- Product Details
- {{item.text}}
Quick Details
-
Weight (KG):
-
560
-
Voltage:
-
220V 380V 50/60HZ
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZCHONE PACK
-
Product name:
-
Automatic Vertical Packing Machine
-
Bag type:
-
Pillow Bag
-
After Warranty Service1:
-
Video technical support
-
After Warranty Service2:
-
Online support
-
After Warranty Service3:
-
Spare parts
-
After-sales Service Provided4:
-
Free spare parts
-
After-sales Service Provided5:
-
Video technical support
-
After-sales Service Provided6:
-
Online support
-
Certification:
-
CE
-
Packing material:
-
SS304
Quick Details
-
Function:
-
FILLING, Labeling, Sealing
-
Packaging Type:
-
Bags, Film, Pouch
-
Packaging Material:
-
Plastic, Paper
-
Weight (KG):
-
560
-
Voltage:
-
220V 380V 50/60HZ
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZCHONE PACK
-
Product name:
-
Automatic Vertical Packing Machine
-
Bag type:
-
Pillow Bag
-
After Warranty Service1:
-
Video technical support
-
After Warranty Service2:
-
Online support
-
After Warranty Service3:
-
Spare parts
-
After-sales Service Provided4:
-
Free spare parts
-
After-sales Service Provided5:
-
Video technical support
-
After-sales Service Provided6:
-
Online support
-
Certification:
-
CE
-
Packing material:
-
SS304
Optional Equipment
Screw conveyor
Thisr is a new type of transporting equipment, which use detaching rotary screw vane to push material, easy to cleaning.
Auger Filler
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder,wheat flour,condiment, solid drink and so on.
Finish product conveyor
The machine can send the packaged finished pouch to the inspection device or to final packaging platform.
Features
1.Be equipped with automatic diagnostic & safety & alarm system, make it most to ensure personal safety and reducing material loss.
2.Can be equipped with remote diagnostic system, help customer to troubleshooting in minimum duration.
3.Unit made by highly strict manufacturing process, most components are provide by international top brand
4.Comply with international safety & hygienic regulation, each unit shall pass safety, RoHs, physical properly and function test.
5.Advanced design, rational construction, reliable performance, low failure rate6.High speed and efficiency, adjust, operate,and maintain are very convenience.
Specification
|
Packing Speed
|
40-60 bags / min
|
|
Pouch Size (mm)
|
L50 - 300, W90 - 200
|
|
Max. Film Width (mm)
|
420
|
|
Pouch Thickness (mm)
|
0.04 - 0.09
|
|
Pouch Material
|
BOPP / CPP, PET / AL / PE etc
|
|
Compress Air
|
0.8MPa, 0.3m3/min
|
|
Power
|
4.0KW
|
|
Voltage
|
220v 50Hz
|
|
Unit Size (mm)
|
1220*1020*1450
|
|
Unit Weight (kg)
|
450
|
|
Pouch Type
|
Pillow bag, Gusseted bag
|
Q1:Do you have manual or operation video for us to know more about the machine?
Yes, not only manual or operation video, 3D drawing also available to make as per your design,also the videowe can make oftesting the material from our packaging machine if your packing goods easier for us to findfrom our local market.
Q2:How can I trust you for the first time business?
Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba tradeassurance service, guarantee your money, and guarantee your machine's on-time delivery and machinequality.
Q3:ls engineer available to serve oversea?
Yes, but the travel fee is paid by you. So actually to save your cost, we will send you a video of full detailsmachine installation and assist you till the end.
Q4:How can we make sure about the machine quality after we put the order?
Before delivery, we will send you the pictures and videos for you to check the quality, and also you canarrange for quality checking by yourself or by your contacts in China.
Q5:Will you provides the door to door service?
Yes. Please offer us your final destination, we will check with our agent to see ifit available, and most of thearea is ok for us to clearing and sending in your countries.
