- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 year, 25 Years
-
Brand Name:
-
Sunpok
-
Model Number:
-
NES144-6-450M
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Product name:
-
Sola Panel
-
Solar cell:
-
166*166mm
-
Junction Box:
-
IP67 Rated
-
Connector:
-
MC4 Compatible Connector
-
Frame:
-
Anodized Aluminium Alloy
-
Cable:
-
4mm2
-
Cell Type:
-
Mono PERC Half Cell
-
Glass:
-
3.2mm Tempered Low Iron
-
OEM/ODM:
-
Acceptale
Quick Details
-
Cell size:
-
166mmx166mm
-
Type:
-
PERC, Half Cell, Shingled
-
Panel Efficiency:
-
20.7%
-
Warranty:
-
25 year, 25 Years
-
Brand Name:
-
Sunpok
-
Model Number:
-
NES144-6-450M
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Product name:
-
Sola Panel
-
Solar cell:
-
166*166mm
-
Junction Box:
-
IP67 Rated
-
Connector:
-
MC4 Compatible Connector
-
Frame:
-
Anodized Aluminium Alloy
-
Cable:
-
4mm2
-
Cell Type:
-
Mono PERC Half Cell
-
Glass:
-
3.2mm Tempered Low Iron
-
OEM/ODM:
-
Acceptale
|
Electrical Characteristics
|
|
|
|
|||
|
Model
|
NES144-6-440M
|
NES144-6-445M
|
NES144-6-450M
|
|||
|
Maximum Power(Pmax)
|
440W
|
445W
|
450W
|
|||
|
Optimum Operating Voltage(Vmp)
|
40.50V
|
40.80V
|
41.00V
|
|||
|
Optimum Operating Current(Imp)
|
10.86A
|
10.92A
|
10.98A
|
|||
|
Open Circuit Voltage(Voc)
|
49.00V
|
49.20V
|
49.50V
|
|||
|
Short Circuit Current(Isc)
|
11.30A
|
11.36A
|
11.42A
|
|||
|
Module Efficiency
|
20.24%
|
20.47%
|
20.70%
|
|||
|
Operating Module Temperature
|
-40 ℃ to +85 ℃
|
|
|
|||
|
Maximum System Voltage
|
1500V DC (IEC)
|
|
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|||
|
STC
|
lrradiance 1000 W/m2 , module temperature 25oC, AM=1.5; Best in Class AAA solar simulator (IEC 60904-9) used
|
|
|
|||
|
Mechanical Characteristics
|
|
|
|
|||
|
Solar Cell
|
166mm 9BB Monocrystalline silicon cells
|
|
|
|||
|
No. of Cells
|
144(6x12x2)
|
|
|
|||
|
Dimensions
|
2094x1038x35mm；2108x1048x35mm
|
|
|
|||
|
Weight
|
24.5kg
|
|
|
|||
|
Front Glass
|
3.2mm(0.13 inches) tempered glass
|
|
|
|||
|
Frame
|
Anodized aluminium alloy
|
|
|
|||
|
Junction Box
|
Ip67 rated
|
|
|
|||
|
Output Cables
|
TÜV (2Pfg1169:2007)
|
|
|
|||
|
|
4.0 mm 2 (0.006 inches 2 ), 300mm/Customized
|
|
|
|||
|
Connectors
|
MC4 connectors
|
|
|
|||
|
Temperature Characteristics
|
|
|
|
|||
|
NOCT
|
45±2 ℃
|
|
|
|||
|
Temperature Coefficient of Pmax
|
-0.380%/ ℃
|
|
|
|||
|
Temperature Coefficient of Voc
|
-0.300%/ ℃
|
|
|
|||
|
Temperature Coefficient of Isc
|
0.060%/ ℃
|
|
|
|||
|
Packing Configuration(35mm)
|
|
|
|
|||
|
Per Pallet
|
30Pieces
|
|
|
|||
|
Per Container (20' GP)
|
282Pieces
|
|
|
|||
|
Per Container (40' HQ)
|
704Pieces
|
|
|
|||
FAQ
Question 1: What kind of Solar Cells do you have?
Answer 1: Mono solar cells, such as 158.75*158.75mm, 166*166mm, 182*182mm, 210*210mm, and Poly solar cells 156.75*156.75mm.
Question 2: What is the lead time?
Answer 2: There are models in stock, we will ship them within 3 days.
Question 3: What is your monthly capacity?
Answer 3:Monthly capacity is about 200MW.
Question 4:What is the warranty period, and how many years?
Answer 4: 12years product warranty, 25years 80% power output warranty for mono facial solar panel, 30years 80% power output warranty for the bifacial solar panel.
Question 5: How is your technical support?
Answer 5: We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you a video call anytime, our engineer will also go to oversea help our customers if necessary.
Question 6:How to become your agent?
Answer 6:Contact us through Alibaba/email, we can talk details to confirm.
Question 7: Is the sample available and free?
Answer 7:Sample will charge cost, but the cost will be refunded after the bulk order.
Question 8: Do you support OEM/ODM?
Answer 8: Of course, we can do customized services for our partners.
