Quick Details
-
Elongation (≥ %):
-
30
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
aerospace, industry use, Aerospace
-
Grade:
-
Nickel
-
Ni (Min):
-
30%, 50
-
Property:
-
Ni-Cr-Fe
-
UNS:
-
N07718
-
Brand Name:
-
Shanghai Phoenix
-
Style:
-
UNS N08800
-
shape:
-
bar/wire/strip/sheet/tube/forging etc
-
Certificate:
-
ISO9001/ROHS/BV
Quick Details
-
Resistance (μΩ.m):
-
1.15
-
Powder Or Not:
-
Not Powder
-
Ultimate Strength (≥ MPa):
-
520
-
Elongation (≥ %):
-
30
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
aerospace, industry use, Aerospace
-
Grade:
-
Nickel
-
Ni (Min):
-
30%, 50
-
Property:
-
Ni-Cr-Fe
-
UNS:
-
N07718
-
Brand Name:
-
Shanghai Phoenix
-
Style:
-
UNS N08800
-
shape:
-
bar/wire/strip/sheet/tube/forging etc
-
Certificate:
-
ISO9001/ROHS/BV
Alloy 800 resists sulfur attack, internal oxidation, scaling and corrosion in a multitude of environments. Alloy 800 is used in a variety of applications involving exposure to corrosive environments and high temperatures. It is used for heat-treating equipment such as baskets, trays, fixtures, and used for heat exchangers and other piping systems in nitric acid media.
Specifications
|
UNS |
W.Nr |
|
N08800 |
1.4876 |
Chemical composition
|
Grade |
% |
Ni |
Cr |
Fe |
C |
Mn |
Si |
Cu |
S |
Al |
Ti |
P |
|
Alloy 800 |
Min |
30 |
19 |
Bal. |
|
|
|
|
|
0.15 |
0.15 |
|
|
Max |
35 |
23 |
0.10 |
1.5 |
1 |
0.75 |
0.015 |
0.60 |
0.60 |
0.03 |
Mechanical properties : (Minimum value at 20 ℃ )
|
σb/MPa |
Yield Strength σp0.2/MPa |
Elongation σ5 /% |
|
520 |
205 |
30 |
Standards
|
Bar |
Forging |
Sheet/Strip |
Wire |
Pipe |
|
ASTM B408
|
|
ASTM B409
|
ASTM B408
|
ASTM B407 ASTM B51 4 |
1.Packing
Standard export packing, carton with plywood case for safety
Wire: below dia 1.0mm, packed in spool; Above 1.0mm, packed in coil
Strip, Bar & Tube, Sheet: Packed in Nylon Polybag first
Welding wire: TIG, 5KGS / box, MIG, 15kgs /spool
The goods can be packed as the clients demand.
2.Delivery time:
We can do the order 45-50days upon receive the 30% deposit or L/C document.
