> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 years, 25 Years Output Power Guarantee
-
Brand Name:
-
Solar home
-
Model Number:
-
BSM400M-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1986*1002*40mm
-
Front Cover:
-
3.2mm High transmission, low Iron
-
Solar cell:
-
Mono 156*156 Cell
-
Junction Box:
-
IP65 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Certificate:
-
TUV
-
Color:
-
Blue And Black
-
OEM Order:
-
Acceptable
-
Application:
-
Solar Power System
Quick Details
-
Cell size:
-
166mmx166mm
-
Type:
-
PERC
-
Panel Efficiency:
-
18%
-
Warranty:
-
25 years, 25 Years Output Power Guarantee
-
Brand Name:
-
Solar home
-
Model Number:
-
BSM400M-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1986*1002*40mm
-
Front Cover:
-
3.2mm High transmission, low Iron
-
Solar cell:
-
Mono 156*156 Cell
-
Junction Box:
-
IP65 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Certificate:
-
TUV
-
Color:
-
Blue And Black
-
OEM Order:
-
Acceptable
-
Application:
-
Solar Power System
Product Description
|
Module
|
BSM370M-72
|
BSM38
0M-72
|
BSM39
0M-72
|
BSM400M-72
|
|||
|
Rated Maximum Power at STC(Wp)
|
370
|
380
|
390
|
400
|
|||
|
Open Circuit Voltage(Voc/V)
|
48.23
|
48.67
|
49.11
|
49.55
|
|||
|
Maximum Power Voltage(Vmp/V)
|
39.51
|
39.95
|
40.39
|
40.78
|
|||
|
Short Circuit Current(Isc/A)
|
10.03
|
10.22
|
10.41
|
10.59
|
|||
|
Maximum Power Current(Imp/A)
|
9.37
|
9.52
|
9.67
|
9.82
|
|||
|
Module Efficiency(%)
|
19.06
|
19.58
|
20.09
|
20.61
|
|||
|
Power Tolerance
|
-0 ~ +5W
|
|
|
|
|||
|
Standard Test Condition(STC)
|
Irradiance 1000W/m², Cell Temperature 25℃, Air Mass 1.5
|
|
|
|
|||
Detailed
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
Produce Line&Packing
|
By Sea
|
Delivery from Shanghai or Ningbo seaport
|
|
|
||
|
By Air
|
Departure from Shanghai Pudong Airport
|
|
|
||
|
By Express
|
By TNT/DHL
|
|
|
||
Our Company
Global Exhibitions
Project
Payment
|
Payment Term
|
T/T
|
EXW
|
30% T/T in advance, paid the balance before shipment
|
||
|
|
|
FOB
|
|
||
|
|
|
CNF
|
30% T/T in advance, paid the balance against copy of B/L
|
||
|
|
|
CIF
|
|
||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
||
|
|
West Union
|
Amount lower than 5000usd
|
|
||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
||
