Quick Details
-
Brand Name:
-
TengShun
-
Model Number:
-
TS-SLA-1204000
-
output voltage and current:
-
12v/4a, 24v/2a, 36v/1.5a, 48v/1a
-
Place of Origin:
-
Guangdong, China
-
Input:
-
AC 100-240V 50/60Hz
-
Input plug:
-
EU US UK AU South Korea Plugs
-
Output:
-
12V4A 24V2A 36V1.5A 48V1A
-
Charge mode:
-
CC--CV--Float Mode
-
Led display:
-
Red--Charging; Green--fully charged
-
Certificate:
-
CE ROHS FCC KC SAA PSE
Quick Details
-
Type:
-
Electric, Desktop Charger
-
Port:
-
DC, AC
-
Function:
-
other
-
Brand Name:
-
TengShun
-
Model Number:
-
TS-SLA-1204000
-
output voltage and current:
-
12v/4a, 24v/2a, 36v/1.5a, 48v/1a
-
Place of Origin:
-
Guangdong, China
-
Input:
-
AC 100-240V 50/60Hz
-
Input plug:
-
EU US UK AU South Korea Plugs
-
Output:
-
12V4A 24V2A 36V1.5A 48V1A
-
Charge mode:
-
CC--CV--Float Mode
-
Led display:
-
Red--Charging; Green--fully charged
-
Certificate:
-
CE ROHS FCC KC SAA PSE
Shenzhen factory electric wheelchair forklift battery charger 48v 36v 24v 12v automatic
battery charger 48v
Application
♦ Electric vehicle, Ebike, Electric Scooter, Mortor, Golf car,
car jumper
♦ Solar Systems, Home Application,UPS
♦ LED Torch, headlight, Portable power bank,etc.
Electrical Specification
♦ Universal Input: 100 – 240V AC, 50/60Hz
♦ Input Plug: EU US UK AU South Korea South Africa Power cords
♦ Output Voltage Range of main products: 4.2~60V DC (Optional)
♦ Output Current Range of main products: 0.5-100A (Optional)
♦ Output: 12V4A 24V2A 36V1.5A 48V1A
♦ Charge mode: CC--CV--Float Mode(Lead acid battery charger)
1. Lead acid Battery Charger
6V Lead acid battery charger: 6.8V(Float Voltage), 7.3V(Top Voltage)
12V Lead acid battery charger: 13.8V(Float Voltage), 14.6V(Top Voltage)
24
V Lead acid battery charger: 27.6V(Float Voltage), 29.2V (Top Voltage)
36
V Lead acid battery charger: 41.4V(Float Voltage), 43.8V
(Top Voltage)
48 V Lead acid battery charger: 55.2V(Float Voltage), 58.4V (Top Voltage)
♦ Led display:
Red--in charging; Green--fully Charge
♦ Cut-off Current:
10-15% of Charge current
♦ Output Connector: 3pin Aviation Plugs, XLR socket, DC Jack, Alligator Clips, SAE connector, Anderson Plugs, RCA
♦ Rated Power: 65W Max
♦ Ripple & Noise:1% of Output Voltage
Mechanical Specification
♦ Size:119*61*35mm;135*66*37mm
♦
Type: desktop Type
♦ Weight:0.3kg/0.4kg
♦ Color:Black
1. 12v1a 24v0.5A lead acid battery charger
2. 12V2A 24V1A Lead acid battery charger
Q1. What are your main products?
Power Supply: 0-150W with 3V 4.5V 5V 6V 7V 9V 10V 12V 15V 18V 19V 20V 24V 25V 30V 36V 48V 60V Outputs
Battery Chargers within 1500W
Lithium/Lipo battery charger
Lifepo4 battery charger
Lead acid battery charger
Nimh/Nicd battery charger
Q2. What is the warranty of your products?
A: 2 years. we can offer the new ones to replace that defective products under warranty.
Q3: What certifications you have?
A: CE ROHS CB GS FCC UL SAA KC KCC PSE CCC for most of products
Q4. What is the lead time?
A: 2-5 days for samples, 12-15 days for mass order. 14 days for new designing.
Q5. What is the shipping way?
A: samples by air, mass order by air or sea. air shipment always choose Fedex,TNT, UPS, DHL with 4-5 days arrival.
Q6. What is the charging mode for your battery chargers?
CC--CV mode for Lithium ion/Lifepo4 Battery charger
CC--CV--Float mode for lead acid battery
CC--CV--Trickle mode for nimh battery
