Quick Details
-
Model Number:
-
IFM24-220E2
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
5.68kg
-
The charging ratio:
-
0.2~1C bespoke
-
The discharge rate:
-
0.2~3C bespoke
-
Nominal Voltage:
-
25.6V
-
Max.Continuous discharge current:
-
16A or bespoke
-
Nominal Capacity:
-
22Ah
-
Energy:
-
563.2Wh
-
Case:
-
ABS/Cold Rolled/Stainless Steel Bespoke
-
Standard Charge/Discharge:
-
4.4A
-
Battery Size:
-
26500
-
Certification:
-
IEC/CE/UN38.3
-
Size:
-
195*130*183 mm
Quick Details
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Brand Name:
-
OEM/ODM
-
Model Number:
-
IFM24-220E2
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
5.68kg
-
The charging ratio:
-
0.2~1C bespoke
-
The discharge rate:
-
0.2~3C bespoke
-
Nominal Voltage:
-
25.6V
-
Max.Continuous discharge current:
-
16A or bespoke
-
Nominal Capacity:
-
22Ah
-
Energy:
-
563.2Wh
-
Case:
-
ABS/Cold Rolled/Stainless Steel Bespoke
-
Standard Charge/Discharge:
-
4.4A
-
Battery Size:
-
26500
-
Certification:
-
IEC/CE/UN38.3
-
Size:
-
195*130*183 mm
In the process of cell manufacturing, we strive for perfection and continue to optimize production processes to ensure cell yield and batch consistency. Our consistent aim is to treat defect zero tolerance.
All of our lithium iron phosphate power battery series have been approved UL , CB , UN38.3 and other certifications. The cell is safe, reliable and stable.
If you have the opportunity to come to China, we welcome you to visit our factory and take you to enjoy Chinese food.
Product Parameters
|
Model No.
|
IFM24-220E2
|
|
Pack
|
IFR18650-8S15P
|
|
Nominal Capacity
|
22Ah
|
|
Minimum Capacity
|
20.9Ah
|
|
Nominal Voltage
|
25.6V
|
|
Energy
|
563.2Wh
|
|
Max. Charging Voltage
|
30V
|
|
Discharge Termination
|
21.6V
|
|
Charging Method
|
CC/CV
|
|
Standard charging
|
4.4A
|
|
Max. Charging Current
|
16A
|
|
Standard Discharge
|
4.4A
|
|
Max.Continuous discharge current
|
16A
|
|
Cycle Life
|
0.2C 2000C/80%DOD
|
|
Internal Resistance
|
≤45Ω
|
|
Dimensions
|
195*130*183mm
|
|
Weight (Approx)
|
5.68kg
|
|
Operating Temperature Range
|
Charging: 0℃~45℃
|
|
|
Discharge:-20℃~60℃
|
|
Storage Temperature Range
|
-10℃~35℃
|
Performance Advantage
All of our lithium iron phosphate power battery series have been approved UL , CB , UN38.3 and other certifications. The cell is safe, reliable and stable.
Automatic production line, high product quality and production efficiency, the whole process online monitoring, data traceability,CID safety design.
---
Battery pack cycle life is long, in line with low carbon, energy saving, environmental protection values.
---Intelligent PACK power assembly line with MES system.
---
The battery string provides high safety performance. When the temperature exceeds the threshold, the battery string automatically starts the protection function.
---The BMS management system runs data monitoring, SOC estimation and data transmission.
---
Using lithium iron phosphate battery, high cycle times, safe and reliable.
---Uniform flow design, superior performance.
