Quick Details
-
Weight (KG):
-
800
-
Voltage:
-
220V
-
Place of Origin:
-
Henan
-
Brand Name:
-
MILES
-
Dimension(L*W*H):
-
1250*800*1850mm
-
Product name:
-
tea Leaf Bag Making Packing Machine Price For Tea Pyramid
-
Model:
-
MT-50T6
-
Measuring method:
-
Six heads
-
Packing speed:
-
50bags/min
-
Measuring range:
-
1-10g
-
Measurement accuracy:
-
0.15g
-
Number of unwinding:
-
1 pcs
-
Packing material:
-
Nylon, non-woven fabric, corn fiber, etc.
-
Roll out diameter:
-
400mm
-
Core diameter:
-
76mm
Quick Details
-
Function:
-
FILLING, Wrapping, Labeling, Laminating, Capping, COATING, Sealing, BOXING, Embossing, Gluing, SLITTING
-
Packaging Type:
-
Cartons, CANS, Bottles, Barrel, Stand-up Pouch, Bags, Film, Foil, Belt, Pouch, case
-
Packaging Material:
-
Plastic, Paper, Metal, Glass, Wood
-
Weight (KG):
-
800
-
Voltage:
-
220V
-
Place of Origin:
-
Henan
-
Brand Name:
-
MILES
-
Dimension(L*W*H):
-
1250*800*1850mm
-
Product name:
-
tea Leaf Bag Making Packing Machine Price For Tea Pyramid
-
Model:
-
MT-50T6
-
Measuring method:
-
Six heads
-
Packing speed:
-
50bags/min
-
Measuring range:
-
1-10g
-
Measurement accuracy:
-
0.15g
-
Number of unwinding:
-
1 pcs
-
Packing material:
-
Nylon, non-woven fabric, corn fiber, etc.
-
Roll out diameter:
-
400mm
-
Core diameter:
-
76mm
Product Description
Automatic Tea Sachet Packing Machine Teabag Making Machine Tea Bag Packaging Machine
1. ultrasonic sealing and cutting, pyramid bag and four corners flat bag production process only one key switch.
2. Automatic quantitative measurement.
3. PLC control, touch screen operation, more stable performance.
5. The use of mechanical and electrical integration design, replacement data without stopping / shut down.
6. Can produce tea inner bags with tags.
Specification
|
Item
|
Inner tea bag packing machine
|
Outer tea bag packing machine
|
|
|
Model
|
MT-50T6
|
MT-800C
|
|
|
Measuring method
|
6 heads roller scale
|
/
|
|
|
Packing speed
|
50-60bags/min
|
35-40 bags/min
|
|
|
Measuring range
|
2-10g
|
/
|
|
|
Measurement accuracy
|
±0.15g
|
/
|
|
|
Particle content
|
≤2±0.5g
|
≤2±0.5g (customizable)
|
|
|
Roll width
|
120mm/140mm/160mm/180mm
|
width 70-120mm; length 70-160mm
|
|
|
Roll diameter
|
≤400mm
|
Max 400mm
|
|
|
Core diameter
|
76mm
|
76mm
|
|
|
Air pressure
|
≥0.6Mpa (buyer supply)
|
≥1.2Mpa (buyer supply)
|
|
|
Power
|
220v/380v; 2.8KW
|
220v/380v; 3.5KW
|
|
|
Size
|
1250*800*1850mm
|
1000 *700*1600mm
|
|
|
Weight
|
500kg
|
350kg
|
|
|
Packing material
|
Nylon, non-woven fabric, corn fiber,PLA material, etc (Ultrasonic sealing material/ biodegradable material)
|
|
|
Details Images
Horizontal packing machine
1. Use a horizontal conveyor to directly connect to the outer bag packaging machine, wrap the inner tea bag in the outer bag, and package it independently.
Outer bag: back seal/three-side seal.
2. The outer bag uses a heat-sealing composite film, and the sealing temperature is controlled through touch screen module communication. Patterns can be designed according to customer requirements and automatically follow labels.
3. (Optional) Nitrogen charging device for nitrogen charging.
4. (Optional) Empty package detection and rejection device.
1.
Integrated inner and outer bag packaging machine.
Outer bag: three-side sealing
2. The pneumatic components of the main engine are made of Japanese SMC, and the electrical components are made of Schneider.
3.
The packaging capacity reaches 1800-2100 bags/hour, depending on the material.
4. The host adopts PLC controller. Touch screen operation makes performance more stable and operation easier.
