master*123456*+861456894255*
Notice: All commands be correct forms & don't go to next step before receiving reply from the device
A: As long as your country has regular 2G GSM network. If you use 3G SIM card or 4G SIM card, before testing,make sure it has 2G GSM service.
2) Q: Does your web platform/ APP have monthly or yearly subscription fees?
A: No, our web platform and APP are life-long free for our customers.
3) Q: Can I choose to use other platforms or my own servers?
A: Yes. We have long-term cooperation with many third-party platforms such as Wialon, Traccar and Gpsgate. Also, we could send our open communication protocols to you if necessary.
4) Q: How many devices can I have in one account on your platform or APP?
A: There is no limit to the number of devices used in one account. So, you can add as many devices as you like to your account.
5) Q: Do your GPS trackers have real-time tracking function?
A: Yes. After registeration, you can send command *routetrack*99* to the device and you could have real-time tracking.
6) Q: How do your gps trackers work?
A: We use sms to command the devices. The gps trackers would alert you by SMS/ Call in unusual cases. Also, you can monitor the devices on our free platform or APP.
7) Q: Should the devices work with SIM card?
A: Yes, you need to use a SIM card with SMS, Call and GPRS functions.
8) Q: Hong long can the battery last?
A: In normal use, 3-5 years.
9) Q: Do you have warranty for your products?
A: Yes, we have 12-month warranty for all our products, except for unnatural damage. And we provide good after-sales service for many years.
10) Q: Do you have any certificates for your products?
A: Yes. We have EC-RED, CE and RoHS certificates
After setting APN and master phone number successfully, you could try to log in our free Web server or APP. Our Web server & APP are life long free. And the data is available forever.
You could use as many devices as you like in one account.
On the Web server, you could read the history, add geo-fence and so on. On the APP
you could observe the real time tracking of the objects
Here are our free Web server & APP:
Web server: Miitown
APP: EZ Tracker(IOS) EZ GPS Tracker(Android)
You could contact us and ask for a demo account to try them.
Please do not register directly on our Web server or APP. Our dear customers are suggested
to register and command the device by SMS. If your SIM card does not have SMS function.
For those people who use SIM cards only with GPRS function, please use your APN portal to
send messages to command the device.
For customers who do not want to use our Web server & APP, please contact us when you
get the product. We would send the instructions and protocols to you and help you use
the third-part servers or your own server.
Service:
1. Reply Time:
All inquiries will be answered within 24 hours.
2. Payment Terms:
We accept payment by Visa Card, Master card, Alipay, Qiwi Wallet, Western Union and Bank Transfer T/T.
3. Shipment Terms:
All orders can be shipped out within 1-3 working days normally. Once the order is shipped out, we will send an email to you include the track number and the package photos.
4. Customize and Sample:
OEM & ODM services are accepted if you place an order with enough quantity, and sample first is highly welcome.
5. Protocol Open:
With it, you could integrate with your own platform directly.
6. MOQ Limitation: No MOQ limit, 1 pc for sample checking is available.
7. Warranty:
7.1. All orders will be in good quality, package condition and will be strictly checked before shipment. We will try our best to avoid any unhappy problem from quality or package, therefore, please kindly let us know if you are not satisfied when receive the orders.
7.2. All orders enjoy 12months quality warranty since shipment. We offer free repair always whether it’s with or without warranty period, but buyers need to pay for the accessories cost and shipping cost.
7.3. Please kindly note that, because different display and/or computer monitor, the color will be a little aberration. Therefore, hope your understanding. If you are not happy with the orders, please feel free to let us know.
