Quick Details
-
Place of Origin:
-
China (Mainland)
-
Brand Name:
-
LUNYEE
-
Model Number:
-
LYI-02
-
Voltage(V):
-
12V/24V/36V/48V
-
Output Power:
-
200W
-
Torque:
-
2N.m
-
Max load force:
-
15000N
-
Stroke length:
-
10-600mm
-
Speed:
-
4mms
-
Output signal:
-
potentiometer
-
product name:
-
v Ip65 200mm Electric 10000n Heavy Duty 12v High Speed Linear Actuator
Quick Details
-
Speed(RPM):
-
3000rpm
-
Continuous Current(A):
-
8.1A
-
Efficiency:
-
IE 2
-
Place of Origin:
-
China (Mainland)
-
Brand Name:
-
LUNYEE
-
Model Number:
-
LYI-02
-
Voltage(V):
-
12V/24V/36V/48V
-
Output Power:
-
200W
-
Torque:
-
2N.m
-
Max load force:
-
15000N
-
Stroke length:
-
10-600mm
-
Speed:
-
4mms
-
Output signal:
-
potentiometer
-
product name:
-
v Ip65 200mm Electric 10000n Heavy Duty 12v High Speed Linear Actuator
2000n 16mm/s Inner Double Limit Switch 12v/24v Ip65 200mm Electric 10000n Heavy Duty 12v High Speed Linear Actuator
2000n 16mm/s Inner Double Limit Switch 12v/24v Ip65 200mm Electric 10000n Heavy Duty 12v High Speed Linear Actuator
3200N 24V 300mm stroke heavy duty electric linear actuator with potentiometer
Product Description
Feature
1.The linear actuator is wildly used in various industry equipment and the high load output.It makes human production and life more convenient and efficient.
2.Heavy duty is an important characteristic of the linear actuator. Its IP gread is 65,and the potentiometer feedback is optionnal.
3.This kind of linear actuator has a good waterproof performance and the CE certification.
The quality of our products is outstanding.It will meet your various demands very well.
Specification
| LYI-02 | |||||||||||
| Code | Gear ratio |
Pitch
(mm) |
Speed without load
(mm/s) |
Speed with full load
(mm/s) |
Max load
(push/pull) N |
Max lock
(push/pull) N |
No load amp (A) | Full load amp (A) |
Potentiometer
(Bourns 0-10K ohm A 5%,10- Turn) |
||
| 12V | 24V | 12V | 24V | ||||||||
| A | 40:1 | 4 | 6.5 | 4.5 | 12000 | 15000 | 4 | 2.4 | 20 | 10.5 |
176mm
e.g.100mm stroke=5.7KΩ |
| B | 30:1 | 8.5 | 5 | 11000 | 12000 | 4 | 2.4 | 20 | 10.5 | ||
| C | 20:1 | 13 | 9 | 9000 | 9000 | 4 | 2.4 | 20 | 10.5 | ||
| D | |||||||||||
| E | 40:1 | 8 | 13 | 7 | 10000 | 12000 | 4 | 2.4 | 20 | 10.5 |
352mm
e.g.200mm stroke=5.7KΩ |
| F | 30:1 | 17 | 9.5 | 7000 | 8000 | 4 | 2.4 | 20 | 10.5 | ||
| G | 20:1 | 25 | 14 | 5000 | 6000 | 4 | 2.4 | 20 | 10.5 | ||
| H | |||||||||||
| I | 40:1 | 12 | 20 | 11 | 6500 | 8000 | 4 | 2.4 | 20 | 10.5 |
528mm
e.g.500mm stroke=9.4KΩ |
| J | 30:1 | 25 | 13 | 4500 | 5500 | 4 | 2.4 | 20 | 10.5 | ||
| K | 20:1 | 38 | 24 | 3200 | 4000 | 4 | 2.4 | 20 | 10.5 | ||
Application
Other products
Packaging & Shipping
Packing Method
1.Outer packing: Standard export carton with required shipping marks
2.Inner packing: Waterproof packing with shock absorbing EPE and cardboard surrounded
3.As per the clients requirements
Delivery & Shipment Method
We will ship the items after the payment.
W e can ship to you by UPS/DHL/TNT/EMS/Fedex,by air and by sea.
For the Countries & Regions where EMS cannot deliver,pls choose other shipping ways;
Pls contact us directly and we will use your preferred ways
Our Services
1. Free maintenance within 12 months permanent.
2. Professional research and development team.
3. Technical support for installation.
4. Strict quality control system.
5. Customize production.
6. Competitive price.
