Quick Details
-
Mold Height(mm):
-
230 - 600 mm
-
Ejector Stroke(mm):
-
150 mm
-
Ejector Force(kN):
-
80 kN
-
Theoretical Shot Volume(cm³):
-
510 cm³
-
Injection Rate (g/s):
-
80 g/s
-
Injection Weight (g):
-
464 g
-
Screw Speed (rpm):
-
0 - 400 rpm
-
Screw diameter (mm):
-
55 mm
-
Screw L/D Ratio:
-
22
-
Weight (KG):
-
10000 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
530 mm
-
Model Number:
-
HXH280
-
Brand Name:
-
CHUANYI
-
Power (kW):
-
37 kW
-
Screw Diameter:
-
50-55mm
-
Dimension:
-
6490*1800*2110mm
-
Drive System:
-
double servo driving system
-
Space between tie-bar:
-
610*560mm
-
Function:
-
Plstic Injection Molding Machinery
-
model no.:
-
HXH 280
-
Machine weight:
-
10T
-
INJECTION SPEED:
-
400
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
610mm
-
Distance between Tie Bars(Height)(mm):
-
560mm
-
Plasticizing Capacity(g/s):
-
80
-
Mold Height(mm):
-
230 - 600 mm
-
Ejector Stroke(mm):
-
150 mm
-
Ejector Force(kN):
-
80 kN
-
Theoretical Shot Volume(cm³):
-
510 cm³
-
Injection Rate (g/s):
-
80 g/s
-
Injection Weight (g):
-
464 g
-
Screw Speed (rpm):
-
0 - 400 rpm
-
Screw diameter (mm):
-
55 mm
-
Screw L/D Ratio:
-
22
-
Weight (KG):
-
10000 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
530 mm
-
Model Number:
-
HXH280
-
Brand Name:
-
CHUANYI
-
Power (kW):
-
37 kW
-
Screw Diameter:
-
50-55mm
-
Dimension:
-
6490*1800*2110mm
-
Drive System:
-
double servo driving system
-
Space between tie-bar:
-
610*560mm
-
Function:
-
Plstic Injection Molding Machinery
-
model no.:
-
HXH 280
-
Machine weight:
-
10T
-
INJECTION SPEED:
-
400
Specifications:
Specification of HXH2 8 0
|
TECHNICAL PARAMETER TABLE |
A |
B |
|
|
Screw diameter |
mm |
50 |
55 |
|
Screw L/D ratio |
L/D |
24 |
22 |
|
Injection capacity in theory |
cm 3 |
422 |
510 |
|
Injection weight (Ps) |
g |
384 |
464 |
|
Injection pressure |
MPa |
1 6 1 |
1 33 |
|
Injection speed |
mm/s |
400 |
|
|
Plasticizing Capacity |
g/s |
57 |
80 |
|
Screw speed |
r/min |
400 |
|
|
Clamping force |
kN |
2600 |
|
|
Opening stroke |
mm |
530 |
|
|
Max mold height |
mm |
600 |
|
|
Min mould height |
mm |
230 |
|
|
Space between tie-bar |
mm |
610x560 |
|
|
Ejector force |
kN |
80 |
|
|
Ejector stroke |
mm |
150 |
|
|
Ejector No. |
n |
13 |
|
|
Pump pressure |
MPa |
17.5 |
|
|
Motor power |
KW |
3 7 +3 7 |
|
|
Heating power |
KW |
17.8 |
|
|
Machine dimension |
m |
6.49x1.80x2.11 |
|
|
Machine weight |
t |
10 |
|
|
Oil tank capacity |
L |
560 |
|
