Quick Details
-
Fork Length:
-
1070 mm
-
Fork Width:
-
100 mm
-
Overall Dimensions:
-
3646mm*2070mm*1170mm
-
Weight (KG):
-
3680 kg
-
Overall length (without fork):
-
2638mm
-
Marketing Type:
-
Hot Product
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
HELI
-
Fork Length:
-
1070 mm
-
Fork Width:
-
100 mm
-
Overall Dimensions:
-
3646mm*2070mm*1170mm
-
Weight (KG):
-
3680 kg
-
Overall length (without fork):
-
2638mm
-
Marketing Type:
-
Hot Product
MAXIZM Construction Machinery is a one-stop machinery supplier, leading in China for 14 years. Including engineering, mining, warehousing, logistics, and various parts. Cooperate directly with the brand, and the official warranty for all machines is one year. We have shipped machines to over 148 countries in the past 14 years. Any machine, please feel free to consult.
Product Overview
New 2.5 Ton Diesel Heli CPCD25 Forklift
Product Features
1. Transmission box, drive axle and other core parts are self-made by HELI, their box manufacturing and assembly equipment has reached international advanced level. The key parts of the box are imported , and box assembly failure rate is low, and has the best quality of domestic box.
2. With attachment of various types of the masts, all use double built-in hose pulley block, and have compact structure, beautiful appearance, good passage capacity , are first adopted in our country (Patent technology).
3. All lifting mast pipeline have equipped with explosion proof safety valve to ensure the safety of the lifting process.
4. Exhaust system use corrugated pipe to realize flexible connection with frame , and reduce the vibration and noise of the whole vehicle.
5. The steering axle and the frame connection place has done the shock absorption processing, and the shock of whole vehicle has reduced by 30 %.
6. Using intake muffler can suppress the intake pulse, so can reduce the intake noise.
7. Hose joint and transition joint in pipeline are sealed with cone form, which has good sealing effect.
8. Seal for the key parts of the cylinder are imported by NOK , which contribute to sealing reliable and quality stable.
9. Steering trapezium use optimal program, and the maximum error is less than 1°, can reduce tire wear and improve service life.
Applications: As lifting and transporting machineries, this serie forklift trucks are widely used for loading, unloading and
transporting the packaged goods in factories, warehouses, stations, wharves, ports and so on. With other attachments of fork lift trucks., they can be used for the handling of the bulk goods and unpackaged goods.
1. Transmission box, drive axle and other core parts are self-made by HELI, their box manufacturing and assembly equipment has reached international advanced level. The key parts of the box are imported , and box assembly failure rate is low, and has the best quality of domestic box.
2. With attachment of various types of the masts, all use double built-in hose pulley block, and have compact structure, beautiful appearance, good passage capacity , are first adopted in our country (Patent technology).
3. All lifting mast pipeline have equipped with explosion proof safety valve to ensure the safety of the lifting process.
4. Exhaust system use corrugated pipe to realize flexible connection with frame , and reduce the vibration and noise of the whole vehicle.
5. The steering axle and the frame connection place has done the shock absorption processing, and the shock of whole vehicle has reduced by 30 %.
6. Using intake muffler can suppress the intake pulse, so can reduce the intake noise.
7. Hose joint and transition joint in pipeline are sealed with cone form, which has good sealing effect.
8. Seal for the key parts of the cylinder are imported by NOK , which contribute to sealing reliable and quality stable.
9. Steering trapezium use optimal program, and the maximum error is less than 1°, can reduce tire wear and improve service life.
Applications: As lifting and transporting machineries, this serie forklift trucks are widely used for loading, unloading and
transporting the packaged goods in factories, warehouses, stations, wharves, ports and so on. With other attachments of fork lift trucks., they can be used for the handling of the bulk goods and unpackaged goods.
FEATURES AT A GLANCE
PRODUCT SPECIFICATIONS
|
Model
|
|
|
|
CPCD25
|
||
|
Power type
|
|
|
|
Diesel
|
||
|
Rated capacity
|
|
|
kg
|
2500
|
||
|
Load center
|
|
|
mm
|
500
|
||
|
Lift height
|
|
|
mm
|
3300
|
||
|
Mast tilt angle (forward/backward)
|
|
|
Deg
|
5/15
|
||
|
Front overhang
|
|
|
mm
|
550
|
||
|
Wheel-base
|
|
|
mm
|
1850
|
||
|
Tread(front/rear)
|
|
|
mm
|
1250/1205
|
||
|
Travel brake
|
|
|
|
Hydraulic-Foot pedal
|
||
|
Parking brake
|
|
|
|
Mechanical-Hand level
|
||
|
Lift speed(with/without load)
|
|
|
mm/s
|
400/520
|
||
|
Lower speed (with/without load)
|
|
|
mm/s
|
(with load)300
|
||
|
Travel speed (with/without load)
|
|
|
km/h
|
18/23
|
||
|
Max. gradeability (with load)
|
|
|
%
|
17
|
||
|
Engine
|
Model
|
|
|
A495BPG
|
||
|
|
Manufacturer
|
|
|
Xinchang
|
||
|
|
Rated power
|
|
kw
|
42/2650
|
||
|
|
Max.roration
|
|
|
174/1800
|
||
|
|
Dispilacement
|
|
|
2.98
|
||
|
Battery
|
Voltage
|
|
V
|
12
|
||
|
|
Capacity
|
|
Ah
|
100
|
||
|
Gearbox
|
Transmission type
|
|
|
Hydraulic
|
||
|
|
Gears,speed (front/rear)
|
|
|
I/I
|
||
|
Tire
|
type
|
|
|
Spare tyres
|
||
|
|
Model
|
Pront
|
|
11.5/80-15.3-14PR
|
||
|
|
|
Rear
|
|
27×10-12-12PR
|
||
|
Self.weight
|
|
|
kg
|
4750
|
||
|
Free lift height
|
|
|
mm
|
120
|
||
|
Fork
|
Thickness×Width×Length
|
|
mm
|
40×125×1070
|
||
|
Overall dimensions
|
Overall length(without forks)
|
|
mm
|
2910
|
||
|
|
Overall width
|
|
mm
|
1480
|
||
|
|
Overall height
|
Extended height(mast)
|
mm
|
4270
|
||
|
|
|
Lower height(mast)
|
mm
|
2310
|
||
|
|
|
Overhead guard
|
mm
|
2515
|
||
|
Min. turning radius
|
|
|
mm
|
2940
|
||
|
Min. under ground clearance
|
Under mast
|
|
mm
|
220
|
||
|
|
Center of wheel-base
|
|
mm
|
310
|
||
|
Model
|
Unit
|
CPC20/CPCD20/
CP(Q)(Y)20/CP(Q)(Y)D20 |
CPC25/CPCD25/
CP(Q)(Y)25/CP(Q)(Y)D25 |
CPC30/CPCD30/
CP(Q)(Y)30/CP(Q)(Y)D30 |
CPC35/CPCD35/
CP(Q)(Y)35/CP(Q)(Y)D35 |
|||
|
Power type
|
|
Diesel/Gasoline/LPG/CNG
|
|
|
|
|||
|
Operation model
|
|
Sit-on type
|
|
|
|
|||
|
Load capacity
|
kg
|
2000
|
2500
|
3000
|
3500
|
|||
|
Load center
|
mm
|
500
|
|
|
|
|||
|
Max.lifting height
|
mm
|
3000
|
|
|
|
|||
|
Overall length (without fork)
|
mm
|
2580
|
2638
|
2748
|
2766
|
|||
|
Overall width
|
mm
|
1150
|
|
1225
|
|
|||
Our Services & Strength
Our business range is very large as below:
01. Hosting equipment (truck cranes, crawler crane, towe crane, truck mounted crane, etc.)
02. Earthmoving equipment ( excavator, wheel loader, bulldozer, etc.)
03. Road equipment ( road roller, motor grader, asphalt paver, cold milling machine, etc.)
04. Logistic equipment ( forklift, reach stacker, container handler, pallet stacker, etc.)
05. Special trucks (dump truck, tractor truck, water tank truck, semi-trailer, crago truck, etc.)
06. Concrete equipment( concrete mixer, concrete pump truck, concrete/asphalt mixing plant, etc.)
07. Drilling equipment (rotary drilling rig, horizontial direction drill rig, etc.)
08. Agricultural machine( tractor, harvester, etc.)
09. Spare parts all available.
Our business range is very large as below:
01. Hosting equipment (truck cranes, crawler crane, towe crane, truck mounted crane, etc.)
02. Earthmoving equipment ( excavator, wheel loader, bulldozer, etc.)
03. Road equipment ( road roller, motor grader, asphalt paver, cold milling machine, etc.)
04. Logistic equipment ( forklift, reach stacker, container handler, pallet stacker, etc.)
05. Special trucks (dump truck, tractor truck, water tank truck, semi-trailer, crago truck, etc.)
06. Concrete equipment( concrete mixer, concrete pump truck, concrete/asphalt mixing plant, etc.)
07. Drilling equipment (rotary drilling rig, horizontial direction drill rig, etc.)
08. Agricultural machine( tractor, harvester, etc.)
09. Spare parts all available.
PRODUCT CONFIGURATION
CHANGCHAI high power engine
Imported EATON control valve
Japan Shimadzu hydraulic motor
Successful Project
Project in Thailand
Project in India
Project in Russia
