75m3/h YHZS75 Mobile Concrete Batching Plant Price

NO

Specifications

QTY

1. Aggregate Supplying System

1.1

aggregate storage bins , total volume: 4 m³X2= 8 m³;4pcs pneumatic cylinder:SC-φ80×250-TC-M-Y

2

1.2

aggregate weighing hopper 2m³,weighing sensor : 1000kgX4,weighing precision : ±2%

1

1.3

discharging belt conveyors B650X8.4m,motor power:4kw

1

2. Aggregate Conveyor Belt

2.1

discharging belt conveyors B650X13.4m,speed 1.6m/s, motor power:5.5kw

1

3.. Additive system

3.1

Water pump ISG32-125, power: 0.75kw

1

3.2

Additive deliver pipe , stainless steel material

3.3

Pipe accessories

1

4. Water Supplying System

4.1

water pump QY15-20-1.1KW

1

4.2

pipe line ,valve Φ150mm .

1

4.3

water weighting hopper :0.3m³; weighing sensor :500kgX1;discharging valve Φ80mm;weighing precision : ±1%

1

5. Pneumatic System

5.1

air compressor, flow rate 1.05m³/min, motor power 5.5kw

1

5.2

PU pipe lineΦ10×12mm,7pcs solenoid valve ( 4V410-15 AC220V ) ,1 pc 3-way connecting kits ( BC4000-15 )

1

6. JS500 Concrete Mixer

6.1

JS500 concrete mixer ,0.5m³/batch, 2 5m³/hr.

1

6.2

pneumatic discharging units 1 set(QGB-ZZ125×150-L3)

1

6.3

transmission system ; gearbox; mixing motor :18.5kw

1

6.4

lubrication system 1 set

1

7. Traveling Chassis

7.1

2-axle chassis

2

7.2

Tyre: 900-R20 ( 2pcs);:825-R12 ( 2pcs)

4

7.3

support feet 6pcs, capacity 20t

6

7.4

steering gear

1

7.5

braking systems , the brake turn indicators

1

7.6

ladder, guardrail, mixing platform

1

8. Electrical Control System( SCHNEIDER Brand)

8.1

comput e r central control system

1

8.2

control system for aggregate supply

1

8.3

control system for cement supply

1

8.4

control system for water supply

1
