bearing,slew drive,gear and pinion,Dia from 50mm-9000mm, Certificated has 3.1,3.2,ABS,CCS.Our team with technical and full experience in the bearing industry. And with a worldwide network, allows us to resolve any bearing issue for you. LYMC bearings are the perfect alternative to the most common and well-known brands.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
LYMC
-
Model Number:
-
162.25.1120.891.21.1503
-
Place of Origin:
-
Henan, China
-
Product Name:
-
Slewing Ring Bearing.slewing Bearing
-
Material:
-
50Mn/42CrMo/Customized
-
Service:
-
24 Hours Service
-
Certificate:
-
ABS CCS
-
Heat treatment:
-
Hardening
-
Precision:
-
P0 P6 P5 P4 P2
-
CAGE:
-
Steel Cage.copper Cage.nylon Cage
-
Application:
-
Automotive.tractor.construction Machinery.rolling Mill
-
Warranty:
-
1 Year
-
Gear:
-
internal Gear
Quick Details
-
Applicable Industries:
-
Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Construction works , Energy & Mining
-
Feature:
-
CROSS ROLLER
-
Seals Type:
-
seal
-
Brand Name:
-
LYMC
-
Model Number:
-
162.25.1120.891.21.1503
-
Place of Origin:
-
Henan, China
-
Product Name:
-
Slewing Ring Bearing.slewing Bearing
-
Material:
-
50Mn/42CrMo/Customized
-
Service:
-
24 Hours Service
-
Certificate:
-
ABS CCS
-
Heat treatment:
-
Hardening
-
Precision:
-
P0 P6 P5 P4 P2
-
CAGE:
-
Steel Cage.copper Cage.nylon Cage
-
Application:
-
Automotive.tractor.construction Machinery.rolling Mill
-
Warranty:
-
1 Year
-
Gear:
-
internal Gear
Product Overview
OEM Internal Gear Ring 162.25.1120.891.21.1503 Swing Roller Bearing Cylindrical Swivel Turntable Exporters
Four-point contact ball slewing turntable bearings
consist of two ring seats. Compact structure, light weight, steel ball and arc track contact at four points, can bear axial force,radial force and overturning moment at the same time, has strong dynamic load.
Single row cross roller slewing bearing
Composed of two or three rings. compact structure, light weight, high manufacturing accuracy, small assembly gap and highrequirement for installation accuracy. Rollers are 1:1 cross-arranged.
Can be bear axial force, overturning moment and large radial force at the same time,and widely used in lifting transportation,construction machinery and precesion products.
Double row ball slewing bearings
This kind of bearings can support high static loads with simple structures. They are mainly used in situations with variation load position and direction and continuously rotating. Main applications of this kind of bearings are deck hoisting, mining and material handling etc.
Three row roller slewing bearing
Three row roller bearing able to bear all kinds of loads at the same time, it is the largest one of the four structural products
with large axle and radial dimensions and firm structure. Especially suitable for heavy machinery requiring larger diameter, such as bucket wheel stacker and reclaimer, wheel crane, marine crane, port crane, ladle turret,large tonnage truck crane,heavy machinery and so on.
consist of two ring seats. Compact structure, light weight, steel ball and arc track contact at four points, can bear axial force,radial force and overturning moment at the same time, has strong dynamic load.
Single row cross roller slewing bearing
Composed of two or three rings. compact structure, light weight, high manufacturing accuracy, small assembly gap and highrequirement for installation accuracy. Rollers are 1:1 cross-arranged.
Can be bear axial force, overturning moment and large radial force at the same time,and widely used in lifting transportation,construction machinery and precesion products.
Double row ball slewing bearings
This kind of bearings can support high static loads with simple structures. They are mainly used in situations with variation load position and direction and continuously rotating. Main applications of this kind of bearings are deck hoisting, mining and material handling etc.
Three row roller slewing bearing
Three row roller bearing able to bear all kinds of loads at the same time, it is the largest one of the four structural products
with large axle and radial dimensions and firm structure. Especially suitable for heavy machinery requiring larger diameter, such as bucket wheel stacker and reclaimer, wheel crane, marine crane, port crane, ladle turret,large tonnage truck crane,heavy machinery and so on.
PRODUCT SPECIFICATIONS
|
Style
|
Item
|
Series
|
Series
|
Series
|
||
|
Single Row Slewing Bearing
|
None Gear
|
010
|
HSB
|
QU
|
||
|
|
Inner Teeth
|
011 012
|
HSN
|
QNA
|
||
|
|
Outer Teeth
|
013 014
|
HSW
|
QWA
|
||
|
Double Row Slewing Bearing
|
None Gear
|
020
|
|
|
||
|
|
Inner Teeth
|
023 024
|
|
|
||
|
|
Outer Teeth
|
021 022
|
|
|
||
|
Three Row Roller Slewing Bearing
|
None Gear
|
130
|
|
|
||
|
|
Inner Teeth
|
133 134
|
|
|
||
|
|
Outer Teeth
|
131 132
|
|
|
||
|
Cross Roller Bearing
|
None Gear
|
110
|
HJB
|
|
||
|
|
Inner Teeth
|
113 114
|
HJN
|
|
||
|
|
Outer Teeth
|
112
|
HJW
|
|
||
Manufacturing Technique
bearing,slew drive,gear and pinion,Dia from 50mm-9000mm, Certificated has 3.1,3.2,ABS,CCS.Our team with technical and full experience in the bearing industry. And with a worldwide network, allows us to resolve any bearing issue for you. LYMC bearings are the perfect alternative to the most common and well-known brands.
SIMILAR PRODUCTS
Application
Construction Machinery
Slewing bearings are widely used in construction machinery such as: excavators, multi-bucket excavators, multi-bucket trenchers, rolling excavators, milling excavators, t
unnel boring machines, shield machines, bulldozers, scrapers, loaders, transport vehicles , Flatbed trucks and dump trucks. Cranes such as tower cranes, self-propelled cranes, mast cranes, grab cranes.
Crane
Crane refers to a multi-action hoisting machinery that vertically lifts and horizontally transports heavy objects within a certain range. Also known as crane, aerial crane, and crane.
The work type of the crane has a very close relationship with the safety performance.
Such as: TS75,TR200,TL250E,NK200,NK250-V
Excavator
We can provide alternative Swing circle for your Excavator slewing bearing There are normal and non standard over 500 hundreds types for you choose.
Such as PC200,PC220,PC1250,R924,R944,
R934
CX130,CX210,JS220,JS200,
R320,
R200,EC180,EC210,DX225,
CAT320,
CAT330,ZX200,SK330,
SK200,SK480,SY130,SY210,SE210,
2054,200CLC and etc.
Filling Machinery
Filling machines are mainly a small class of products in packaging machines. From the perspective of packaging materials,
they can be divided into liquid filling machines, paste filling machines, powder filling machines, and granular filling machines;
from the degree of automation of production It is divided into semi-automatic filling machine and fully automatic filling production line.
Forest Vehicles
Modern logging equipment is mainly logging machine, which is very important for the life time of the logging excavator, Forest Machinery requires strong components,
Our finishing by grinding brings a valid pre-loading which is very important for the life time of the bearing and the comfort of the forest machine's drivers.
The Slewing ring bearing always used dia within 1000mm.Please send us the tyeps or your demands, we can design the bearing for the special machinery.
Ladle Turret
Ladle turret is commonly known as a continuous casting machine; this kind of equipment generally uses three-row roller structure slewing ring bearing,
such as 132.45.2500/2800/3150/3550, etc. Materla always 42Crmo.This structured product is a kind of slewing bearing with high load-carrying capacity,
mainly used in heavy load operation occasions.
Product packaging
Slewing Bearing Package
1 Filling With Anti-rust oil
2 Covered with Plastic Paper
3 Covered With Kraft Paper
4 Covered With Blue Tie
5 Put in Wooden Box
SALES AND SERVICE NETWORK
Why Choose Us
LYMC Bearing Received Good Reputation From The Customers, We Will Do Better And Better For All Of Our Customers
1.Q:Are you trading company or manufacturer?
A:We are original equipment manufacturer.
2.Q:How long is your delivery time?
A:It is according to the model and quantity.Generally it is 3-5 days if the product are in stock.It will be 15-35 days if you want to customize the product.
3.Q:Do you provide samples? ls it free or extra?
A:Yes,we could offer you the sample.But it's not free.
You need to pay for the sample and the cost of freight.
4.Q:What is your terms of payment?
A:We accept T/T,Westerm Union,Money Gram,Paypal,etc.
A:We are original equipment manufacturer.
2.Q:How long is your delivery time?
A:It is according to the model and quantity.Generally it is 3-5 days if the product are in stock.It will be 15-35 days if you want to customize the product.
3.Q:Do you provide samples? ls it free or extra?
A:Yes,we could offer you the sample.But it's not free.
You need to pay for the sample and the cost of freight.
4.Q:What is your terms of payment?
A:We accept T/T,Westerm Union,Money Gram,Paypal,etc.
